Festo
9791
Pressure gauge OH-10
The Festo part number 9791 is an industrial component designed for an operating pressure range of 0.14 MPa to 0.8 MPa (1.4 bar to 8 bar, or 20.3 psi to 116 psi) using compressed air as per ISO 8573-1:2010 [7:-:-]. This RoHS-compliant unit weighs 4 g, features a PK-3 barbed pneumatic connection, and operates within an ambient temperature range of -10 °C to 80 °C with VDMA24364-B1/B2-L LABS conformity. Operation with oil lubrication is possible and required for further use. Submit the exact part number, quantity, and application requirements for a quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Festo references — within one business day.
- Manufacturer
- Festo
- Part number
- 9791
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to 9791.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Operating pressure
- 0.14 MPa...0.8 MPa | 1.4 bar...8 bar | 20.3 psi...116 psi
- Operating medium
- Compressed air as per ISO 8573-1:2010 [7:-:-]
- Information on operating and pilot media
- Operation with oil lubrication possible (required for further use)
- LABS (PWIS) conformity
- VDMA24364-B1/B2-L
- Ambient temperature
- -10 °C...80 °C
- Product weight
- 4 g
- Pneumatic connection
- Barbed connector PK-3
- Note on materials
- RoHS compliant
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Festo 9791. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
