Palazzoli
The Palazzoli 616101 is a 30 kW construction site assembly featuring an IP65 protection degree, IK10 shock resistance, and a 4P 63A MCB switch type alongside 63A 4P 30mA differential protection. Operating at 50-60Hz with a rated current of 63A, the unit includes four interlocked socket-outlets at 16A 2P+E 230V and two interlocked socket-outlets at 16A 3P, with a net weight of 22 KG and an ambient temperature range from -25°C to +50°C. Submit part number 616101, quantity, and application requirements to receive an official quote.
View product details →Palazzoli
The Palazzoli 615107 is a 30 kW assembly for construction sites (ACS) featuring interlocked socket-outlets protected by an MCB entry with a terminal block operating at 50-60Hz with an IP65 protection degree. This unit integrates an MCB 4P 63A switch type, a 63A 4P 30mA differential protection, two interlocked 16A 2P+E 230V sockets, one interlocked 16A 3P socket, and one interlocked 32A 3P socket within a 22 KG enclosure rated for IK10 shock resistance. The system functions within an ambient temperature range of -25°C to +50°C and a storage range of -30°C to +70°C at a rated current of 63A. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →Palazzoli
The Palazzoli 615106 is an assembly for construction sites rated for 30 kW and 50-60Hz operation, featuring an MCB 4P 63A switch type and 63A 4P 30mA differential protection with a 63A rated current. This IP65 unit includes terminal block entry, IK10 shock resistance, two interlocked socket-outlets 16A 2P+E 230V, and three interlocked socket-outlets at 16A 3P, 32A 3P, and 63A 3P respectively. Designed to function within ambient temperatures from -25°C to +50°C and storage temperatures from -30°C to +70°C, the 22 KG assembly has a minimum order quantity of 1. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
Palazzoli part number 615105 is a 30 kW construction site assembly featuring an MCB 4P 63A switch type, a 63A 4P 30mA differential protection, and an entry with a terminal block operating at 50-60Hz. The unit is rated for a 63A current and provides IP65 protection, IK10 shock resistance according to IEC/EN 62262, and houses two 16A 2P+E 230V interlocked socket-outlets, two 16A 3P interlocked socket-outlets, and one 32A 3P interlocked socket-outlet with a net weight of 22KG. It functions within an ambient temperature range of -25°C to +50°C and a storage temperature range of -30°C to +70°C. Submit the exact part number, quantity, and application requirements to request a quote for this assembly.
View product details →Palazzoli
Palazzoli part number 615104 is an Assembly for Construction Sites (ACS) featuring interlocked socket-outlets protected by an MCB entry with a terminal block rated for 50-60Hz. This IP65-rated unit delivers 30 kW of power, operates at a rated current of 63A, and includes an MCB 4P - 63A switch type alongside differential protection of 63A 4P 30mA. The configuration incorporates two interlocked socket-outlets at 16A 2P+E 230V, two at 16A 3P, and one at 32A 3P, all housed within an enclosure offering IK10 shock resistance according to IEC/EN 62262, a net weight of 22 KG, and an ambient operating temperature range of -25°C to +50°C. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
Palazzoli part number 615103 is a 30 kW construction site assembly featuring an MCB 4P 63A switch type, a 63A 4P 30mA differential protection, two interlocked socket-outlets at 16A 2P+E 230V, and three interlocked socket-outlets at 16A 3P operating at 50-60Hz. Enclosed in an IP65 rated housing with an IK10 shock resistance according to IEC/EN 62262, this 22 kg unit handles a rated current of 63A across 4 poles within ambient temperatures from -25°C to +50°C. Submit the exact part number, quantity, and application requirements for a formal quote.
