Industrial sourcing catalog
Browse verified product records and request commercial availability, lead time and technical documentation.
Omron
The Omron G2R2SNDI24VDC is an industrial component identified by GTIN 4050571312220. Submit the exact part number, quantity, and application requirements for a quote on this Omron product.
View product details →
Omron
The Omron G2R2SND24VDC is an industrial component bearing GTIN 4050571312213. Submit the exact part number, quantity, and application requirements to request a quote for this Omron product.
View product details →
Omron
This Omron industrial component, part number G2R1SNDI24VDC, features the GTIN-13 4050571312152. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Omron
The Omron G2R1SN24VDC is an industrial component identified by GTIN 4050571312138. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Omron
Source the Omron industrial component, part number G2R2SN230VAC, identified by GTIN 4050571312190. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Omron
Source the Omron SHLW255 industrial component with GTIN 4050571625788 directly from verified manufacturer inventory. Submit your exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Omron
The Omron S8VK-G48048 is a single-phase, DIN-rail mounted power supply delivering an output voltage of 48 V and a power output of 480 W at a rated output current of 10 A. This unit operates across a rated AC supply voltage of 100-240 V (50 Hz), with allowable supply ranges of 85-264 V AC and 90-350 V DC, maintaining an efficiency of 93 % within a temperature range of -40 to 70 °C. Measuring 95 mm wide, 125 mm high, and 140 mm deep, the hardware features screw terminals, a 120 % power boost ratio, one output branch, and no communication ports or alarm functions. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this Omron component.
View product details →Omron
The Omron S8VK-G48024 is a single-phase, DIN-rail mounted power supply delivering a 24 V output voltage and a 480 W power output at a 20 A rated output current. Featuring a 93 % efficiency and a 120 % power boost ratio, this unit operates across a temperature range of -40 to 70 °C with an allowable AC supply voltage of 85-264 V and DC supply voltage of 90-350 V. Measuring 95 mm wide, 125 mm high, and 140 mm deep, it is equipped with screw terminals and lacks communication ports. Submit the exact part number, quantity, and application requirements to receive a quote.
View product details →Omron
The Omron S8VK-G24048 is a single-phase DIN-rail power supply delivering a 48 V output voltage at 240 W and a rated output current of 5 A with a 120 % power boost ratio. Featuring a 92 % efficiency rating, this unit operates within a temperature range of -40 to 70 °C and accepts a rated supply voltage of 100-240 V AC at 50 Hz, with allowable supply ranges of 85-264 V AC and 90-350 V DC. It is equipped with screw terminals, one output branch, and no communication ports, measuring 60 mm in width, 125 mm in height, and 140 mm in depth. Submit the exact part number, quantity, and application requirements to request a quote for this component.
View product details →Omron
The Omron S8VK-G24024 is a single-phase DIN-rail mounted power supply delivering a 24 V output voltage, 240 W power output, and a 10 A rated output current with a 120 % power boost ratio. Measuring 60 mm wide, 125 mm high, and 140 mm deep, this 92 % efficient unit operates within a temperature range of -40 to 70 °C and accepts an allowable supply voltage of 85 to 264 VAC or 90 to 350 VDC from a rated supply voltage of 100 to 240 VAC at 50 Hz. It features screw terminals and one output branch without communication ports or an alarm function. Submit the exact part number, quantity, and application requirements for a quote.
View product details →Omron
The Omron S8VK-G12024 is a single-phase DIN-rail mount power supply delivering a 24 V output voltage at a 5 A rated output current and 120 W power output. This unit operates within a temperature range of -40 to 70 °C, features an 89 % efficiency rating with a 120 % power boost ratio, and utilizes screw terminals across dimensions of 40 mm width, 125 mm height, and 113 mm depth. Powered by a rated supply voltage of 100-240 V AC at 50 Hz with allowable supply voltage ranges of 85-264 V AC and 90-350 V DC, the device includes one output branch without communication ports or alarm functions. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this component.
View product details →Omron
The Omron S8VK-G06024 is a single-phase DIN-rail power supply delivering 24 V output voltage at a 60 W power output and 2.5 A rated output current. Featuring a 120% power boost ratio, 88% efficiency, and screw terminals, this unit operates within a -40 to 70 °C temperature range and accepts a rated supply voltage of 100-240 V AC at 50 Hz, with allowable supply voltages of 85-264 V AC and 90-350 V DC. Measuring 32 mm in width, 90 mm in height, and 110 mm in depth, this Omron component has one output branch and no communication ports. Submit the exact part number, quantity, and application requirements for a quote.
