Festo
The Festo 1380713 is a double-acting industrial component featuring a 40 mm piston diameter and a 10 mm stroke, operating via compressed air in accordance with ISO 8573-1:2010 [7:4:4] across a working pressure range of 0.6 to 10 bar. This unit incorporates flexible cushioning rings or plates at both ends, a male thread piston-rod end, and G1/8 pneumatic connections, delivering a theoretical force of 754 N on the advance stroke and 633 N on the return stroke at 6 bar. Engineered with a moderate corrosion resistance classification CRC of 2, the assembly supports an ambient temperature range of -20 to 80 °C and offers flexible mounting via through holes or threads in any assembly position. Submit the exact part number, quantity, and application requirements to receive a quote for this component.
View product details →
Festo
The Festo 1463475 is an ISO 15552 industrial component featuring a 63 mm piston diameter, an adjustable stroke ranging from 1 mm to 2800 mm, and an M16x1.5 or M10 piston rod thread. Built with a profile barrel, piston, and piston rod structural design, this unit incorporates position sensing via proximity switch and supports multiple cushioning types including elastic rings, adjustable pneumatic cushioning at both ends, and self-adjusting pneumatic end-position cushioning. It operates in any mounting position with a piston rod rotation angle between -0.45 and 0.45 degrees, and is available in numerous application-specific variants. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 14083 is a double-acting industrial component featuring a 63 mm equivalent piston diameter, a 300 mm stroke, and an M16x1.5 piston rod thread with a single-end rod configuration and an oval piston providing an anti-torsion guide with a maximum rotation angle of ±0.67 degrees and 2 Nm max torque. It operates within a 0.6 bar to 10 bar pressure range using compressed air meeting ISO 8573-1:2010 [7:4:4] standards, supports oil-lubricated operation, and incorporates adjustable pneumatic cushioning at both ends with a 23 mm cushioning length. Built with a CRC 2 moderate corrosion stress rating and VDMA24364-B2-L LABS conformity, this unit permits any mounting position, ambient temperatures from -20 °C to 80 °C, position sensing via proximity switch, and delivers a theoretical retracting force of 1682 N at 6 bar. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
This Festo industrial component, part number 1450372, features a 9-pin Sub-D straight socket with 6 occupied pins on the field device side and an open-end cable connection with 6 occupied pins on the control side. The shielded cable spans 10 meters with a 6.2 mm diameter, a 62 mm flexible installation bending radius, and energy chain compatibility for a DC operating voltage range of 0 V to 72 V at a 24 V nominal operating voltage without a label holder. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
Engineered by Festo with a 40 mm piston diameter and a 100 mm stroke, this double-acting industrial component operates at working pressures between 0.6 and 10 bar using compressed air conforming to ISO8573-1:2010 [7:4:4]. The unit features flexible cushioning rings at both ends, a male thread piston-rod end, and G1/8 pneumatic connections, delivering theoretical forces of 754 N on the advance stroke and 633 N on the return stroke at 6 bar. Constructed with a moderate corrosion resistance classification of CRC 2, it functions within an ambient temperature range of -20 to 80 °C and supports optional mounting via through holes or threads. Submit the exact part number, quantity, and application requirements for a formal quote.
View product details →
Festo
The Festo 14082 is a double-acting industrial component featuring a 63 mm equivalent piston diameter, a 250 mm stroke, and an M16x1.5 piston rod thread at one end. This oval piston design provides a maximum angle of rotation of +/- 0.67 degrees, offering a max torque of 2 Nm for protection against torsion, along with adjustable pneumatic cushioning at both ends over a 23 mm cushioning length. It operates within a pressure range of 0.6 bar to 10 bar using compressed air conforming to ISO 8573-1:2010 [7:4:4] across an ambient temperature range of -20 °C to 80 °C, supports position sensing via proximity switch, and achieves a theoretical retracting force of 1682 N at 6 bar. Submit the exact part number, quantity, and application requirements to receive a quote.
