Industrial sourcing catalog
Browse verified product records and request commercial availability, lead time and technical documentation.
Danfoss Power Solutions
The Danfoss Power Solutions 719.40.038.00 is a TAP4NN series external gear pump featuring a displacement of 83.3 ccm, an aluminum housing, and a clockwise rotation configuration driven by an SAE 14T-12/24 splined shaft. It operates at a nominal pressure of 220 bar, supports peak pressures up to 230 bar, and achieves a maximum speed of 3000 U/min with radial side ports. This Frame 4 unit includes an SAE-C 2-hole mounting flange with a 127 mm pilot, rectangular SAE connections, and no integrated valves. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Danfoss Power Solutions
The Danfoss Power Solutions 719.40.031.00 is an external gear pump from the TAP4NN series featuring an 83.3 ccm displacement, a 220 bar operating pressure, and a 230 bar peak pressure rating within an aluminum housing. This frame size 4 component operates at a maximum speed of 3000 U/min with counterclockwise rotation, incorporating an SAE-C 2-hole mounting flange with a 127 mm pilot diameter and a splined SAE 14T-12/24 shaft configured to SAE J498 standards. Fluid connections utilize radial rectangular SAE ports comprising an inlet port sized at 37.5/27x35.71x69.85x1/2-13UNC and an outlet port measuring 31x30.18x58.72x7/16-14UNC, without integrated valves. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Danfoss Power Solutions
The Danfoss Power Solutions TAP4NN external gear pump, part number 719.40.061.00, features a 58.0 ccm displacement and operates at a maximum pressure of 220 bar with a 230 bar peak rating. Constructed with an aluminum housing and a clockwise rotation, this Frame Size 4 component includes a konisch 1/8 shaft with a 6.375mm passfederbreite, a European 4-hole mounting flange with a 63.5mm centering collar, and radial side ports with a 36x62xM10 inlet and 30x56xM10 outlet. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Danfoss Power Solutions
The Danfoss Power Solutions model 719.40.037.00 is an external gear pump featuring a 58.0 ccm displacement, a 220 bar operating pressure, and a 230 bar peak pressure. Constructed with an aluminum housing and a clockwise rotation, this Frame Size 4 TAP4NN series pump operates at a maximum speed of 3000 U/min and utilizes an SAE 14T-12/24 splined shaft configuration alongside an SAE-C 2-bolt mounting flange with a 127 mm pilot diameter. Radial side ports include a rectangular SAE inlet port sized 37,5/27x35,71x69,85x1/2-13UNC and an outlet port sized 31x30,18x58,72x7/16-14UNC without integrated valves. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Danfoss Power Solutions
The Danfoss Power Solutions model 211.20.181.00 is a Frame Size 2 external gear pump featuring a 25,2 ccm displacement, a 160 bar operating pressure, and a 175 bar peak pressure rating within an aluminum housing. This counterclockwise-rotating unit includes a splined SAE 9T-16/32 SAE J498 shaft with through-drive capability, an SAE-A 2-bolt mounting flange with an 82,55 mm pilot diameter, and radial side ports comprising a 1-1/16-12UNF inlet and a 7/8-14UNF UNF SAE O-ring boss outlet. Designed without integrated valves, the pump operates at a maximum speed of 3000 RPM. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Danfoss Power Solutions
The Danfoss Power Solutions SNW2NN series external gear pump, part number 83042267, features a displacement of 22,8 ccm and an aluminum housing with a Frame Size 2 design. This clockwise-rotating unit operates at a continuous pressure of 180 bar with a peak pressure rating of 200 bar, supporting a maximum speed of 3000 U/min. It is equipped with a European 4-hole mounting flange featuring a 36,5 mm centering collar, a 1/8 conical shaft with a 4 mm parallel key and flat tang through-drive, radial inlet and outlet ports sized 20x40xM6 and 15x35xM6 respectively, and lacks integrated valves. Request a quote by submitting the exact part number, quantity, and application requirements.
