Festo
8714
End stop limit switch SDK-3-PK-3
The Festo 8714 is a mechanical 3/2-way closed, monostable industrial component featuring a direct-controlled ball seat structural design with soft sealing and an adjustable exhaust air function. Operating with compressed air as per ISO 8573-1:2010 [7:4:4] across a pressure range of 0 bar to 8 bar and temperatures from -10 °C to 80 °C, this 50 g unit delivers a normal nominal flow rate of 16 l/min at an actuating force of 12 N utilizing a PK-3 pneumatic working port. It incorporates a mechanical spring reset method, through-hole mounting, and VDMA24364-B1/B2-L LABS conformity while permitting oil lubrication. Submit the exact part number, quantity, and application requirements to receive a formal quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 8714
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 8714.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Valve function
- 3/2-way, closed, monostable
- Actuation type
- Mechanical
- Normal nominal ow rate (normalized to DIN 1343)
- 16 l/min
- Pneumatic working port
- PK-3
- Operating pressure
- 0 bar...8 bar
- Structural design
- Ball seat
- Reset method
- Mechanical spring
- Nominal width
- 0.6 mm
- Exhaust air function
- Adjustable
- Sealing principle
- Soft
- Type of control
- directly
- Flow direction
- Non-reversible
- Operating medium
- Compressed air as per ISO 8573-1:2010 [7:4:4]
- Information on operating and pilot media
- Operation with oil lubrication possible (required for further use)
- LABS (PWIS) conformity
- VDMA24364-B1/B2-L
- Temperature of medium
- -10 °C...80 °C
- Ambient temperature
- -10 °C...80 °C
- Actuating force
- 12 N
- Product weight
- 50 g
- Type of mounting
- With through-hole
- Pneumatic connection 1
- PK-3
- Pneumatic connection 2
- PK-3
- Pneumatic connection 3
- Not ducted
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 8714. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
