Palazzoli
The Palazzoli 532035EX is a wall-mounting junction box manufactured from thermosetting GRP with a low blind cover and a net weight of 0.29 kg. This unit features dimensions of 92x92x68 mm with a box height of 50 mm, a 5 mm thickness, a dissipable power rating of 8W, and an IP66/IP67 degree of protection according to IEC 60670-1. It provides shock resistance of 7 J at -40°C and 4 J at -50°C per IEC 60079-0, and is supplied without a plate for Zone 1-2 gas and Zone 21-22 dust environments. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Palazzoli
Palazzoli part number 532018EX is a wall mounting junction box manufactured from thermosetting GRP with a blind high cover and dimensions of 250x125x125 mm. This enclosure features a box height of 75 mm, a wall thickness of 5 mm, a net weight of 1.02 KG, and a dissipable power rating of 22W. It provides IP66/IP67 degree protection per IEC 60670-1 along with a shock resistance of 7 J at -40°C and 4 J at -50°C according to IEC 60079-0. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →Palazzoli
The Palazzoli 532017EX is a wall-mounted junction box constructed from thermosetting GRP with a blind high cover and dimensions of 185x125x125 mm, featuring a box height of 75 mm, a wall thickness of 5 mm, and a net weight of 0.84 kg. This unit provides IP66 and IP67 protection degrees per IEC 60670-1 alongside a maximum dissipable power of 17W and shock resistance rated at 7 J at -40°C and 4 J at -50°C according to IEC 60079-0. It is rated for use in Zone 1-2 gas and Zone 21-22 dust hazardous environments. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →Palazzoli
The Palazzoli 532016EX is a wall-mounted junction box manufactured from thermosetting GRP with a blind high cover and dimensions of 125x125x125 mm, featuring an internal box height of 75 mm and a wall thickness of 5 mm. This enclosure provides IP66 and IP67 protection according to IEC 60670-1, supports a dissipable power of 15W, and offers a shock resistance of 7 J at -40°C and 4 J at -50°C under IEC 60079-0 for use in gas zones 1-2 and dust zones 21-22. With a net weight of 0.64 kg, this unit requires a minimum order quantity of 1 and is identified by EAN code 8014950009763. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
The Palazzoli 532015EX is a wall-mounting junction box manufactured from thermosetting GRP featuring a blind high cover and dimensions of 185X92X100 mm with an internal box height of 50 mm and a 5 mm thickness. This unit provides IP66/IP67 protection per IEC 60670-1, a dissipable power of 16W, and a net weight of 0.54 kg with a shock resistance rating of 7 J at -40°C and 4 J at -50°C according to IEC 60079-0 for Zone 1-2 gas and Zone 21-22 dust environments. Submit part number 532015EX, required quantity, and application requirements to receive a formal quotation.
View product details →Palazzoli
Palazzoli part number 532006EX is a wall-mounting junction box manufactured from thermosetting GRP with a blind high cover and dimensions of 125x90x100 mm. This enclosure features an IP66/IP67 degree of protection according to IEC 60670-1, a dissipable power rating of 11W, a net weight of 0.43 kg, and a shock resistance of 7 J at -40°C or 4 J at -50°C per IEC 60079-0. It is designated for zone 1-2 gas and zone 21-22 dust environments with a 5 mm thickness and a 50 mm box height. Submit your exact part number, quantity, and application requirements for an official quote.
View product details →
Palazzoli
The Palazzoli 532204EX is a high-capacity junction box manufactured from thermosetting GRP, featuring external dimensions of 380x185x125 mm and a net weight of 2.04 kg. Designed for wall mounting with a blind cover, this IP66/IP67 rated enclosure provides a dissociable power of 25W and a shock resistance of 7 J at -40°C or 4 J at -50°C. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →Palazzoli
The Palazzoli 532203EX is a wall-mounted junction box manufactured from thermosetting GRP featuring a blind cover and an IP66/IP67 protection degree according to IEC 60670-1. This high-capacity unit measures 290x185x125 mm with a box height of 75 mm, a wall thickness of 5.50 mm, and a net weight of 1.70 kg. It offers a dissipable power of 24W and is rated for shock resistance of 7 J at -40°C or 4 J at -50°C under IEC 60079-0 for Zone 1-2 gas and Zone 21-22 dust environments. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
Manufactured by Palazzoli from thermosetting GRP, the 532202EX is a blind-cover junction box featuring high-capacity IP66 and IP67 protection degrees under IEC 60670-1. This wall-mounting enclosure measures 250x185x125 mm externally with a box height of 75 mm, a wall thickness of 5.50 mm, a net weight of 1.53 KG, and a dissipable power rating of 23W. It provides a shock resistance of 7 J at -40°C and 4 J at -50°C in accordance with IEC 60079-0 for hazardous locations in gas zones 1-2 and dust zones 21-22. Submit the exact part number, quantity, and application requirements to request a quote for this Palazzoli component.
View product details →Palazzoli
The Palazzoli 532201EX is a wall-mounted high-capacity junction box manufactured from thermosetting GRP with a blind cover and dimensions of 190x190x125 mm. This enclosure provides IP66/IP67 degree protection according to IEC 60670-1, supports a dissipable power of 19W, and delivers shock resistance of 7 J at -40°C or 4 J at -50°C per IEC 60079-0. Weighing 1.23 kg with a wall thickness of 5.50 mm and a box height of 75 mm, the unit is rated for Zone 1-2 gas and Zone 21-22 dust hazardous areas. Submit the exact part number, quantity, and application requirements to receive a quote for this item.
