Confirm the exact configuration
Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.
Global industrial sourcing · Houston, Texas info@mropartsrfq.com
Reference imageConfirm configuration by manufacturer part number.
Omron
S8VK-G03012
Omron S8VK-G03012 S8VK-G
The Omron S8VK-G03012 is a single-phase DIN-rail power supply providing a 12 V output voltage and a 30 W power output with a rated output current of 2.5 A and an 82 % efficiency. This unit operates across a rated AC supply voltage of 100-240 V, with allowable supply voltage ranges of 85-264 V AC and 90-350 V DC, featuring a 120 % power boost ratio and a temperature range of -40 to 70 °C. Housed in a 32 mm wide, 90 mm high, and 90 mm deep enclosure, the device includes screw terminals and a single output branch with no communication ports. Submit the exact part number, quantity, and application requirements for a formal quote.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued Omron references — within one business day.
- Manufacturer
- Omron
- Part number
- S8VK-G03012
- Product series
- S8VK-G
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to S8VK-G03012.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Product Family
- S8VK-G
- Type
- DIN-rail
- Mounting method
- DIN rail
- Phase
- Single
- Output voltage
- 12 V
- Power output
- 30 W
- Rated output current
- 2.5 A
- Power boost ratio
- 120 %
- Temperature range
- -40-70 °C
- Terminal type
- Screw
- Communication port(s)
- None
- Alarm function
- -
- Number of output branches
- 1
- Efficiency
- 82 %
- Rated supply voltage at AC 50 Hz
- 100-240 V
- Allowable supply voltage AC
- 85-264 V
- Allowable supply voltage DC
- 90-350 V
- Product Width (unpacked)
- 32 mm
- Product Height (unpacked)
- 90 mm
- Product Depth (unpacked)
- 90 mm
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against Omron S8VK-G03012. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
