Palazzoli
The Palazzoli 63A 4P wall-mounting isolator switch features a durable aluminium alloy construction with windowed walls, rated for 50-60Hz operation with IP66/IP67 ingress protection and 400°C 120' fire resistance. Engineered with a CAM layout of 3, a rated insulation voltage of 690 V, and indirect clamping screw terminals supporting a maximum conductor section of 16mm², this unit measures 185X252X230 mm with a net weight of 3.55 KG. The enclosure undergoes fluorozirconic passivation and is finished with an anti-UV non-toxic polyester paint cured in the oven, delivering a corrosivity category equivalent to C5(M)/C4(H) according to ISO 12944 while withstanding maximum ambient temperatures up to +60°C. Submit the exact part number, quantity, and application requirements to request a quote for this component.
View product details →Palazzoli
Engineered by Palazzoli, the part number 152430 is a 63A 3P fire-resistant wall-mounting isolator switch featuring an aluminium alloy construction with windowed walls, fluorozirconic passivation, and a non-toxic anti-UV oven-cured polyester paint finish. The unit operates at 50-60Hz with a rated insulation voltage of 690V, accommodating conductor sections from 6mm² to 16mm² via indirect clamping screw terminals within dimensions of 185X252X230 mm and an IP66/IP67 ingress protection rating. It withstands a maximum ambient temperature of +60°C, a storage temperature up to +80°C, and maintains 400°C 120’ fire resistance with a net weight of 3.40KG. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
Palazzoli part number 152360 is a 6-pole wall-mounting isolator switch with a rated current of 40A, operating at 50-60Hz with a CAM layout of 3.1 and a rated insulation voltage of 690V. Housed in an aluminium alloy enclosure measuring 185X252X230 mm with windowed walls, the unit features IP66/IP67 ingress protection, 400°C 120' fire resistance, fluorozirconic passivation treatment, and a non-toxic anti-UV oven-cured polyester paint surface finish in Grey RAL 7035 and Red RAL 3020. The switch accommodates a minimum conductor section of 4mm² via indirect clamping screw terminals, operates up to a maximum ambient temperature of +60°C, and weighs 3KG net with a gross weight of 3.25KG. Submit the exact part number, quantity, and application requirements for an RFQ quote.
View product details →Palazzoli
The Palazzoli 40A 4P wall-mounting isolator switch features an aluminium alloy construction with windowed walls, fire resistance rated for 400ÞgC 120', and an IP66/IP67 ingress protection rating operating at 50-60Hz. Measuring 185X252X230 mm with a net weight of 3.30 kg, the enclosure is treated with fluorozirconic passivation and finished in non-toxic anti-UV oven-cured polyester paint in Grey RAL 7035 and Red RAL 3020. This component utilizes indirect clamping screw terminals accommodating a minimum conductor section of 4mm², a rated insulation voltage of 690 V, and a CAM layout of 3 while withstanding a maximum ambient temperature of +60ÞgC. Submit the exact part number, quantity, and application requirements to receive a formal quotation for part code 152340.
View product details →Palazzoli
The Palazzoli 152330 is a 3P, 40A wall-mounting isolator switch housed in a fire-resistant aluminium alloy enclosure featuring windowed walls and a CAM 2 layout. Built for 50-60Hz applications, this IP66/IP67 rated device withstands 400°C for 120 minutes, featuring fluorozirconic passivation and a non-toxic anti-UV polyester oven-cured paint finish in grey RAL 7035 and red RAL 3020. The unit measures 185X252X230 mm with a net weight of 2.63 KG, utilizing indirect clamping screw terminals for a minimum conductor section of 4mm² and supporting a rated insulation voltage of 690 V up to a maximum ambient temperature of +60°C. Submit part number 152330, required quantity, and application parameters to request a formal quote.
