NX102-1100

Name: Omron NX102-1100 NX1-SERIES
Brand: Omron

Omron NX102-1100 NX1-SERIES

The Omron NX102-1100 is an NX1-series machine automation controller that features a 1 ms primary task cycle time, 5 MB of program memory, and 33.5 MB of variables memory. This controller supports sequence, position, and motion control for a maximum of 4 point-to-point axes and 4 synchronous axes, alongside up to 64 remote I/O nodes. Communication capabilities include EtherCAT Master, EtherNet/IP, Ethernet TCP/IP, and OPC-UA, while database connections are not supported. Submit the exact part number, quantity, and application requirements for a formal quotation.

Request pricing and availabilityCommercial response within one business day for your destination and required quantity.

Request a Quote

Why no listed price?

Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Omron references — within one business day.

Manufacturer: Omron
Part number: NX102-1100
Product series: NX1-SERIES
Data verification: Manufacturer evidence reviewed

For a faster response, include quantity, condition, and delivery destination.

Exact part-number verificationTechnical properties are matched to NX102-1100.

Worldwide sourcingSupport for planned and urgent industrial requirements.

Manufacturer documentationA document is added when the reviewed source provides one.

Verified configuration

Technical Specifications

Product Family: NX1-SERIES
Supports motion control: Yes
Supports DB connection: No
Primary task cycle time: 1 ms
Program memory: 5 MB
Variables memory: 33.5 MB
Max. number of PTP axes: 4
Max. number of synchronous axes: 4
Communication port(s): EtherCAT Master, EtherNet/IP, Ethernet TCP/IP
Max. number of remote I/O nodes: 64
Supports sequence control: Yes
Supports position control: Yes
Supports OPC-UA: Yes

Engineering context

Identification and RFQ Guidance

Confirm the exact configuration

Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.

What to include in your RFQ

Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.

Technical verification

Our sourcing response is prepared against Omron NX102-1100. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
