Omron
NX-HAD402
Omron NX-HAD402 NX-SERIES
The Omron NX-HAD402 is an NX-series analog input module featuring 4 differential linear analog inputs with a 16-bit resolution. It delivers a conversion time of 0.02 ms/unit and supports high-speed, synchronous signal processing across multiple voltage and current ranges including -10 to 10 V, 0 to 20 mA, and 4 to 20 mA. This component utilizes a push-in I/O connection type and is not suitable for safety functions. Submit the exact part number, quantity, and application requirements to receive a quote.
View product details →Omron
NX-ECT101
Omron NX-ECT101 NX-SERIES
The Omron NX-ECT101 is an NX-Series communication module featuring two EtherCAT Slave communication ports. This unit utilizes free running signal processing and does not support safety functions. Submit the exact part number, quantity, and application requirements for a quote.
View product details →Omron
NX-ECS212
Omron NX-ECS212 NX-SERIES
The Omron NX-ECS212 is an NX-Series encoder input module featuring two SSI encoder input channels with a maximum input frequency of 2000 kHz and signal processing capabilities for both free running and synchronous operation. This unit includes no pulse output channels and is not suitable for safety functions. External connectivity is established via push-in I/O connections alongside two IOV (V+) terminals and two IOG (V-) terminals. To receive pricing and availability, submit your exact part number, quantity, and application requirements for a formal quote.
View product details →Omron
NX-ECS112
Omron NX-ECS112 NX-SERIES
The Omron NX-ECS112 is an NX-Series encoder input module featuring 1 SSI encoder input channel and 0 pulse output channels. This unit supports a maximum encoder input frequency of 2000 kHz, 0 kHz max pulse output frequency, and provides free running or synchronous signal processing with no safety function suitability. Equipped with push-in I/O connections, 2 IOV (V+) terminals, and 2 IOG (V-) terminals, the module contains no digital outputs. Submit your exact part number, quantity, and application requirements to receive a formal quotation for this Omron component.
View product details →Omron
NX-EC0222
Omron NX-EC0222 NX-SERIES
The Omron NX-EC0222 is an NX-Series encoder input module featuring two incremental encoder channels with PNP digital input type and push-in I/O connections. This unit processes signals through free running, synchronous, or task period prioritized modes up to a maximum encoder input frequency of 500 kHz, while including two IOV and two IOG terminals without pulse output channels or safety function suitability. Request a quote for this exact part number by submitting your required quantity and application specifications.
View product details →Omron
NX-EC0212
Omron NX-EC0212 NX-SERIES
The Omron NX-EC0212 is an NX-Series encoder input module featuring 2 incremental encoder channels with NPN digital input types and no digital output channels. This component supports a maximum encoder input frequency of 500 kHz alongside 2 IOV (V+) terminals and 2 IOG (V-) terminals via push-in I/O connections. Signal processing operations are handled through free running, synchronous, and task period prioritized modes without safety function suitability. Submit the exact part number, quantity, and application requirements to receive a quote for this module.
View product details →Omron
NX-EC0132
Omron NX-EC0132 NX-SERIES
The Omron NX-EC0132 is an NX-Series encoder input module featuring one incremental encoder input channel with support for Line driver (RS-422) and NPN digital input types, and zero pulse output channels. This component accommodates a maximum encoder input frequency of 4000 kHz, provides signal processing via free running, synchronous, or task period prioritized modes, and includes three IOV (V+) terminals alongside three IOG (V-) terminals with push-in I/O connections. It does not support safety functions. Submit the exact part number, quantity, and application requirements for a quote.
View product details →Omron
NX-EC0122
Omron NX-EC0122 NX-SERIES
The Omron NX-EC0122 is an NX-Series encoder input module featuring 1 incremental encoder input channel with a PNP digital input type and a maximum encoder input frequency of 500 kHz. This component includes 0 pulse output channels, 4 IOV (V+) terminals, 4 IOG (V-) terminals, and utilizes a push-in I/O connection type without safety functions. Signal processing operates via free running, synchronous, or task period prioritized modes. Submit the exact part number, quantity, and application requirements to receive a quote.
View product details →Omron
NX-EC0112
Omron NX-EC0112 NX-SERIES
The Omron NX-EC0112 is an NX-Series encoder input module featuring one incremental encoder channel with NPN digital input and a maximum input frequency of 500 kHz. This module utilizes a push-in I/O connection type alongside four IOV (V+) terminals and four IOG (V-) terminals, excluding any pulse output channels. Signal processing is configurable via free running, synchronous, or task period prioritized modes without safety function suitability. Submit the exact part number, quantity, and application requirements for a quote.
