Festo
190028
Semi-rotary actuator DRE-8-F05-Q08-FS-O
The Festo 190028 is a single-acting rack and pinion industrial component featuring an actuator size of 8, a 90-degree swivel angle, and an ISO 5211 conforming F05 flange hole pattern. Operating at pressures from 2 to 10 bar on dried compressed air, this unit incorporates VDI/VDE 3845 NAMUR valve connection compliance, spring force closing direction, and an ATEX classification of II 2 GD c X for environments spanning -20°C to +60°C. It offers a corrosion resistance classification of CRC 3, ambient temperature limits of -20 to 80 °C, end-position adjustment ranges of -4 to 8 deg at 0° and -8 to 4 deg at 90°, and is built without cushioning or position detection for any assembly position. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
