Omron
NX701-1620
Omron NX701-1620 NX7-SERIES
The Omron NX701-1620 is an NX7-series controller supporting up to 128 synchronous axes with a primary task cycle time of 0.125 ms. It features 80 MB of program memory, 260 MB of variables memory, and supports sequence control, motion control, database connection, and OPC-UA without AI control. Equipped with EtherCAT Master, EtherNet/IP, and Ethernet TCP/IP communication ports, this unit accommodates a maximum of 512 remote I/O nodes. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Omron references — within one business day.
- Manufacturer
- Omron
- Part number
- NX701-1620
- Product series
- NX7-SERIES
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to NX701-1620.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Product Family
- NX7-SERIES
- Max. number of synchronous axes
- 128
- Supports DB connection
- Yes
- Supports OPC-UA
- Yes
- Supports AI control
- No
- Primary task cycle time
- 0.125 ms
- Program memory
- 80 MB
- Variables memory
- 260 MB
- Communication port(s)
- EtherCAT Master, EtherNet/IP, Ethernet TCP/IP
- Max. number of remote I/O nodes
- 512
- Supports sequence control
- Yes
- Supports motion control
- Yes
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Omron NX701-1620. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