View product details →
Danfoss Power Solutions
The Danfoss Power Solutions 211.20.683.00 is a Frame Size 2 external gear pump featuring a 19,2 ccm displacement, a 210 bar operating pressure, and a 230 bar peak pressure rating housed in aluminum. This counterclockwise rotating unit utilizes a conical 1/5 shaft configuration with a 3mm Woodruff key and a through-drive flat pin, alongside a German 2-hole mounting flange with a 50mm centering collar and O-ring. Radial ports include a 20x40xM6 inlet and a 15x35xM6 square flange outlet without integrated valves up to a maximum speed of 3000 RPM. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Danfoss Power Solutions
The Danfoss Power Solutions SNW2NN series external gear pump, part number 83018853, features a displacement of 14,4 ccm within a frame size 2 aluminum housing. Engineered for clockwise rotation with an SAE-A 2-hole mounting flange featuring an 82,55 mm pilot diameter and a splined SAE 9T-16/32 shaft configuration with through-drive capability, this unit operates at up to 250 bar with a 280 bar peak pressure rating and a maximum speed of 3500 U/min. Fluid connections utilize radial BSPP threaded ports, consisting of a G 3/4 inlet and a G 1/2 outlet, without integrated valves. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Danfoss Power Solutions
The Danfoss Power Solutions SNP3NN external gear pump, part number 111.25.031.0C, features an 88,2 ccm displacement within a frame size 3 aluminum housing and operates with a clockwise rotation. This model incorporates a European 4-hole mounting flange with a 50,8 mm pilot diameter, a 1/8 taper shaft with a 4 mm parallel key, radial ports with 36x62xM10 inlet and 27x51xM10 outlet dimensions, and lacks integrated valves. Rated for a 150 bar operating pressure, a 170 bar peak pressure, and a maximum speed of 2500 RPM, this unit connects via a European square flange configuration. Submit the exact part number, quantity, and application requirements to receive a quote.
View product details →
Danfoss Power Solutions
The Danfoss Power Solutions 111.25.020.0C is an external gear pump from the SNP3NN series featuring an 88,2 ccm displacement, a frame size of 3, and a clockwise rotation. Constructed with an aluminum housing and an SAE-B 2-hole mounting flange with a 101,6 mm centering collar, this component operates at 150 bar with a peak pressure rating of 170 bar and a maximum speed of 2500 U/min. It utilizes a splined SAE 13T-16/32 shaft configuration per SAE J498, radial side ports with rectangular SAE connections, and contains no integrated valves. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Danfoss Power Solutions
The Danfoss Power Solutions model 111.25.020.0A is an external gear pump from the SNP3NN series featuring a frame size 3 aluminum housing, an 88,2 ccm displacement, and a counterclockwise rotation. It operates at a maximum pressure of 150 bar, a peak pressure of 170 bar, and a maximum speed of 2500 U/min with an SAE-B 2-hole mounting flange, SAE 13T-16/32 splined shaft, and radial side ports. This unit lacks integrated valves and incorporates rectangular SAE inlet and outlet port configurations. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Danfoss Power Solutions
The Danfoss Power Solutions 111.25.073.0C is a Frame 3 SNP3NN series external gear pump featuring an aluminum housing and a displacement of 74.4 ccm with clockwise rotation. It operates at a nominal pressure of 180 bar, supports a peak pressure of 200 bar, and achieves a maximum speed of 2500 U/min. This unit is configured with a European 4-hole mounting flange featuring a 50.8 mm pilot diameter, a 1/8 tapered shaft with a 4 mm keyway, radial side ports with a G 1-1/4 inlet, and a G 1 outlet without integrated valves. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Danfoss Power Solutions
The Danfoss Power Solutions model 111.25.030.0C is a Frame Size 3 external gear pump featuring a 74,4 ccm displacement, a 180 bar operating pressure, and a 200 bar peak pressure. This clockwise-rotating aluminum component is constructed with a european 4-hole mounting flange with a 50,8mm pilot diameter, a tapered 1/8 shaft with a 4mm keyway, radial side ports, and European square flange connections sized 36x62xM10 for the inlet and 27x51xM10 for the outlet. Designed without integrated valves and rated for a maximum speed of 2500 RPM, this industrial unit is ready for specification in your fluid power systems. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Danfoss Power Solutions