View product details →Palazzoli
The Palazzoli 615102 is a 30 kW assembly for construction sites featuring interlocked socket-outlets protected by an MCB entry with a terminal block operating at 50-60Hz with an IP65 protection degree. This unit incorporates a 63A 4P MCB switch type, a 63A 4P 30mA differential protection, three interlocked socket-outlets of 16A 2P+E 230V, one interlocked socket-outlet of 16A 3P, and one interlocked socket-outlet of 32A 3P with a rated current of 63A. Built to withstand an IK10 shock resistance according to IEC/EN 62262, the assembly operates within an ambient temperature range of -25°C to +50°C and has a net weight of 22KG. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
Palazzoli part number 615101 is a 30 kW construction site assembly featuring an MCB 4P 63A switch type, a 63A 4P 30mA differential protection, and a terminal block operating at 50-60Hz. The unit includes three interlocked socket-outlets at 16A 2P+E 230V, one at 16A 3P, and one at 32A 3P, all housed within an IP65 enclosure rated for IK10 shock resistance. It supports an ambient temperature range of -25°C to +50°C, a storage range of -30°C to +70°C, and has a net weight of 22 KG. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
The Palazzoli 614107 is a 20 kW assembly for construction sites featuring interlocked socket-outlets protected by an MCB entry with a terminal block operating at 50-60Hz with an IP65 protection degree. This unit incorporates a 32A 4P MCB switch type, a 40A 4P 30mA differential protection, one 16A 2P+E 230V interlocked socket-outlets, two 16A 3P interlocked socket-outlets, and one 32A 3P interlocked socket-outlets. Built for a rated current of 32A and a net weight of 21KG, it operates within an ambient temperature range of -25°C to +50°C and provides IK10 shock resistance according to IEC/EN 62262. Submit the exact part number, quantity, and application requirements for a quote.
View product details →Palazzoli
The Palazzoli 614106 is a 20 kW assembly for construction sites featuring an IP65 protection degree and IK10 shock resistance operating at 50-60Hz with a rated current of 32A. This unit incorporates an MCB 4P 32A switch type, a 40A 4P 30mA differential protection, a terminal block, and interlocked socket-outlets comprising two 16A 2P+E 230V units, one 16A 3P unit, and one 32A 3P unit. It is rated for ambient temperatures ranging from -25°C to +50°C and storage temperatures between -30°C and +70°C, with a net weight of 21 kg. Submit the exact part number, quantity, and application requirements to receive a quote.
View product details →Palazzoli
The Palazzoli 614105 is an assembly for construction sites rated for 20 kW at 50-60Hz with an IP65 protection degree and IK10 shock resistance. This 32A, 4P unit features an MCB 4P 32A switch type, a 40A 4P 30mA differential protection, two interlocked socket-outlets of 16A 2P+E 230V, and one interlocked socket-outlet of 16A 3P with an entry via terminal block. The enclosure operates within a minimum and maximum ambient temperature range of -25°C to +50°C and has a net weight of 21 kg. Submit the exact part number, quantity, and application requirements to receive a formal quote.
View product details →Palazzoli
The Palazzoli 614104 is an IP65-rated construction site assembly (ACS) with a rated current of 32A, a power capacity of 20 kW, and a frequency of 50/60Hz across 4 poles. This unit features an MCB 4P - 32A switch type, a 40A 4P 30mA differential protection device, two interlocked socket-outlets rated at 16A 2P+E 230V, and two interlocked socket-outlets rated at 16A 3P with a terminal block entry. Built with an IK10 shock resistance according to IEC/EN 62262, the assembly operates within an ambient temperature range of -25°C to +50°C and stores between -30°C and +70°C, carrying a net weight of 21KG and a gross weight of 21.16KG. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →Palazzoli
The Palazzoli 614103 is a 20 kW assembly for construction sites featuring a 32A rated current, 50-60Hz frequency, and IP65 protection degree across 4 poles. This unit includes a 4P 32A MCB switch type, a 40A 4P 30mA differential protection, three interlocked 16A 2P+E 230V socket-outlets, one interlocked 32A 3P socket-outlet, and an MCB entry with a terminal block, delivering IK10 shock resistance with a net weight of 21 kg. Operating within ambient temperatures from -25°C to +50°C and storage temperatures between -30°C and +70°C, it requires a minimum order quantity of one unit. Submit the exact part number, quantity, and application requirements for a formal quote.
View product details →Palazzoli
The Palazzoli 614102 is a 16 kW construction site assembly featuring an MCB 4P 32A switch type, 40A 4P 30mA differential protection, and a terminal block operating at 50-60Hz with an IP65 protection degree. This 4-pole unit includes three interlocked socket-outlets of 16A 2P+E 230V and one interlocked socket-outlet of 16A 3P, yielding a net weight of 21 kg and supporting an ambient temperature range of -25°C to +50°C alongside IK10 shock resistance. Submit the exact part number, quantity, and application requirements to request a quote for this assembly.