View product details →Omron
The Omron S8VK-G06012 is a single-phase, 60 W DIN-rail power supply providing a 12 V output voltage and a 4.5 A rated output current with a 120% power boost ratio. This unit operates across a rated AC supply voltage of 100-240 V, an allowable AC range of 85-264 V, and a DC range of 90-350 V, achieving 85% efficiency within a -40 to 70 °C temperature range. Housed in an unpacked width of 32 mm, height of 90 mm, and depth of 110 mm, it features screw terminals and a single output branch without communication ports. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this component.
View product details →Omron
The Omron S8VK-G03024 is a single-phase DIN-rail power supply providing a 24 V output voltage, a 30 W power output, and a 1.3 A rated output current with an 86 % efficiency and a 120 % power boost ratio. This unit operates on a rated supply voltage of 100-240 V at AC 50 Hz, with allowable supply voltage ranges of 85-264 V AC and 90-350 V DC, within a temperature range of -40-70 °C. Featuring screw terminals and measuring 32 mm in width, 90 mm in height, and 90 mm in depth, this model includes no communication ports or alarm functions across its single output branch. Submit the exact part number, quantity, and application requirements to request a quote for this component.
View product details →Omron
The Omron S8VK-G03012 is a single-phase DIN-rail power supply providing a 12 V output voltage and a 30 W power output with a rated output current of 2.5 A and an 82 % efficiency. This unit operates across a rated AC supply voltage of 100-240 V, with allowable supply voltage ranges of 85-264 V AC and 90-350 V DC, featuring a 120 % power boost ratio and a temperature range of -40 to 70 °C. Housed in a 32 mm wide, 90 mm high, and 90 mm deep enclosure, the device includes screw terminals and a single output branch with no communication ports. Submit the exact part number, quantity, and application requirements for a formal quote.
View product details →Omron
The Omron S8VK-G03005 is a single-phase DIN-rail power supply delivering 30 W of power output at a 5 V rated output current of 5 A. This unit operates on a rated supply voltage of 100-240 V AC at 50 Hz, with allowable supply voltage ranges of 85-264 V AC and 90-350 V DC, featuring a 79 % efficiency and a 120 % power boost ratio. Housed in a screw terminal configuration measuring 32 mm in width, 90 mm in height, and 90 mm in depth, it functions within a temperature range of -40 to 70 °C. Submit the exact part number, quantity, and application requirements to request a quote for this component.
View product details →Omron
The Omron S8VK-G01524 is a single-phase DIN-rail power supply providing a 24 V output voltage, 15 W power output, and 0.65 A rated output current with an 80% efficiency rating. This component features screw terminals, a 120% power boost ratio, a 22.5 mm width, a 90 mm height, a 90 mm depth, and a wide operating temperature range of -40 to 70 °C. It accepts a rated supply voltage of 100-240 VAC at 50 Hz, with allowable supply voltage ranges of 85-264 VAC and 90-350 VDC. Submit the exact part number, quantity, and application requirements for a quote.
View product details →Omron
The Omron S8VK-G01512 is a single-phase DIN-rail power supply delivering a 12 V output voltage at 1.2 A and 15 W power output with a 120 % power boost ratio. This unit operates on a rated supply voltage of 100-240 V AC at 50 Hz, with allowable supply ranges of 85-264 V AC and 90-350 V DC, achieving 77 % efficiency across a -40-70 °C temperature range. Featuring screw terminals, a single output branch, and un-packed dimensions of 22.5 mm width, 90 mm height, and 90 mm depth, the device lacks communication ports and alarm functions. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Omron
The Omron S8VK-G01505 is a single-phase DIN-rail power supply delivering a 5 V output voltage, 15 W power output, and 3 A rated output current with a 120 % power boost ratio. This unit operates across an AC supply voltage of 100-240 V (allowable AC 85-264 V, allowable DC 90-350 V), features screw terminals, and operates within a temperature range of -40 to 70 °C with 77 % efficiency. Measuring 22.5 mm wide, 90 mm high, and 90 mm deep, this single-branch device lacks communication ports and alarm functions. Submit the exact part number, quantity, and application requirements to receive a formal quote.
View product details →
Omron
The Omron S8VK-C48024 is a single-phase DIN-rail mounted power supply delivering a 24 V output voltage at a 480 W power output and 20 A rated output current. This S8VK-C unit operates within a temperature range of -25 to 60 °C, features screw terminals, and achieves 92 % efficiency with an AC supply voltage rating of 100-240 V at 50 Hz, alongside allowable supply voltages of 85-264 V AC and 90-350 V DC. Measuring 95 mm in width, 125 mm in height, and 140 mm in depth, the device includes no communication ports or alarm functions across its single output branch. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