The Danfoss Power Solutions SNP3NN frame size 3 external gear pump, part number 111.25.019.0C, features a 74.4 ccm displacement and operates at a maximum speed of 2500 U/min with a clockwise rotation. Constructed with an aluminum housing and an SAE-B 2-hole mounting flange with a 101.6 mm pilot diameter, this unit incorporates a splined SAE 13T-16/32 shaft configured to SAE J498 standards. It delivers an operating pressure of 180 bar and a peak pressure of 200 bar through radial side-oriented rectangular SAE connection ports, including an inlet port sized at 37.5/27x35.71x69.85x1/2-13UNC and an outlet port sized at 31x30.18x58.72x7/16-14UNC without integrated valves. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Danfoss Power Solutions
The Danfoss Power Solutions 111.25.019.0A is an external gear pump featuring a Frame Size 3 SNP3NN series design with a 74,4 ccm displacement and an aluminum housing. This counterclockwise-rotating unit operates at a maximum speed of 2500 U/min, delivering a nominal operating pressure of 180 bar and a peak pressure of 200 bar. It includes an SAE-B 2-hole mounting flange with a 101,6 mm pilot, a splined SAE 13T-16/32 shaft, radial side ports with rectangular SAE connections, and lacks integrated valves. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Danfoss Power Solutions
The Danfoss Power Solutions 111.25.009.0A is an SNP3NN frame size 3 external gear pump featuring a 74.4 ccm displacement, a counterclockwise rotation, and an aluminum housing. This unit is configured with a 13-tooth SAE J498 splined shaft, an SAE-B 2-hole mounting flange with a 101.6 mm pilot, European square flange connections, and radial side ports sized 36x62xM10 for the inlet and 27x51xM10 for the outlet. It operates at a maximum speed of 2500 RPM, an operating pressure of 180 bar, and a peak pressure of 200 bar without integrated valves. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Danfoss Power Solutions
The Danfoss Power Solutions 111.25.072.0C is an SNP3NN series frame size 3 external gear pump featuring an aluminum housing, 63.4 ccm displacement, and a clockwise rotation. This model operates at a 210 bar operating pressure with a 230 bar peak pressure, a maximum speed of 2500 RPM, and lacks integrated valves. It is built with a European 4-hole mounting flange featuring a 50.8 mm pilot diameter, a tapered 1/8 shaft with a 4 mm keyway, radial side ports, a G 1-1/4 inlet, a G 1 outlet, and BSPP threaded connections. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Danfoss Power Solutions
The Danfoss Power Solutions model SNP3NN/063R external gear pump features a 63.4 ccm displacement, a 210 bar operating pressure, and a 230 bar peak pressure with a clockwise rotation. This Frame Size 3 aluminum component utilizes a 4-hole European mounting flange with a 50.8 mm centering collar, a tapered 1/8 shaft with a 4 mm parallel key, and radial side ports including an inlet port size of 36x62xM10 and an outlet port size of 27x51xM10. Operating at a maximum speed of 2500 RPM, this unit does not include integrated valves and uses a European square flange connection type. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Danfoss Power Solutions
The Danfoss Power Solutions 111.25.018.0C is an external gear pump from the SNP3NN series featuring a frame size of 3, an aluminum housing, and a displacement of 63.4 ccm. This clockwise-rotating unit includes an SAE-B 2-hole mounting flange with a 101.6 mm centering collar, a splined SAE 13T-16/32 shaft configuration per SAE J498, and radial side-oriented rectangular SAE connection ports. Operating at a rated pressure of 210 bar with a peak pressure of 230 bar and a maximum speed of 2500 RPM, this model operates without integrated valves. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Danfoss Power Solutions
The Danfoss Power Solutions 111.25.008.0C is a Frame Size 3 external gear pump featuring an aluminium housing, a displacement of 63,4 ccm, and a clockwise rotation. This model delivers an operating pressure of 210 bar with a peak pressure rating of 230 bar at a maximum speed of 2500 U/min, utilizing an SAE-B 2-hole mounting flange, an SAE 13T-16/32 splined shaft, and radial side ports. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
