Festo
2385040
Motor controller CMMP-AS-C2-3A-M0-C1
The Festo 2385040 industrial component operates with a nominal operating voltage of 230 V AC, a nominal controller power of 500 VA, and a nominal output current of 2.5 A across an output voltage range of 3x 0 to 270 V AC at an output frequency of 0 to 1,000 Hz. This unit incorporates active PFC, an integrated mains filter, a seven-segment display, a 60 Ohm braking resistance with 2.8 kVA pulse power, a max intermediate circuit voltage of 320 V DC, a set point input impedance of 20 kOhm, electrically isolated and freely configurable digital logic outputs with a 100 mA maximum current and 5 s peak current duration, and a hardware fault tolerance of 1 with 97.07% diagnostic coverage. Integrated safety functions include Safe Torque Off (STO) achieving SIL 3, SILCL 3, and Category 4, Performance Level e, alongside Safe Stop 1 (SS1). Submit the exact part number, quantity, and application requirements for a formal quote.
