Palazzoli
Palazzoli part number 292146 is a flush-mounting IP54 black handle featuring an aluminum front plate and transparent protection, designed for 16A deviatori control devices with 67x67 mm flange dimensions. This component has a rated current of 16/25A, a net and gross weight of 0.06 KG, and complies with Reg. EU 2023/988 (GPSR). Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
Palazzoli part number 292336 is a flush-mounting IP54 black handle assembly featuring an aluminum front plate and transparent protection, designed for control devices type INTERRUTTORI, COMMUTATORI, INV. This component accommodates a rated current of 40/63A and measures 99X99 mm in flange dimensions with a net weight of 0.16KG, adhering to Reg. EU 2023/988 (GPSR) standards and directives. Submit the exact part number, quantity, and application requirements to receive an RFQ quote.
View product details →Palazzoli
Palazzoli part number 292136 is a flush-mounting IP54 black handle featuring an aluminum front plate and transparent protection, designed for interruttori, commutatori, and inv control devices. This component has flange dimensions of 67X67 mm, a rated current of 16/25A, and a net weight of 0.05 kg while complying with Reg. EU 2023/988 (GPSR) standards and directives. Submit the exact part number, quantity, and application requirements to request a quote for this minimum order quantity of 1 unit.
View product details →Palazzoli
The Palazzoli 292316 is a black handle assembly featuring an aluminum front plate and transparent protection designed for flush-mounting control devices rated at 40/63A. This IP54-rated component includes a 99x99 mm flange and a net weight of 0.16 kg, complying with Reg. EU 2023/988 (GPSR) standards. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
Palazzoli part number 292116 is a black handle featuring an aluminum front plate and transparent protection designed for flush-mounting control devices type INTERRUTTORI 16/25A. This component has a rated current of 16/25A, flange dimensions of 67X67 mm, and an IP54 protection degree, with a net and gross weight of 0.07KG adhering to Reg. EU 2023/988 (GPSR). The minimum order quantity is 1 with EAN code 8014950205608. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Palazzoli
The Palazzoli 270900 is an adjustable spacer support kit in steel designed for fixing back panel-mounted devices with a minimum length of 97mm and a maximum length of 168mm. This component features a net weight of 0.26 kg, a gross weight of 0.27 kg, and complies with Reg. EU 2023/988 (GPSR) standards. The EAN code for this product is 8014950201549, and the minimum order quantity is 10 units. Submit the exact part number, quantity, and application requirements to receive a quote.
View product details →
Palazzoli
Engineered by Palazzoli, the 290104EX is a 4-pole, wall-mounting isolator switch fabricated from thermosetting GRP in black RAL 9005 with a 100A rated current and 690V rated operating voltage. This 50-60Hz unit features indirect clamping screw terminals accommodating conductor sections from 6mm² to 35mm², an M40 hole type, an IP66 protection degree, and a 4J shock resistance under IEC 60079-0 for use in zone 2 gas and zones 21-22 dust environments. It maintains a net weight of 3.55KG and a storage temperature range of -50°C to +80°C. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
The Palazzoli 290103EX is a 3-pole wall-mounting isolator switch constructed from black RAL 9005 thermosetting GRP with an IP66 protection degree and 4J shock resistance. Operating at 50/60Hz with a rated current of 100A, 690V rated insulation voltage, and 690V~ rated operating voltage, it accommodates conductor sections from 6mm² to 35mm² via screw indirect clamping terminals and features an M40 hole type. This unit is designed for storage room temperatures ranging from -50°C to +80°C and is rated for use in gas zone 2 and dust zones 21 and 22, with a net weight of 3.50KG and gross weight of 3.69KG under EAN code 8014950153121. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
The Palazzoli 290634EX is a 4P, 63A wall-mounting isolator switch constructed from black RAL 9005 thermosetting GRP with an IP66 protection degree and 4J shock resistance for 50-60Hz systems. Rated for 690V operating and insulation voltage, this unit accommodates conductor sections from 6mm² to 25mm² using indirect clamping screw terminals and features an M32 hole type. It operates within storage temperatures ranging from -50°C to +80°C for Zone 2 gas and Zones 21 and 22 dust hazardous areas, maintaining a net weight of 1.86KG. Submit the exact part number, quantity, and application requirements to receive a quote.
View product details →Palazzoli
The Palazzoli 290633EX is a 3-pole thermosetting GRP wall-mounting isolator switch rated for 63A and 690V~ at 50-60Hz. Manufactured in black RAL 9005 Palazzoli thermosetting GRP, this IP66-rated switch features indirect clamping screw terminals accommodating conductor sections from 6mm² to 25mm², an M32 hole type, a 4J shock resistance, and a storage temperature range of -50°C to +80°C for Zone 2 gas and Zone 21-22 dust hazardous areas. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
The Palazzoli 40A 4P wall-mounted isolator switch is manufactured from thermosetting GRP in black RAL 9005 and operates at a frequency of 50-60Hz with a rated operating and insulation voltage of 690V. Featuring an IP66 protection degree, 4J shock resistance per IEC 60079-0, M32 holes, and screw terminals with indirect clamping for conductor sections from 1mm² to 10mm², this unit functions within storage temperatures ranging from -50°C to +80°C for Zone 2 gas and Zone 21-22 dust environments. Submit the exact part number, quantity, and application requirements to request a quote for this 1.60kg switch.
