Murata
SCR2200-D13
Murata SCR2200-D13 — Inertial Sensors
The Murata SCR2200-D13 is a 1-axis gyro IC featuring a measuring range of ±125°/s and a sensitivity of 50 LSB/(°/sec). This device operates at a supply voltage of 3,0 to 3,6 VDC, delivering an in-band quiescent noise of 0,12 °/s rms, a bias over temperature of ± 1,3 °/s, and selectable bandwidths of 10 Hz and 60 Hz. Submit the exact part number, quantity, and application requirements to receive a quote for this component.
Request pricing and availabilityCommercial response for your destination and required quantity.
Request a Quote- Manufacturer
- Murata
- Part number
- SCR2200-D13
- Product series
- SCR2200-D13
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to SCR2200-D13.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Product Name
- SCR2200-D13
- Product Category
- Inertial Sensors
- Design
- IC
- Device type
- Gyro
- No. of axes
- 1
- Angular range [±°/s]
- 125
- Measuring range
- 125°/s
- Sensitivity
- 50 LSB/(°/sec)
- In-Band quiescent noise
- 0,12 °/s rms
- Bias over temperature
- ± 1,3 °/s
- Bandwidth
- 10 Hz, 60 Hz
- Supply voltage [VDC]
- 3,0 to 3,6
- Supplier
- Murata
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Murata SCR2200-D13. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