View product details →Omron
NX-DA3605
Omron NX-DA3605 NX-SERIES
The Omron NX-DA3605 is an NX-Series analog output module featuring four linear analog outputs with a range of -15 to 15 V (specifically -10 to 10 V). This unit delivers synchronous signal processing with a conversion time of 0.04 ms/unit and a 15-bit analog output resolution through a push-in I/O connection type. It contains zero analog inputs, no linear analog or temperature input types, and is not suitable for safety functions. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →Omron
NX-DA3603
Omron NX-DA3603 NX-SERIES
The Omron NX-DA3603 is an NX-Series analog I/O module featuring four analog outputs with a linear output range of -13 to 10 V and a 13-bit resolution. This unit operates without analog inputs, linear analog input types, temperature input types, input circuits, or safety functions. Featuring a free-running signal processing method with a conversion time of 1 ms per unit, the module utilizes a push-in I/O connection type. Submit the exact part number, quantity, and application requirements for a quote today.
View product details →Omron
NX-DA3205
Omron NX-DA3205 NX-SERIES
The Omron NX-DA3205 is an NX-Series analog output module featuring four linear analog outputs supporting a 4 to 20 mA signal range and a 15-bit resolution. This unit operates with a conversion time of 0.04 ms per unit and utilizes synchronous signal processing through a push-in I/O connection type. It does not include analog inputs, temperature inputs, or safety functions. Submit the exact part number, quantity, and application requirements for a quote.
View product details →Omron
NX-DA3203
Omron NX-DA3203 NX-SERIES
The Omron NX-DA3203 is an NX-Series analog output module featuring four linear analog outputs ranging from 4 to 20 mA with a 13-bit resolution. This unit provides a conversion time of 1 ms per unit utilizing free-running signal processing and includes push-in I/O connections without any analog inputs or safety functions. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →Omron
NX-DA2605
Omron NX-DA2605 NX-SERIES
The Omron NX-DA2605 is an NX-Series analog output module featuring 2 analog outputs with a 15-bit resolution and a linear analog output range of -10 to 10 V. This unit operates without analog inputs, temperature inputs, linear analog inputs, or safety functions, utilizing a synchronous signal processing method with a conversion time of 0.02 ms/unit. Connections are established via a push-in I/O connection type. Submit the exact part number, quantity, and application requirements for an RFQ.
View product details →Omron
NX-DA2603
Omron NX-DA2603 NX-SERIES
The Omron NX-DA2603 is an NX-Series analog output module featuring two linear analog outputs with a voltage range of -13 to 10 V and a 13-bit resolution. This component operates with a conversion time of 0.5 ms per unit utilizing free-running signal processing and a push-in I/O connection type. It contains no analog inputs, temperature inputs, or linear analog input types and is not suitable for safety functions. Submit the exact part number, quantity, and application requirements for a quote.
View product details →Omron
NX-DA2205
Omron NX-DA2205 NX-SERIES
The Omron NX-DA2205 is an NX-Series analog I/O module featuring two analog outputs with a 15-bit resolution and a 4 to 20 mA linear analog output type. This synchronous unit provides a conversion time of 0.02 ms/unit and utilizes a push-in I/O connection type with zero analog inputs. Submit the exact part number, quantity, and application requirements to receive a formal quote.
View product details →Omron
NX-DA2203
Omron NX-DA2203 NX-SERIES
The Omron NX-DA2203 is an NX-Series analog output module featuring two analog outputs with a 13-bit resolution and a 4 to 20 mA linear analog output type. This unit operates with a conversion time of 0.5 ms per unit, utilizes free-running signal processing, and connects via a push-in I/O connection type without supporting safety functions, linear analog inputs, or temperature inputs. Submit the exact part number, quantity, and application requirements for an RFQ quote.
View product details →Omron
NX-CT2420
Omron NX-CT2420 NX-SERIES
The Omron NX-CT2420 is an NX-series encoder input module featuring 2 incremental encoder input channels with RS-422 line driver and PNP support, alongside 6 pulse input channels and 1 pulse output channel. This component handles a maximum encoder input frequency of 4000 kHz, utilizes push-in I/O connections with two IOV (V+) terminals, and processes signals via free running, synchronous, or task period prioritized modes without safety functions. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this unit.
View product details →Omron
NX-CT2320
Omron NX-CT2320 NX-SERIES
The Omron NX-CT2320 is an NX-series encoder input module featuring 2 incremental encoder and line driver or NPN digital input channels with a maximum frequency of 4000 kHz. This unit includes 6 pulse input channels, 1 pulse output channel with a 0 kHz maximum frequency, and NPN or PWM digital output types. Configured with push-in I/O connections, 2 IOG terminals, and 0 IOV terminals, it supports free running, synchronous, and task period prioritized signal processing without safety functions. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this component.
View product details →Omron
NX-CT2220
Omron NX-CT2220 NX-SERIES
The Omron NX-CT2220 is an NX-series encoder input module featuring 2 incremental encoder input channels, 6 pulse input channels, and 1 pulse output channel supporting PNP and voltage pulse digital input types alongside PNP and PWM digital output types. This component accommodates a maximum encoder input frequency of 1000 kHz, features push-in I/O connections, and provides 2 IOV (V+) terminals with 0 IOG (V-) terminals. Signal processing functions via free running, synchronous, or task period prioritized modes while operating without safety functions. Submit the exact part number, quantity, and application requirements for an RFQ quote.
