Omron
J7TC-01-E72
Omron J7TC-01-E72 J7TC
The Omron J7TC-01-E72 is a J7TC product featuring a 0.48-0.72 A direct-on-line and star-delta setting range equipped with 1 normally open and 1 normally closed auxiliary contact. This unit utilizes Push-in Plus terminal technology and measures 45 mm in width, 97.5 mm in height, and 55.5 mm in depth unpacked. Submit the exact part number, quantity, and application requirements to receive a formal price quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Omron references — within one business day.
- Manufacturer
- Omron
- Part number
- J7TC-01-E72
- Product series
- J7TC
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to J7TC-01-E72.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Product Family
- J7TC
- Auxiliary Contacts NO
- 1
- Auxiliary Contacts NC
- 1
- Setting range D.O.L. (A)
- 0.48-0.72 A
- Setting range Star-delta [A]
- 0.48-0.72 A
- Terminal type
- Push-in Plus
- Product Width (unpacked)
- 45 mm
- Product Height (unpacked)
- 97.5 mm
- Product Depth (unpacked)
- 55.5 mm
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Omron J7TC-01-E72. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