View product details →Palazzoli
The Palazzoli 290403EX is a 3P, 40A wall-mounting isolator switch constructed from black RAL 9005 thermosetting GRP with an IP66 protection degree, operating at 50-60Hz with a rated insulation and operating voltage of 690V. This execution features screw-type indirect clamping terminals, an M32 hole type, a 4J shock resistance under IEC 60079-0, a minimum conductor section of 1mm², and storage temperature limits between -50°C and +80°C for Zone 2 gas and Zone 21-22 dust hazardous environments. With a net weight of 1.57KG and gross weight of 1.97KG, this unit carries EAN code 8014950153220 within the thermosetting GRP wall-mounting isolator switch family. Submit the exact part number, quantity, and application requirements for a formal quote.
View product details →Palazzoli
The Palazzoli 290324EX is a 4P, 32A wall-mounting isolator switch manufactured from thermosetting GRP in black RAL 9005 with an IP66 protection degree. Rated for 690V~ operating voltage and 690V insulation voltage at 50/60Hz, it features indirect clamping screw terminals accommodating conductor sections from 1mm² to 10mm² through an M32 hole type. This component provides 4J shock resistance under IEC 60079-0 and operates within a storage temperature range of -50°C to +80°C, weighing 1.60 kg net and 2.00 kg gross with EAN 8014950153213 for zone 2 gas and zones 21-22 dust hazardous areas. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
The Palazzoli 290323EX is a 3-pole, wall-mounting isolator switch fabricated from thermosetting GRP in black RAL 9005 with an IP66 protection degree and 4J shock resistance. Operating at 50-60Hz with a rated current of 32A and a rated insulation and operating voltage of 690V, this unit accommodates conductor sections from 1mm² to 10mm² using screw indirect clamping terminals and features an M32 hole type. Certified for zone 2 gas and zones 21-22 dust environments, the switch supports storage temperatures ranging from -50°C to +80°C and maintains a net weight of 1.57KG. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →Palazzoli
The Palazzoli 290254EX is a 4-pole thermosetting GRP wall-mounting isolator switch rated for 25A and 690V~ at 50/60Hz, featuring IP66 protection and M25 holes for Zone 2 gas and Zone 21-22 dust hazardous areas. Constructed from black RAL 9005 Palazzoli thermosetting GRP with an indirect clamping screw terminal design accommodating 1mm² to 10mm² conductors, this 1.60 kg unit withstands 4J shock resistance per IEC 60079-0 and storage temperatures from -50°C to +80°C. Submit the exact part number, quantity, and application requirements for a formal quote.
View product details →Palazzoli
The Palazzoli 290253EX is a wall-mounted 3P isolator switch featuring a thermosetting GRP construction in black RAL 9005 with an IP66 protection degree and 4J shock resistance. Operating at 50/60Hz with a rated current of 25A and a rated insulation voltage of 690V, this unit accommodates conductor sections from 1mm² to 10mm² using screw indirect clamping terminals and includes an M25 hole type. Designed for zone 2 gas and zones 21-22 dust hazardous areas, the device maintains a storage temperature range of -50°C to +80°C and weighs 1.57KG net. Submit the exact part number, quantity, and application requirements to request a quote for this item.
View product details →Palazzoli
The Palazzoli 290252EX is a 2P, 25A wall-mounting isolator switch fabricated from black RAL 9005 thermosetting GRP for use in 50-60Hz systems with an IP66 protection degree. Rated for 690V~ operational and 690V insulation voltage, this hazardous area switch accommodates conductor sections from 1mm² to 10mm² using indirect clamping screw terminals and features an M25 hole type with 4J shock resistance under IEC 60079-0. Designed for Zone 2 gas and Zones 21 and 22 dust environments, the unit weighs 1.55 kg net and operates within storage temperatures ranging from -50°C to +80°C. Submit the exact part number, quantity, and application requirements for a formal quote.
View product details →Palazzoli
The Palazzoli 290164EX is a wall-mounted 4P isolator switch composed of thermosetting GRP in black RAL 9005 with an IP66 protection degree and 4J shock resistance. Operating at 50/60Hz with a rated insulation and operating voltage of 690V, this 16A unit features M25 holes, indirect clamping screw terminals accommodating conductor sections from 1mm² to 10mm², and a storage room temperature range of -50°C to +80°C. With a net weight of 1.60KG and gross weight of 1.79KG, this device is rated for zone 2 gas and zones 21-22 dust hazardous environments. Submit the exact part number, quantity, and application requirements for an RFQ quote.
View product details →Palazzoli
The Palazzoli 290163EX is a 3-pole wall-mounting isolator switch manufactured from thermosetting GRP in a black RAL 9005 finish, featuring a 16A rated current, 690V rated insulation voltage, and 690V~ rated operating voltage at 50-60Hz. Designed for Zone 2 gas and Zone 21-22 dust hazardous areas, this IP66-rated unit incorporates M25 hole types, indirect clamping screw terminals for a minimum conductor section of 1mm², and 4J shock resistance per IEC 60079-0, with a net weight of 1.57KG and storage temperature tolerances between -50°C and +80°C. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this Palazzoli component.
View product details →Palazzoli
The Palazzoli 290162EX is a 2-pole wall-mounting isolator switch constructed from black RAL 9005 thermosetting GRP with a net weight of 1.55 kg and an IP66 protection degree. Operating at 50/60Hz, this 16A switch handles a rated operating and insulation voltage of 690V, accommodating conductor sections from 1 mm² to 10 mm² via indirect clamping screw terminals. Rated for zone 2 gas and zones 21 and 22 dust hazardous areas, the unit features M25 knockouts, a 4J shock resistance under IEC 60079-0, and a storage temperature range of -50°C to +80°C. Submit the exact part number, quantity, and application requirements to request a quote.
