Palazzoli
The Palazzoli 500872 is a 35 kW assembly for construction sites on a stand featuring a stainless steel plate with interlocked socket-outlets protected by fuses operating at 50-60Hz. This 63A, 4P unit includes an SEZ 4P 63A C/FUSE switch type, 63A 4P 30mA differential protection, two interlocked socket-outlets at 16A 2P+E 230V, and three interlocked socket-outlets at 16A 3P. Rated at IP65 with IK10 shock resistance, the 56.58 kg system operates in ambient temperatures from -25°C to +50°C. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
The Palazzoli 500863 is an Assembly for Construction Sites (ACS) on a stand featuring a stainless steel plate, rated for 35 kW, 63A, and 50/60Hz with an IP65 protection degree and IK10 shock resistance. This unit includes an SEZ 4P 63A C/FUSE switch, a 63A 4P 30mA differential protection, three interlocked socket-outlets 16A 2P+E 230V, one interlocked socket-outlet 16A 3P, and one interlocked socket-outlet 32A 3P, operating within a temperature range of -25°C to +50°C with a net weight of 56.58 KG. Submit the exact part number, quantity, and application requirements to receive a quote.
View product details →Palazzoli
The Palazzoli 500874 is an assembly for construction sites on a stand featuring a stainless steel plate with interlocked socket-outlets protected by fuses operating at 50-60Hz with an IP65 protection degree. This unit handles a 35 kW power rating at a 63A rated current across 4P poles, utilizing an SEZ 4P 63A C/FUSE switch type and 63A 4P 30mA differential protection, alongside three 16A 2P+E 230V and two 16A 3P interlocked socket-outlets. Built with an IK10 shock resistance according to IEC/EN 62262, it functions within a minimum ambient temperature of -25°C and a maximum ambient temperature of +50°C, with a net weight of 56.58KG. Submit the exact part number, quantity, and application requirements for an RFQ quote.
View product details →
Palazzoli
The Palazzoli 500897 is a 150 kW assembly for construction sites on a stand featuring a stainless steel plate with direct outlets protected by MCB at 50-60Hz with an IP65 protection degree. This unit incorporates a 250A rated current, a 4P - 250A switch type, a 4P 30mA differential protection, and direct outputs comprising three 4P 25A, three 4P 32A, and two 4P 63A connections. Built with an IK10 shock resistance according to IEC/EN 62262, it operates within an ambient temperature range of -25°C to +50°C and a net weight of 120 KG. Submit the exact part number, quantity, and application requirements for a quote.
View product details →Palazzoli
The Palazzoli part number 500896 is a 120 kW assembly for construction sites on a stand featuring a stainless steel plate with direct outlets protected by MCB at 50-60Hz with an IP65 rating and a rated current of 200A. This unit includes a 4P 200A SEZ switch type, a 4P 30mA differential protection, and direct outputs comprising one 4P 16A, three 4P 25A, three 4P 32A, and one 4P 63A connection. Operating within an ambient temperature range of -25°C to +50°C, storage capabilities from -50°C to +80°C, and an IK10 shock resistance according to IEC/EN 62262, the assembly has a net weight of 120 KG and a gross weight of 120.51 KG. Submit the exact part number, quantity, and application requirements for a quote.
View product details →Palazzoli
The Palazzoli part number 500895 is an assembly for construction sites on a stand featuring a stainless steel plate with direct outlets protected by MCB operating at 50-60Hz with an IP65 protection degree and IK10 shock resistance. This 150 kW unit has a rated current of 250A, includes an SEZ 4P - 250A switch type, a 4P 30mA differential protection, and multiple direct outputs consisting of two 4P 25A, three 4P 32A, and two 4P 63A connections. It operates within an ambient temperature range of -25°C to +50°C and a storage temperature range of -50°C to +80°C, with a net weight of 108 kg. Submit the exact part number, quantity, and application requirements for a formal quote.
View product details →Palazzoli
Palazzoli part number 500894 is an assembly for construction sites on a stand featuring a stainless steel plate with direct outlets protected by an MCB, operating at 50-60Hz with a rated current of 200A and a power capacity of 120 kW. This unit includes a 4P 200A SEZ switch type, a 4P 30mA differential protection, and direct outputs comprising one 4P 16A, two 4P 25A, three 4P 32A, and one 4P 63A connection. Built with an IK10 shock resistance according to IEC/EN 62262 and an IP65 rating, the 108 kg assembly operates within an ambient temperature range of -25°C to +50°C and supports storage temperatures from -50°C to +80°C. Submit the exact part number, quantity, and application requirements for a quote.
