Confirm the exact configuration
Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.
Global industrial sourcing · Houston, Texas+1 417 261 6001 info@mropartsrfq.com
Reference imageConfirm configuration by manufacturer part number.
Festo
8205393
Parallel grippers HPPH-16-16-NC-P-SR12
Festo Parallel grippers HPPH-16-16-NC-P-SR12, part number 8205393, is documented in the official Festo United States product data sheet. Review the technical specifications and operating conditions below when requesting a quotation.
Request pricing and availabilityCommercial response for your destination and required quantity.
Request a Quote- Manufacturer
- Festo
- Part number
- 8205393
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 8205393.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationTechnical documents are stored and served from our system.
Verified configuration
Technical Specifications
Identification and family-level technical context are preserved from reviewed source evidence and official English-language manufacturer documentation.
- Size
- 16
- Complete stroke
- 16 mm
- Stroke per gripper jaw
- 8 mm
- Max. gripper jaw angular play ax, ay
- 0 deg
- Max. gripper jaw backlash Sz
- 0 mm
- Pneumatic gripper repetition accuracy
- 0.06 mm
- Number of gripper jaws
- 2
- Actuator system
- Pneumatic
- Mounting position
- Any
- Mode of operation
- Double-acting
- Cushioning
- At one end | Not adjustable
- Gripper function
- Parallel
- Gripping force backup
- During closing
- Structural design
- Lateral connection direction | Double piston | Flat mounting type for gripper ngers | Guide | Gear rack/pinion | with gripper nger | Pneumatic gripper | Positively driven motion sequence
- Guide
- Ball guide
- Position sensing
- With integrated linear potentiometer
- Switching status indication
- LED blue, switching status via signal input
- Operating pressure
- 0.25 MPa...0.7 MPa | 2.5 bar...7 bar | 36.25 psi...101.5 psi
- HRC operating pressure
- 0.25 MPa...0.5 MPa | 2.5 bar...5 bar | 36.25 psi...72.5 psi
- Max. operating frequency of pneumatic gripper
- 1 Hz
- Min. opening time at 6 bar
- 180 ms
- Min. closing time at 6 bar
- 90 ms
Technical library
Documents and Data Sheets
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 8205393. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