View product details →Palazzoli
The Palazzoli 614101 is an Assemblies for construction sites (ACS) with interlocked socket-outlets protected by MCB entry with terminal block 50-60Hz IP65 unit featuring a 7 kW power rating, a 32A 2P MCB switch type, and 32A 2P 30mA differential protection operating at 230V and 50/60Hz. Weighing 21 KG net with a gross weight of 21.22 KG, this IP65-rated and IK10 shock-resistant assembly includes four 16A 2P+E 230V interlocked socket-outlets, a rated current of 32A across 2 poles, and a maximum ambient operating temperature of +50°C alongside a minimum ambient rating of -25°C. Submit your required quantity and application details referencing part number 614101 to receive a formal quotation.
View product details →Palazzoli
The Palazzoli 616009 is a 63A, 40 kW assembly for construction sites featuring an IP65 rating, an inlet frequency of 50-60Hz, and IK10 shock resistance. This unit includes a 63A 4P MCB, a 63A 4P 30mA differential protection, a 3P+N+T 63A plug, two 16A 2P+E 230V interlocked socket-outlets, two 16A 3P interlocked socket-outlets, and one 32A 3P interlocked socket-outlette. Operating within an ambient temperature range of -25°C to +50°C and a storage temperature range of -30°C to +70°C, the system has a net weight of 23 kg. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
The Palazzoli 616008 is an assembly for construction sites rated for 63A and 40 kW operating at 50/60Hz, featuring an MCB 4P - 63A switch type, a 63A 4P 30mA differential protection, and an inlet plug type of 3P+N+T - 63A. This IP65-rated unit includes two interlocked socket-outlets 16A 2P+E 230V, two interlocked socket-outlets 16A 3P, and two interlocked socket-outlets 32A 3P, delivering an IK10 shock resistance according to IEC/EN 62262 with a net weight of 23 kg. It functions within a minimum ambient temperature of -25°C and a maximum ambient temperature of +50°C, alongside a storage temperature range from -30°C to +70°C. Submit the exact part number, quantity, and application requirements for a quote.
View product details →Palazzoli
The Palazzoli part number 616007 is an assembly for construction sites featuring an IP65 rating, a 63A 4P MCB switch, and a 63A 4P 30mA differential protection operating at 50/60Hz with a total power capacity of 40 kW. This unit includes two 16A 2P+E 230V interlocked socket-outlets, two 16A 3P interlocked socket-outlets, two 32A 3P interlocked socket-outlets, and a 3P+N+T 63A plug, with a net weight of 23 KG and an IK10 shock resistance according to IEC/EN 62262. It functions within an ambient temperature range of -25°C to +50°C and a storage temperature range of -30°C to +70°C. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
The Palazzoli part number 616006 is an Assembly for Construction Sites (ACS) featuring an interlocked socket-outlet configuration protected by an MCB entry with an inlet operating at 50-60Hz and an IP65 rating. This unit includes a 63A 4P MCB switch type, a 63A 4P 30mA differential protection, two interlocked 16A 2P+E 230V sockets, three interlocked 16A 3P sockets, one interlocked 32A 3P socket, and a 3P+N+T 63A plug type with a 40 kW power capacity. Rated for a 63A current with IK10 shock resistance according to IEC/EN 62262, the assembly operates within a temperature range of -25°C to +50°C and stores between -30°C and +70°C, with a net weight of 23 kg. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
The Palazzoli 616005 is a 63A 50/60Hz assembly for construction sites featuring an IP65 ingress protection rating, IK10 shock resistance, and a total power capacity of 30 kW. This unit integrates a 4-pole 63A MCB switch, a 63A 4P 30mA differential protection device, a 3P+N+T 63A inlet plug, three interlocked 16A 2P+E 230V socket-outlets, two interlocked 16A 3P socket-outlets, and one interlocked 32A 3P socket-outlet within a 23 kg enclosure. It operates within ambient temperatures from -25°C to +50°C and withstands storage temperatures between -30°C and +70°C. Submit the exact part number, quantity, and application requirements for a formal quote.
View product details →
