Festo
9626
Adapter AD-3/8NPT-G3/8-I
The Festo part number 9626 is an industrial component featuring an 11.5 mm nominal width, a galvanized steel housing, and PVC seals that comply with RoHS standards. This assembly operates across a pressure range of -0.95 bar to 10 bar and an ambient temperature range of -10 °C to 60 °C, with a low corrosion stress classification of CRC 1 and VDMA24364-B1/B2-L LABS conformity. It weighs 25.98 g and is equipped with a 3/8 NPT external thread for pneumatic connection 1 with a max tightening torque of 22 Nm, alongside a G3/8 internal thread for pneumatic connection 2 with a max tightening torque of 25 Nm. Submit the exact part number, quantity, and application requirements to receive a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 9626
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 9626.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Nominal width
- 11.5 mm
- Operating pressure for entire temperature range
- -0.95 bar...10 bar
- Corrosion resistance class (CRC)
- 1 - Low corrosion stress
- LABS (PWIS) conformity
- VDMA24364-B1/B2-L
- Ambient temperature
- -10 °C...60 °C
- Max. tightening torque, pneumatic connection 1
- 22 Nm
- Max. tightening torque, pneumatic connection 2
- 25 Nm
- Product weight
- 25.98 g
- Pneumatic connection 1
- external thread 3/8 NPT
- Pneumatic connection 2
- Internal thread G3/8
- Note on materials
- RoHS compliant
- Seals material
- PVC
- Housing material
- Steel, galvanized