View product details →
Palazzoli
The Palazzoli 152260 is a 6-pole wall-mounting isolator switch featuring a 25A rated current, 690V rated insulation voltage, and CAM layout 3.1 within an aluminum alloy enclosure measuring 125x185x175 mm. Constructed with windowed walls, fluorozirconic passivation, and non-toxic anti-UV polyester oven-cured paint, this fire-resistant unit is rated for IP66/IP67, 400ÞgC for 120 minutes, and a maximum ambient temperature of +60ÞgC. It utilizes indirect clamping screw terminals accommodating conductor sections from 1.50 mm² to 6 mm² and has a net weight of 2.18 kg. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →Palazzoli
Palazzoli part number 152240 is a 25A 4P wall-mounting isolator switch constructed from aluminium alloy with windowed walls, featuring a CAM layout of 3 and dimensions of 125X185X175 mm. The enclosure is finished with fluorozirconic passivation and non-toxic anti-UV polyester paint in grey RAL 7035 and red RAL 3020, operating at 50-60Hz with IP66/IP67 ingress protection and a 400°C 120’ fire-resistant rating. Electrical connections utilize indirect clamping screw terminals accommodating conductors from 1.50mm² to 6mm², while maintaining a maximum ambient operating temperature of +60°C and storage up to +80°C with a net weight of 1.25KG. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →Palazzoli
The Palazzoli 152230 is a 25A 3P fire-resistant wall-mounted isolator switch featuring an aluminium alloy construction with windowed walls, configured with CAM layout 2 and measuring 125X185X175 mm. Protected by a fluorozirconic passivation treatment and a non-toxic anti-UV polyester paint cured in the oven, this IP66/IP67-rated unit operates at 50-60Hz with a rated insulation voltage of 690 V and supports a maximum ambient temperature of +60°C alongside a 400°C 120' thermal rating. Electrical connections are accommodated via screw terminals with indirect clamping for conductor sections ranging from 1.50mm² to 6mm², yielding a net weight of 1.20KG. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
The Palazzoli 152160 is a 6-pole, wall-mounted isolator switch with a rated current of 16A and a CAM layout of 3.1, housed in an aluminium alloy enclosure measuring 125X185X175 mm with windowed walls. This fire-resistant 50-60Hz unit is rated for IP66/IP67, operates at a maximum ambient temperature of +60°C, and withstands 400°C for 120 minutes, featuring a non-toxic anti-UV polyester paint finish over fluorozirconic passivation. It utilizes indirect clamping screw terminals accommodating conductor sections from 1.50mm² to 6mm² with a rated insulation voltage of 690V and a net weight of 1.35KG. Submit the exact part number, quantity, and application requirements to request a quote for this component.
View product details →Palazzoli
The Palazzoli 152140 is a 16A 4P wall-mounting fire-resistant isolator switch featuring an aluminium alloy construction with windowed walls, operating at 50-60Hz with IP66/IP67 and 400°C 120' ratings. Measuring 92x125x138 mm with a net weight of 0.69 kg, the enclosure is finished in grey RAL 7035 and red RAL 3020 using fluorozirconic passivation and non-toxic anti-UV polyester paint cured in the oven. It accommodates conductor sections from 1.50 mm² to 6 mm² via screw terminals with indirect clamping, operates in ambient temperatures up to +60°C, and withstands storage temperatures up to +80°C. Submit the exact part number, quantity, and application requirements for a quote.
View product details →Palazzoli
Manufactured by Palazzoli under part number 152130, this fire-resistant wall-mounting isolator switch features a 3-pole configuration with a 16A rated current, CAM layout 2, and windowed walls housed in aluminium alloy measuring 92X125X138 mm. The enclosure is treated with fluorozirconic passivation and finished in non-toxic anti-UV oven-cured polyester paint in grey RAL 7035 and red RAL 3020, accommodating conductor sections from 1.50 mm² to 6 mm² via indirect clamping screw terminals. Operating at 50-60Hz with IP66/IP67 ingress protection, the unit withstands a maximum ambient temperature of +60°C, storage temperatures up to +80°C, and a fire resistance rating of 400°C for 120 minutes with a net weight of 0.67 KG. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Palazzoli
The Palazzoli 4P two-way switch, part number 276611, features a black anodised aluminium front plate rated IP65 and a rated current of 16A with a CAM layout of 11. Designed with a depth of 98 mm and a net weight of 0.34 kg, this component accommodates conductor sections from 1.50 mm² to 6 mm² via indirect clamping screw terminals and provides an IK08 shock resistance according to IEC/EN 62262. It operates at a rated insulation voltage of 690 V within an ambient temperature range of -25°C to +60°C and a storage range of -40°C to +80°C. Submit the exact part number, quantity, and application requirements to request a quote for this distribution board switch.