View product details →Palazzoli
The Palazzoli 532200EX is a wall-mounting junction box manufactured from thermosetting GRP with a blind cover and dimensions of 185x125x125 mm (box height 75 mm). This high-capacity enclosure provides IP66 and IP67 protection degrees per IEC 60670-1, a dissipable power of 18W, and a shock resistance of 7 J at -40°C or 4 J at -50°C according to IEC 60079-0. Featuring a net and gross weight of 0.95 KG and a material thickness of 5.50 mm, the unit is designated for zone 1-2 gas and zone 21-22 dust environments. Submit part number 532200EX, quantity, and application requirements to receive an exact quotation.
View product details →
Palazzoli
The Palazzoli 531062EX is a high-capacity wall-mounting junction box manufactured from thermosetting GRP with an 8.50mm thickness and a blind cover. Featuring exterior dimensions of 500X370X140 mm, internal dimensions of 480X350X120 mm, a box height of 115mm, and a net weight of 9.90KG, this Class II insulated enclosure provides IP66/IP67 ingress protection and a dissipable power of 60W. It withstands mechanical impacts of 7 J at -40°C and 4 J at -50°C under IEC 60079-0 standards. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
The Palazzoli 531042EX is a high-capacity wall-mounting junction box manufactured from thermosetting GRP with external dimensions of 370x250x140 mm and internal dimensions of 350x230X120 mm. This Class II insulated enclosure features a blind cover, a box height of 115 mm, an 8.50 mm wall thickness, a net weight of 5 kg, and a maximum dissipable power of 35W. It provides IP66 and IP67 protection degrees according to IEC 60670-1 alongside a shock resistance rating of 7 J at -40°C and 4 J at -50°C per IEC 60079-0. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →Palazzoli
Engineered for wall mounting by Palazzoli, the 531040EX high-capacity junction box features a thermosetting GRP construction with a blind cover and an 8.50mm material thickness. This IP66/IP67 rated enclosure measures 250X250X140 mm externally with internal dimensions of 230X230X120 mm, a box height of 115mm, and an Insulation Class II design supporting 28W of dissipable power. Weighing 3.90KG net and providing shock resistance of 7 J at -40°C or 4 J at -50°C, the unit carries EAN code 8014950210176. Submit part number 531040EX, your required quantity, and application parameters to request a formal quote.
View product details →Palazzoli
The Palazzoli 531021EX is a high-capacity junction box manufactured from thermosetting GRP with external dimensions of 250X185X140 mm, internal dimensions of 230X165X120 mm, and a wall-mounting execution featuring a blind cover. This Class II insulated enclosure provides IP66 and IP67 protection degrees per IEC 60670-1, supports 24W of dissipable power, and delivers an 8.50 mm thickness with a net weight of 2.70 KG. It withstands mechanical impacts of 7 J at -40°C and 4 J at -50°C in accordance with IEC 60079-0 standards. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
The Palazzoli 531011EX is a high-capacity wall mounting junction box manufactured from thermosetting GRP with external dimensions of 185X185X140 mm, internal dimensions of 165X165X120 mm, and a box height of 115 mm. This Class II insulated enclosure features a blind cover, a wall thickness of 8.50 mm, a net weight of 2.40 kg, and a maximum dissipable power of 20W. It provides IP66 and IP67 protection degrees per IEC 60670-1 alongside shock resistance ratings of 7 J at -40°C and 4 J at -50°C according to IEC 60079-0. Submit the exact part number, quantity, and application requirements to request a quote for this item.
View product details →
Palazzoli
The Palazzoli 532704 is a galvanized steel back plate designed for enclosures measuring 380x185 mm with actual dimensions of 145x135x2 mm and a net weight of 0.79 kg. This component is compatible with enclosure codes 532304, 532204EX, 532204, and 532244EX, adhering to Reg. EU 2023/988 (GPSR) standards. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
Palazzoli part number 532703 is a steel back plate designed for junction box enclosures with dimensions of 290X185 mm, specifically matching enclosure codes 532203EX, 532203, and 532303. This component measures 260x145x2 mm with a net and gross weight of 0.62 KG, complying with Reg. EU 2023/988 (GPSR) standards and directives. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
The Palazzoli 532718 is a galvanized steel back plate designed for TAIS-EX enclosures measuring 250X125 mm, specifically compatible with enclosure codes 532618, 532118EX, 532118, 532628, 538018, 532638, 538118, 532018EX, and 532018. Manufactured from steel and compliant with Reg. EU 2023/988 (GPSR), this 0.26 KG component has a minimum order quantity of 1 and an EAN code of 8014950502400. Submit part number 532718, quantity, and application requirements to request a quote.
View product details →Palazzoli
Manufactured by Palazzoli, the 532717 galvanized steel back plate measures 185X125 mm with exact dimensions of 135x85x2 and a net weight of 0.18 KG. This steel mounting component is compatible with TAIS-EX enclosures bearing codes 532117, 532017EX, 532667, 532117EX, 538017, 532017, and 538117 while complying with Reg. EU 2023/988 (GPSR) standards. Submit a request for quote with the exact part number, quantity, and application requirements to procure this item.
View product details →