View product details →
Festo
The Festo part number 1463452 is a double-acting industrial component featuring a 40 mm piston diameter, an adjustable stroke ranging from 100 mm to 2000 mm, and integrated linear potentiometer position sensing. Operating on compressed air according to ISO 8573-1:2010 [6:4:4] within a pressure range of 0.2 MPa to 0.8 MPa, this unit delivers a theoretical force of 754 N at 6 bar in both advancing and retracting directions. It is constructed with a wrought aluminum alloy cover, incorporates elastic cushioning rings at both ends, and carries RCM, CE, and UKCA conformity markings. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo part number 1380709 is a double-acting industrial component featuring a 40 mm piston diameter and a 40 mm stroke, operating with compressed air in accordance with ISO8573-1:2010 [7:4:4] across a working pressure range of 0.6 to 10 bar. This unit incorporates flexible cushioning rings or plates at both ends, a male thread piston-rod end, and G1/8 pneumatic connections, delivering theoretical forces of 754 N on the advance stroke and 633 N on the return stroke at 6 bar. Constructed with a CRC 2 moderate corrosion resistance classification, it functions within an ambient temperature range of -20 to 80 °C and supports optional mounting via through holes or threads in any assembly position. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
This Festo industrial component, part number 1450371, features a straight 9-pin Sub-D socket on the field device side with 6 occupied pins and a 7 m cable with an open end on the control side having 6 occupied wires. The shielded cable has a 6.2 mm diameter, a 62 mm bending radius for flexible installation, and is suitable for energy chains while operating across a DC voltage range of 0 V to 72 V with a nominal DC operating voltage of 24 V. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
The Festo 1463254 is a double-acting industrial component featuring a 32 mm piston diameter, an M10x1.25 piston rod thread, and a stroke length ranging from 1 mm to 2800 mm. Built with a profile barrel structural design conforming to ISO 15552, it incorporates adjustable pneumatic cushioning at both ends and allows for position sensing via proximity switches across an operating pressure range of 0.6 bar to 12 bar. This unit operates within an ambient temperature range of -20 °C to 80 °C using compressed air as per ISO 8573-1:2010 [7:4:4], and holds a corrosion resistance class of CRC 2 along with ISO Class 5 cleanroom suitability. Submit the exact part number, quantity, and application requirements to receive a quote.
View product details →
Festo
The Festo 1380707 is a double-acting industrial component featuring a 40 mm piston diameter and a 50 mm stroke, operating via compressed air in accordance with ISO 8573-1:2010 [7:4:4] across a working pressure range of 0.6 to 10 bar. This unit incorporates flexible cushioning rings at both ends, a male thread piston-rod end, and offers optional mounting via through holes or threads for installation in any assembly position. It delivers theoretical forces of 754 N on the advance stroke and 633 N on the return stroke at 6 bar, while maintaining an ambient temperature range of -20 to 80 °C and a CRC 2 moderate corrosion resistance classification. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo part number 14081 is a double-acting industrial component featuring a 63 mm equivalent piston diameter, a 200 mm stroke, and an M16x1.5 piston rod thread. This unit utilizes an oval piston for torsion protection, an adjustable pneumatic cushioning system at both ends with a 23 mm cushioning length, and position sensing via proximity switch. It operates within a pressure range of 0.06 MPa to 1 MPa and handles compressed air conforming to ISO 8573-1:2010 [7:4:4] with an ambient temperature range of -20 °C to 80 °C. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo part number 1450370 is an industrial component featuring a 5-meter shielded cable with a 6.2 mm diameter and an energy chain-compatible characteristic requiring a 62 mm flexible cable installation bending radius. Electrical connection 1 on the field device side utilizes a straight, 9-pin Sub-D socket of square design with 6 occupied pins and no label holder, while electrical connection 2 on the control side consists of 6 open-ended wires with all 6 pins occupied. This component operates across a DC voltage range of 0 V to 72 V with a nominal DC operating voltage of 24 V. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
