Festo
190770
Multiple distributor QSLV2-1/4-5/16-U
The Festo part number 190770 is a standard industrial component featuring a 4.3 mm nominal size, one supply line, and two outputs with 5/16" outside diameter tubing ports. Constructed with a nickel-plated brass threaded plug, a grey release ring, and a coated screw-in stud, this RoHS-compliant assembly supports a complete temperature operating pressure range of -0.95 to 10 bar and lubricated compressed air media in accordance with ISO8573-1:2010 [7:-:-]. It operates within an ambient temperature range of -10 to 60 °C, exhibits a CRC 1 low corrosion stress classification, incorporates a push/pull design structure for any assembly position, and weighs 47 g with a maximum tightening torque of 14 Nm. Submit the exact part number, quantity, and application requirements for a quote.