View product details →Palazzoli
The Palazzoli 500893 is an assembly for construction sites on a stand featuring a stainless steel plate with direct outlets protected by an MCB, rated for 150 kW and 250A at 50/60Hz. This IP65-rated unit incorporates a 4P 250A SEZ switch type, a 4P 30mA differential protection, and direct outputs comprising one 4P 25A, two 4P 32A, and three 4P 63A connections. Built with an IK10 shock resistance according to IEC/EN 62262, the 100 kg assembly operates within an ambient temperature range of -25°C to +50°C and withstands storage temperatures from -50°C to +80°C. Submit the exact part number, quantity, and application requirements to receive a quote.
View product details →Palazzoli
The Palazzoli 500892 is a 120 kW construction site assembly on a stand featuring a stainless steel plate with direct outlets protected by an MCB operating at 50-60Hz with an IP65 protection degree. This unit incorporates a 200A, 4P SEZ switch type, a 4P 30mA differential protection, and direct outputs consisting of one 4P 25A, four 4P 32A, and one 4P 63A connection. Built for demanding thermal environments, it withstands ambient temperatures from -25°C to +50°C, storage temperatures from -50°C to +80°C, and provides IK10 shock resistance with a net weight of 100 kg. Submit the exact part number, quantity, and application requirements to request a quote for this assembly.
View product details →Palazzoli
The Palazzoli 500891 is an assembly for construction sites on a stand featuring a stainless steel plate with direct outlets protected by MCB operating at 50-60Hz with an IP65 protection degree. This 120 kW, 200A unit includes a 4P 200A SEZ switch type, a 4P 30mA differential protection, one 4P 25A direct output, three 4P 32A direct outputs, and one 4P 63A direct output. Rated for ambient temperatures ranging from -25°C to +50°C and an IK10 shock resistance according to IEC/EN 62262, the assembly has a net and gross weight of 92.50KG. Submit the exact part number, quantity, and application requirements to receive a quote.
View product details →Palazzoli
The Palazzoli 500890 is a 60 kW assembly for construction sites on a stand featuring a stainless steel plate with direct outlets protected by MCB operating at 50-60Hz. This 4-pole unit delivers a 100A rated current, an SEZ 4P - 100A switch type, a 4P 30mA differential protection, one direct output 4P 25A, and four direct outputs 4P 32A within an IP65 protection degree and an IK10 shock resistance rating according to IEC/EN 62262. Designed to function in ambient temperatures ranging from -25°C to +50°C and store in temperatures from -50°C to +80°C, the assembly has a net weight of 92.50KG and a gross weight of 92.69KG. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Palazzoli
The Palazzoli 500886 pair of supports for ACS assemblies measures 590X690mm and features a net and gross weight of 9.25KG per unit. This product complies with Reg. EU 2023/988 (GPSR) and is available with a minimum order quantity of 1, identified by EAN Code 8014950046164. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Palazzoli
The Palazzoli 500885 is a cabinet manufactured from galvanized and painted steel in a blue RAL 5015 color, measuring 1530X740X430 mm with internal dimensions of 1430X685 mm and a net weight of 60.50KG. This Insulation Class I enclosure features an IP65 protection degree, IK10 shock resistance according to IEC/EN 62262, C3 corrosivity category per ISO 12944, and a rated insulation voltage of 500 V while accommodating up to 8 socket-outlets within an ambient temperature range of -25 °C to +50 °C. Please submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
The Palazzoli 500884 is a painted galvanised steel cabinet measuring 1160X740X430 mm with internal dimensions of 1065X685 mm and a net weight of 50.80 KG. Finished in blue RAL 5015, this Class I insulation cabinet provides IP65 protection, IK10 shock resistance according to IEC/EN 62262, and a C3 corrosivity category per ISO 12944 with a rated insulation voltage of 500 V. The unit accommodates 6 installable socket-outlets and operates within an ambient temperature range of -25 °C to +50 °C, with a minimum storage temperature of -30 °C. Submit the exact part number, quantity, and application requirements for a quote on this minimum order quantity of 1 unit.
