Festo
8203293
Push-in fitting NPQO-D-M5-Q6-P10
Engineered in a straight design utilizing the push-pull principle, this Festo industrial component features a nominal width of 2.5 mm, a tubing insertion depth of 15.6 mm, and an O-ring seal on the screwed plug. The unit operates within a temperature range of 0 °C to 120 °C and handles an operating pressure spanning from -0.09 MPa to 2 MPa (-0.9 bar to 20 bar, -13.05 psi to 290 psi) for compressed air, inert gases, carbon dioxide, air, oxygen, and nitrogen. Delivered in a pack size of 10, the part requires a nominal tightening torque of 2.25 Nm with a ±10% tolerance and a maximum tightening torque of 2.5 Nm, while offering moderate corrosion resistance (CRC 2) and VDMA24364 Zone III LABS conformity. Submit the exact part number 8203293, desired quantity, and application requirements to request a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 8203293
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 8203293.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Nominal width
- 2.5 mm
- Tubing insertion depth
- 15.6 mm
- Type of seal on screwed plug
- O-ring
- Mounting position
- Any
- Design
- Straight design
- Pack size
- 10
- Structural design
- Push-pull principle
- Operating pressure for entire temperature range
- -0.09 MPa...2 MPa | -0.9 bar...20 bar | -13.05 psi...290 psi
- Operating medium
- Compressed air as per ISO 8573-1:2010 [7:4:4] | Inert gases | Carbon dioxide | Air | Oxygen | Nitrogen
- Corrosion resistance class (CRC)
- 2 - Moderate corrosion stress
- LABS (PWIS) conformity
- VDMA24364 Zone III
- For use in the food industry
- See supplementary material information
- Temperature of medium
- 0 °C...120 °C
- Ambient temperature
- 0 °C...120 °C
- Biocompatibility according to standard
- ISO 18562
- Oxygen suitability according to standard
- ASTM G 93 | ISO 15001
- Impurity level, hydrocarbons maximum
- 550 MGM
- Max. tightening torque
- 2.5 Nm
- Nominal tightening torque
- 2.25 Nm
- Tolerance for nominal tightening torque
- ±10%
- Product weight
- 7.41 g
- Pneumatic connection 1
- External thread M5
- Pneumatic connection 2
- for pneumatic tubing outside diameter 6 mm
- Ambient temperature Fahrenheit
- 32 °F...248 °F
- Releasing ring color
- White
- Material of screwed plug
- high-alloy stainless steel
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 8203293. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