The Festo interface module IC-8M3/2-0,9-24-PH is an industrial component specified in the official Festo EN-US data sheet. Its materials note indicates that the unit contains PWIS substances. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
The Festo 1463252 is a double-acting industrial component featuring a 32 mm piston diameter, an external M10x1.25 piston rod thread at one end, and a profile barrel structural design accommodating strokes from 1 mm to 2800 mm. Operating on compressed air according to ISO 8573-1:2010 [7:4:4] within a 0.06 MPa to 1.2 MPa pressure range and -20 °C to 80 °C ambient temperatures, it conforms to ISO 15552 and incorporates self-adjusting pneumatic end-position cushioning with a 17 mm cushioning length and 0.4 J end-position impact energy. This unit provides position sensing via proximity switch, features a CRC 2 moderate corrosion stress rating, meets VDMA24364-B1/B2-L LABS conformity, and achieves ISO 14644-1 Class 5 cleanroom suitability while supporting any mounting position and optional oil lubrication. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo 14080 is a double-acting industrial component featuring a 63 mm equivalent piston diameter, a 160 mm stroke, and an M16x1.5 piston rod thread with a single-end rod design and oval piston torsion protection. It operates on compressed air according to ISO 8573-1:2010 [7:4:4] within a 0.6 bar to 10 bar pressure range, utilizing adjustable pneumatic cushioning at both ends and position sensing via proximity switch. The unit exhibits a CRC 2 moderate corrosion resistance class, a VDMA24364-B2-L LABS conformity, an ambient temperature range of -20 °C to 80 °C, and delivers a theoretical retracting force of 1682 N at 6 bar. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
This Festo industrial component, part number 1450369, features a straight square 9-pin Sub-D socket with 6 occupied pins on the field device side and an open-ended 6-wire cable with 6 occupied pins on the control side. The shielded assembly includes a 2.5 m cable with a 6.2 mm diameter, a 62 mm flexible bending radius, and energy chain compatibility, operating across a 0 V to 72 V DC range with a 24 V nominal DC voltage and no label holder. Request a formal quote for this exact part number by submitting your required quantity and application details.
View product details →
Festo
The Festo 1379454 is a round, flat industrial component featuring a 40 mm suction cup diameter, a 32.5 mm effective suction cup diameter, and a 3 mm height compensation. Operating within a pressure range of -0.095 MPa to 0 MPa, this transparent 14 g part delivers a holding force of 58 N at its nominal operating pressure of -0.07 MPa utilizing atmospheric air according to ISO 8573-1:2010 [7:-:-]. It accommodates ambient temperatures from -40 °C to 200 °C, features a G1/4 vacuum connection for mounting, and achieves moderate corrosion stress resistance under CRC 2 along with VDMA24364 Zone III LABS conformity. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo 1463250 is an industrial component featuring a 32 mm piston diameter and an adjustable stroke length from 1 mm to 2800 mm based on the ISO 15552 norm. Designed with a profile barrel, piston, and piston rod with M6 or M10x1.25 threading, this unit supports any mounting position and provides position sensing via proximity switch. Cushioning options include elastic rings or pads, adjustable pneumatic end-position cushioning, and self-adjusting pneumatic cushioning, with a maximum piston rod angle of rotation between -0.65 and 0.65 degrees. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 14079 is a double-acting industrial component featuring a 63 mm equivalent piston diameter, a 125 mm stroke, and an M16x1.5 piston rod thread. This unit incorporates an oval piston for torsion protection, providing a maximum anti-rotation torque of 2 Nm and a piston rod rotation angle of plus or minus 0.67 degrees. Configured with adjustable pneumatic cushioning at both ends over a 23 mm cushioning length, the assembly operates within a pressure range of 0.6 bar to 10 bar using compressed air conforming to ISO 8573-1:2010 [7:4:4]. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
