G3PF-525B-24VDC

Name: Omron G3PF-525B-24VDC G3PF
Brand: Omron

Omron G3PF-525B-24VDC G3PF

The Omron G3PF-525B-24VDC is a G3PF product family component featuring ON/OFF control across 1 phase, utilizing a DIN rail mounting method with screw terminals and a screw socket. It operates within an AC voltage range of 200 to 480 V (rated operational voltage AC 180-528 V), a DC supply voltage of 9.6-26.4 V, a maximum control current of 10 mA, a must-operate voltage maximum of 9.6 V, and a must-release voltage minimum of 1 V. The unpacked unit measures 100 mm in height, 45 mm in width, and 110 mm in depth, with a rated operation current Ie at AC-1 of 25 A and an operating temperature range of -20 °C to 60 °C. Submit the exact part number, quantity, and application requirements to receive a quote.

Request pricing and availabilityCommercial response within one business day for your destination and required quantity.

Request a Quote

Why no listed price?

Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Omron references — within one business day.

Manufacturer: Omron
Part number: G3PF-525B-24VDC
Product series: G3PF
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to G3PF-525B-24VDC.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationA document is added when the reviewed source provides one.

Verified configuration

Technical Specifications

Product Family: G3PF
Application: G3PF-525B DC24
Number of phases: ON/OFF control
Mounting method: 1
Terminal type: DIN rail/screw
Complete with socket: Screw
LED indicator: No
Rated operational voltage, AC: Yes
Operating voltage range, AC: 200-480 V
Rated operation current Ie at AC-1: 180-528 V
Product Height (unpacked): 25 A
Product Width (unpacked): 100 mm
Product Depth (unpacked): 45 mm
Supply voltage DC: 110 mm
Control current max.: 9.6-26.4 V
Must operate voltage max.: 10 mA
Must release voltage min.: 9.6 V
Maximum operating temperature: 1 V
Minimum operating temperature: 60 °C
Isolation: -20 °C
Switching at zero-crossing: Phototriac
Functions: Yes

Engineering context

Identification and RFQ Guidance

Confirm the exact configuration

Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.

What to include in your RFQ

Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.

Technical verification

Our sourcing response is prepared against Omron G3PF-525B-24VDC. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
