Palazzoli
Palazzoli part number 237122 is a 2P two-way switch featuring a 67x67 mm grey front plate for back panel-mounting with an IP65 degree of protection on the front plate and IK08 shock resistance according to IEC/EN 62262. This component operates at a rated current of 12A, a rated insulation voltage of 690 V, and incorporates 2 discs with a CAM layout of 9, accommodating a maximum conductor section of 6 mm² via indirect clamping screw terminals. The unit weighs 0.17 kg net with dimensions of 110x104x164 mm and functions within a minimum ambient temperature range of -25°C and storage temperatures from -40°C to +80°C. Submit part number 237122, quantity, and application requirements to request a quote.
View product details →Palazzoli
Palazzoli part number 237121 is a 1P two-way switch featuring a 67x67 mm grey front plate for back panel-mounting with an IP65 degree of protection on the front plate and IK08 shock resistance according to IEC/EN 62262. This component operates at a rated current of 12A, a rated insulation voltage of 690 V, utilizes 1 disc with a CAM layout of 8, and accommodates a maximum conductor section of 6 mm² via indirect clamping screw terminals. The device maintains a net weight of 0.20 kg, dimensions of 110x104x164 mm, and an ambient operating temperature range from -25°C with storage capabilities between -40°C and +80°C. Submit the exact part number, quantity, and application requirements to request a quote for this item.
View product details →
Palazzoli
The Palazzoli 236253 is a 3-pole, 25A two-way switch featuring a 48x48 mm grey front plate and 3 discs with a CAM 10 layout for back panel-mounting. This IP65 front plate rated device offers an IK08 shock resistance, a rated insulation voltage of 690 V, and accommodates a maximum conductor section of 6 mm² via indirect clamping screw terminals. Measuring 104x64x79 mm with a net weight of 0.20 kg, it operates within an ambient temperature range of -25°C to +80°C storage. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
The Palazzoli 236252 is a 2P two-way switch featuring a 48x48 grey front plate designed for back panel-mounting with an IP65 degree of protection on the front plate and an IK08 shock resistance rating. This component operates at a rated current of 25A with a rated insulation voltage of 690V, utilizing screw indirect clamping terminals supporting a maximum conductor section of 6mm² across 2 discs and CAM layout 9. The unit measures 104x64x79 mm with a net weight of 0.14 kg and functions within an ambient temperature range of -25°C to a storage maximum of +80°C. Submit the exact part number, quantity, and application requirements to receive a formal quote.
View product details →Palazzoli
The Palazzoli 236251 is a 25A single-pole two-way switch featuring a 48x48 mm grey front plate designed for back panel-mounting with an IP65 degree of protection. This component utilizes one disc, CAM layout 8, and screw terminals with indirect clamping supporting a maximum conductor section of 6 mm². Constructed with an IK08 shock resistance rating according to IEC/EN 62262 and a rated insulation voltage of 690 V, the unit operates in ambient temperatures from -25°C to +80°C. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →Palazzoli
Palazzoli part number 236203 is a 20A, 3-pole two-way switch featuring 3 discs, a CAM layout of 10, and a 48x48 mm grey front plate designed for back panel-mounting. This component provides an IP65 degree of protection on the front plate, IK08 shock resistance according to IEC/EN 62262, and accommodates a maximum conductor section of 6 mm² via indirect clamping screw terminals. The unit operates within a minimum ambient temperature of -25°C and a storage temperature range from -40°C to +80°C, supporting a rated insulation voltage of 690 V with dimensions of 104x64x79 mm and a net weight of 0.19 kg. Submit the exact part number, quantity, and application requirements for a quote.