View product details →Palazzoli
The Palazzoli 3P two-way switch, part number 276610, features a 16A rated current and a black anodised aluminium front plate rated to IP65. This component includes indirect clamping screw terminals supporting conductor sections from 1.50mm² to 6mm², an IK08 shock resistance rating, and a CAM layout of 10 within an 83mm depth. Operating within an ambient temperature range of -25°C to +60°C, the unit maintains a rated insulation voltage of 690 V and a net weight of 0.27KG. Submit the exact part number, quantity, and application requirements to request a quote for this item.
View product details →Palazzoli
The Palazzoli 16A 2P two-way switch features a black anodised aluminium front plate and a CAM layout of 9 for distribution boards. This IP65 rated component provides IK08 shock resistance and accommodates conductor sections from 1.50mm² to 6mm² using indirect clamping screw terminals. Operating within an ambient temperature range of -25°C to +60°C, the unit has a rated insulation voltage of 690 V and a net weight of 0.21KG. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →Palazzoli
The Palazzoli 276608 is a 1P, 16A two-way switch featuring a black anodised aluminium front plate designed for distribution boards with an IP65 degree of protection. Built with CAM layout 8 and a depth of 52 mm, this unit accommodates conductor sections from 1.50 mm² to 6 mm² via screw terminals with indirect clamping. It delivers IK08 shock resistance according to IEC/EN 62262, a rated insulation voltage of 690 V, and operates in ambient temperatures ranging from -25°C to +60°C. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this 0.15 KG component.
View product details →
Palazzoli
Palazzoli part number 276932 is a transparent protection cap for distribution boards designed for devices with a depth of 159. This component features an IP54 protection degree, a rated current of 40/63A, a net weight of 0.51 kg, and complies with Reg. EU 2023/988 (GPSR). Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
Manufactured by Palazzoli under code 276913, these transparent protection caps are engineered for distribution boards with device depths of 145, 148, 160, and 164. The unit features an IP54 protection degree, a rated current of 16/25A, a net weight of 0.23 KG, a gross weight of 0.30 KG, and complies with Reg. EU 2023/988 (GPSR). Submit part number 276913, your required quantity, and application details to request an official quote.
View product details →Palazzoli
The Palazzoli 276912 transparent protection cap is designed for distribution boards supporting devices with a depth of 114, 116, 130, or 132. Rated at 16/25A with an IP54 protection degree, this unit weighs 0.25 KG net and complies with Reg. EU 2023/988 (GPSR). Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
Palazzoli part number 276931 is a transparent protection cap designed for distribution boards with an IP54 protection degree, compatible with devices featuring depths of 108, 110, 128, and 134. This component supports a rated current of 40 or 63A, maintains a net weight of 0.47 KG, and complies with Reg. EU 2023/988 (GPSR) standards and directives. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
Palazzoli part number 276911 is a transparent protection cap for distribution boards rated at IP54 with a net weight of 0.23 KG and gross weight of 0.30 KG. Designed for devices with depths of 79, 83, 84, 95, 96, 98, and 100 millimeters, this component operates at a rated current of 16/25A and measures 110x104x164 millimeters in height, width, and depth. It adheres to Reg. EU 2023/988 (GPSR) standards and carries EAN code 8014950204205 with a minimum order quantity of 1. Submit the exact part number, quantity, and application requirements to request a quote.
