Festo
8226144
Motor cable NEBM-H17G12-FH-5-Q9N-R3LEG14
This Festo industrial component, part number 8226144, has a product weight of 1.12 kg and conforms to the EN 61984 norm without a label holder. It features a field device side with a straight, round M21x1 hybrid socket connection technology utilizing a screw-type lock, 12 pins, and 12 occupied wires, alongside a control side cable featuring straight RJ45 and open-end connections with 14 pins and 12 occupied wires. The unit operates within a DC operating voltage range of 0 V to 850 V and an AC operating voltage range of 0 V to 630 V. Submit the exact part number, quantity, and application requirements for a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 8226144
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 8226144.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Based on norm
- EN 61984
- Cable designation
- Without label holder
- Product weight
- 1.12 kg
- Electrical connection 1, function
- Field device side
- Electrical connection 1, design
- Round
- Electrical connection 1, connection type
- Hybrid socket
- Electrical connection 1, cable outlet
- Straight
- Electrical connection 1, connection technology
- M21x1
- Electrical connection 1, number of pins/wires
- 12
- Electrical connection 1, occupied pins/wires
- 12
- Electrical connection 1, type of mounting
- Screw-type lock
- Electrical connection 2, function
- Control side
- Electrical connection 2, connection type
- Cable
- Electrical connection 2, cable outlet
- Straight
- Electrical connection 2, connection technology
- RJ45 and open end
- Electrical connection 2, number of pins/wires
- 14
- Electrical connection 2, occupied pins/wires
- 12
- Electrical connection 2, type of mounting
- Inserted
- DC operating voltage range
- 0 V...850 V
- Operating voltage range AC
- 0 V...630 V
- Current rating at 40° C
- 17.8 A
- Surge resistance
- 6 kV
- Shield
- Yes
- Cable length
- 5 m
- Cable characteristic
- suitable for use in the food industry
- Connector cable test conditions
- Test conditions on request
- Bending radius, xed cable installation
- 57.5 mm
- Cable diameter
- 11.5 mm
- Cable diameter tolerance
- ± 0.3 mm