View product details →Palazzoli
The Palazzoli 236202 is a 20A, 2-pole two-way switch featuring two discs and a CAM layout of 9 for back panel-mounting applications. Built with an IP65 front plate providing additional ingress protection and an IK08 shock resistance rating according to IEC/EN 62262, this device accommodates a maximum conductor section of 6mm² via screw terminals with indirect clamping. It operates across a minimum ambient temperature of -25°C and a storage temperature range from -40°C to +80°C, supported by a rated insulation voltage of 690V and dimensions of 104x64x79mm with a 48x48mm grey front plate. Submit the exact part number, quantity, and application requirements for a quote.
View product details →Palazzoli
The Palazzoli 236201 is a 20A 1P two-way switch featuring a 48x48 grey front plate designed for back panel-mounting with an IP65 front plate protection degree and IK08 shock resistance according to IEC/EN 62262. This component includes 1 disc, CAM layout 8, indirect clamping screw terminals accommodating a maximum conductor section of 6mm², and a rated insulation voltage of 690V within dimensions of 104x64x79 mm. It operates in ambient temperatures from -25°C and withstands storage temperatures between -40°C and +80°C, with a net weight of 0.14 KG. Submit the exact part number, quantity, and application requirements for a formal quote.
View product details →Palazzoli
The Palazzoli 236163 is a 3-pole two-way switch featuring a 48x48 grey front plate designed for back panel-mounting with an IP65 front plate degree of protection. This 16A component incorporates 3 discs, CAM layout 10, screw terminals with indirect clamping, and accommodates a maximum conductor section of 6mm². Operating within a minimum ambient temperature of -25°C and storage temperatures ranging from -40°C to +80°C, the unit offers a rated insulation voltage of 690 V and IK08 shock resistance according to IEC/EN 62262. Submit the exact part number, quantity, and application requirements for an RFQ quote.
View product details →Palazzoli
The Palazzoli 236162 is a 2-pole, 16A two-way switch featuring two discs and a CAM layout of 9 for back panel-mounting. This component incorporates an IP65 front plate measuring 48x48 mm, indirect clamping screw terminals supporting a maximum conductor section of 6 mm², and an IK08 shock resistance rating according to IEC/EN 62262. Operating within a minimum ambient temperature range of -25°C and with a rated insulation voltage of 690V, the unit weighs 0.26 kg with overall dimensions of 104x64x79 mm. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
Palazzoli part number 236161 is a 16A, 1P two-way switch featuring a 48x48 mm grey front plate for back panel-mounting with an IP65 degree of protection. This component utilizes one disc with a CAM layout of 8, indirect clamping screw terminals supporting a maximum conductor section of 6mm², and provides an IK08 shock resistance according to IEC/EN 62262 alongside a rated insulation voltage of 690V. The unit operates within a minimum ambient temperature of -25°C and storage temperatures ranging from -40°C to +80°C, with overall dimensions of 104x64x79 and a net weight of 0.13 KG. Submit the exact part number, quantity, and application requirements for a quote.
View product details →Palazzoli
The Palazzoli 236123 is a 3-pole two-way switch featuring 3 discs, a CAM layout of 10, and a rated current of 12A at a rated insulation voltage of 690V. Designed for back panel-mounting, this component includes an IP65-rated 48x48 mm grey front plate, screw indirect clamping terminals supporting a maximum conductor section of 6mm², and an IK08 shock resistance rating according to IEC/EN 62262. The unit operates within a minimum ambient temperature range of -25°C and withstands storage temperatures from -40°C to +80°C, with a net weight of 0.19 kg and dimensions of 104x64x79 mm. Submit the exact part number, quantity, and application requirements to request a formal quote.
View product details →Palazzoli
The Palazzoli 236122 is a 2-pole, 12A two-way switch featuring two discs and a CAM layout of 9 for back panel-mounting applications. This component includes a 48x48 mm grey front plate providing IP65 degree protection, complemented by an IK08 shock resistance rating according to IEC/EN 62262 and a rated insulation voltage of 690 V. Featuring screw indirect clamping terminals supporting a maximum conductor section of 6 mm², the unit operates within a minimum ambient temperature range of -25°C and withstands storage temperatures from -40°C to +80°C. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this product.