View product details →
Palazzoli
The Palazzoli 678002 is a 100 kW metal cabinet assembly for construction sites featuring interlocked socket-outlets protected by an MCB entry with a terminal block operating at 50-60Hz with an IP65 rating. This unit features a 200A 4P MCB switch, a 63A 4P 30mA differential protection, and multiple interlocked socket-outlets including two 16A 2P+E 230V, two 16A 3P, two 32A 3P, and one 63A 3P. Built with a net weight of 90KG, an IK10 shock resistance according to IEC/EN 62262, and a rated current of 200A, the assembly functions within a minimum ambient temperature of -25°C and a maximum ambient temperature of +50°C. Submit the exact part number, quantity, and application requirements for a quote.
View product details →Palazzoli
The Palazzoli 678001 is a 100 kW Assemblies for Construction Sites (ACS) housed in a metal cabinet with a net weight of 4.50 kg, operating at a frequency of 50-60Hz with a rated current of 200A. This unit features MCB switch type, modular differential protection, a terminal block entry, and an IP65 rating with an IK10 shock resistance according to IEC/EN 62262, functioning within a minimum ambient temperature of -25°C and a maximum ambient temperature of +50°C. Output configurations include three interlocked socket-outlets at 16A 2P+E 230V, two interlocked socket-outlets at 16A 3P, two interlocked socket-outlets at 32A 3P, and one interlocked socket-outlet at 63A 3P. Submit the exact part number, quantity, and application requirements to receive a formal quote.
View product details →Palazzoli
The Palazzoli 677004 is a 60 kW Assembly for Construction Sites (ACS) housed in a metal cabinet measuring 1160X1330X690 mm with an M63 hole type, featuring an MCB 4P - 100A switch type, a 100A 4P 30mA differential protection, and interlocked socket-outlets comprising two 16A 2P+E 230V units, two 16A 3P units, and three 32A 3P units operating at 50-60Hz with IP65 ingress protection. Designed for wall mounting or installation on a support, this unit weighs 80 KG and is rated for a minimum ambient temperature of -25°C, a maximum ambient temperature of +50°C, and IK10 shock resistance according to IEC/EN 62262. Submit your exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
The Palazzoli 677003 is a 100 kW metal cabinet assembly for construction sites featuring an MCB 4P - 200A switch type, a 100A 4P 30mA differential protection, and an entry terminal block operating at 50-60Hz with an IP65 rating. This unit weighs 80 KG, measures 1160X1330X690 mm, offers IK10 shock resistance according to IEC/EN 62262, and is configured for wall mounting or installation on a support across an ambient temperature range of -25°C to +50°C. It includes interlocked socket-outlets comprising two 16A 2P+E 230V, two 16A 3P, two 32A 3P, and one 63A 3P connection. Submit the exact part number, quantity, and application requirements for a quote.
View product details →Palazzoli
The Palazzoli 677002 is a 60 kW Assemblies for Construction Sites (ACS) housed in a metal cabinet measuring 1160X1330X690 mm with an M63 hole type, featuring an MCB 4P - 100A switch type, a 100A 4P 30mA differential protection, and interlocked socket-outlets comprising two 16A 2P+E 230V units, two 16A 3P units, and three 32A 3P units. Configured for wall mounting or on support, this 50-60Hz IP65 unit operates within a minimum ambient temperature of -25°C and a maximum ambient temperature of +50°C, while offering IK10 shock resistance according to IEC/EN 62262 and an 80KG net and gross weight. Submit the exact part number, quantity, and application requirements for a quote.
View product details →Palazzoli
The Palazzoli 677001 is a 60 kW metal cabinet assembly for construction sites featuring an MCB 4P - 100A switch type, a 100A 4P 30mA differential protection, and an entry terminal block operating at 50-60Hz with an IP65 rating. This unit includes three interlocked socket-outlets at 16A 2P+E 230V, two at 16A 3P, and two at 32A 3P, housed in an 1160X1330X690 mm enclosure with an M63 hole type, IK10 shock resistance, and an 80 kg net and gross weight. Built for wall mounting or support installation, it functions within a minimum ambient temperature of -25°C and a maximum ambient temperature of +50°C. Submit the exact part number, quantity, and application requirements for a formal quote.
View product details →
