Festo
8207658
Label holder ASCF-RP1-XA-50
The Festo part number 8207658 is an industrial component measuring 26 mm in width, 7 mm in height, and 50 mm in length with a size 2 designation and a product weight of 16 g. It accommodates a maximum of 4 valve positions and is compatible with the VTUX-A-P and VTUX-A-S valve manifolds. Built with a CRC rating of 1 for low corrosion stress and compliant with VDMA24364-B1/B2-L LABS conformity, it is suitable for battery production with reduced Cu/Zn/Ni values (F1a). Submit part number 8207658, quantity, and application requirements for a quote today.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 8207658
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 8207658.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Width
- 26 mm
- Height
- 7 mm
- Length
- 50 mm
- Size
- 2
- Pack size
- 1
- Max. no. of valve positions
- 4
- Compatible with
- Valve manifold VTUX-A-P | Valve manifold VTUX-A-S
- Corrosion resistance class (CRC)
- 1 - Low corrosion stress
- LABS (PWIS) conformity
- VDMA24364-B1/B2-L
- Suitability for the production of Li-ion batteries
- Suitable for battery production with reduced Cu/Zn/Ni values (F1a)
- Cleanroom suitability, measured according to ISO 14644-14
- Statically installed element, no meaningful evaluation possible | according to ISO 14644-1
- Storage temperature
- -20 °C...70 °C
- Ambient temperature
- -5 °C...50 °C
- Max. tightening torque
- 0.5 Nm
- Product weight
- 16 g
- Note on materials
- RoHS compliant
- Inscription label holder material
- PA-reinforced
- Sign material
- PVC
- Inspection window material
- PVC