View product details →Palazzoli
The Palazzoli 236121 is a 1P two-way switch rated at 12A with 1 disc and an 8 CAM layout designed for back panel-mounting. Featuring a 48x48 grey front plate with an IP65 protection degree and IK08 shock resistance, this component accommodates a max conductor section of 6mm² via indirect clamping screw terminals. It operates across a minimum ambient temperature of -25°C and withstands storage temperatures from -40°C to +80°C with a rated insulation voltage of 690 V. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
The Palazzoli 223633 is a three-pole reversing switch rated at 63A with a 690V rated insulation voltage, featuring three discs, a CAM layout of 12, and a 67x67 grey front plate for back panel-mounting with an IP65 degree of protection. Designed with an IK08 shock resistance according to IEC/EN 62262, this 0.40 KG unit accommodates a minimum conductor section of 2.50mm² up to a maximum of 16mm², operating within an ambient temperature range of -25°C to +60°C and a storage range of -40°C to +80°C. Submit the exact part number, quantity, and application requirements to request a quote for this component.
View product details →Palazzoli
The Palazzoli 223403 is a three-pole reversing switch featuring three discs, a CAM layout of 12, and a 67x67 grey front plate designed for back panel-mounting with an IP65 rating. Rated at 40A with a rated insulation voltage of 690V, this unit accommodates conductor sections from 2.50mm² to 16mm² and provides IK08 shock resistance according to IEC/EN 62262. Operating reliably in ambient temperatures ranging from -25°C to +60°C and with a net weight of 0.36 KG, this component has dimensions of 110x104x164 mm. Submit the exact part number, quantity, and application requirements for a formal quote.
View product details →Palazzoli
The Palazzoli 32A three-pole reversing switch features three discs with a CAM layout of 12 and a 67x67 grey front plate designed for back panel-mounting. This IP65-rated component accommodates a minimum conductor section of 2.50mm² and a maximum conductor section of 16mm², operating within an ambient temperature range of -25°C to +60°C. It provides an IK08 shock resistance rating according to IEC/EN 62262 and a rated insulation voltage of 690V, with a net weight of 0.33KG and dimensions measuring 110x104x164. Submit part number 223323, quantity, and application requirements to request a quote.
View product details →Palazzoli
The Palazzoli 222253 is a three-pole reversing switch featuring a 67x67 mm grey front plate and is designed for back panel-mounting with an IP65 degree of protection on the front plate. Rated at 25A with a 690V insulation voltage, this 3-disc component utilizes a 12 CAM layout and accommodates a minimum conductor section of 1.50 mm². It offers IK08 shock resistance according to IEC/EN 62262, operating within an ambient temperature range of -25°C to +60°C and a storage range of -40°C to +80°C. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this 0.19 kg assembly.
View product details →Palazzoli
Palazzoli part number 222203 is a three-pole reversing switch featuring a 67x67 grey front plate designed for back panel-mounting with an IP65 degree of protection on the front plate. This 3P device operates at a rated current of 20A with a rated insulation voltage of 690V, utilizing 3 discs and a CAM layout of 12. Accommodating conductor sections from 1.50mm² to 6mm², the unit weighs 0.19 kg net and provides IK08 shock resistance according to IEC/EN 62262 across ambient temperatures from -25°C to +60°C. Submit the exact part number, quantity, and application requirements to request a formal quote for this product.
View product details →Palazzoli
The Palazzoli 222163 is a three-pole reversing switch featuring a 67x67 grey front plate designed for back panel-mounting with an IP65 degree of protection on the front plate. This 16A component incorporates 3 poles, 3 discs, and a cam layout of 12, operating within an ambient temperature range of -25°C to +60°C and accommodating conductor sections from 1.50mm² to 6mm². Built with an IK08 shock resistance rating per IEC/EN 62262 and a rated insulation voltage of 690V, the unit measures 110x104x164 and has a net weight of 0.19 kg. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
