Festo
197406
Solenoid valve MHA2-M5H-3/2O-2-TC
The Festo 197406 is an electrical 3/2 open monostable industrial component featuring a width of 10 mm, a grid dimension of 14 mm, and a nominal size of 2 mm with a standard nominal flow rate of 100 l/min. Built with a pressure-relieved poppet valve design structure, soft sealing principle, and mechanical spring reset, this unit supports direct piloting, reversible flow with restrictions, and a maximum switching frequency of 130 Hz across an operating pressure range of -0.9 to 8 bar. Additional specifications include 12V DC operating voltage, subbase pneumatic working line, throttleable exhaust-air function, pushing manual override, IP40 protection class, c UL us recognition, and any assembly position. Submit the exact part number, quantity, and application requirements to request a formal quote for this component.
