Festo
1776047
ISO cylinder DSBF-C-63-100-PPVA-N3-R
The Festo 1776047 is a double-acting industrial component featuring a 63 mm piston diameter, a 100 mm stroke, and an M16x1.5 piston rod thread with an external end. Operating within a pressure range of 0.04 MPa to 1.2 MPa, this ISO 15552 conforming unit incorporates adjustable pneumatic cushioning at both ends with a 22 mm cushioning length and 1.3 J impact energy. Designed with a profile barrel, piston, and piston rod, it achieves theoretical forces of 1870 N advancing and 1682 N retracting at 6 bar using compressed air per ISO 8573-1:2010 [7:4:4]. Submit the exact part number, quantity, and application requirements for a formal quotation.
View product details →
Festo
1776046
ISO cylinder DSBF-C-63-80-PPVA-N3-R
The Festo 1776046 is a double-acting industrial component featuring a 63 mm piston diameter, an 80 mm stroke, and an M16x1.5 piston rod thread with an external thread end. Built with a piston, piston rod, and profile barrel structural design conforming to ISO 15552, it operates within a pressure range of 0.04 MPa to 1.2 MPa utilizing compressed air as per ISO 8573-1:2010 [7:4:4]. This unit includes adjustable pneumatic cushioning at both ends, a 22 mm cushioning length, position sensing via proximity switch, and a corrosion resistance class of 3 for high corrosion stress. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
1776045
ISO cylinder DSBF-C-63-50-PPVA-N3-R
The Festo 1776045 is a double-acting industrial component featuring a 63 mm piston diameter, a 50 mm stroke, and an M16x1.5 piston rod thread with an external end. Conforming to ISO 15552, this profile barrel unit operates within a pressure range of 0.04 MPa to 1.2 MPa and includes adjustable pneumatic cushioning at both ends with a 22 mm cushioning length. Built with a corrosion resistance class of 3 for high corrosion stress, it operates across an ambient temperature range of -20 °C to 80 °C using compressed air as per ISO 8573-1:2010 [7:4:4]. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
1776044
ISO cylinder DSBF-C-63-40-PPVA-N3-R
The Festo 1776044 is a double-acting industrial component featuring a 63 mm piston diameter, a 40 mm stroke, and an M16x1.5 external piston rod thread conforming to ISO 15552. Designed with a profile barrel, piston, and piston rod, this unit operates within a 0.4 bar to 12 bar pressure range using compressed air as per ISO 8573-1:2010 [7:4:4] and includes adjustable pneumatic cushioning at both ends with a 22 mm cushioning length. It delivers theoretical forces of 1870 N advancing and 1682 N retracting at 6 bar while providing position sensing via proximity switch and a high corrosion stress resistance class (CRC 3). Submit the exact part number, quantity, and application requirements to request a quote for this component.
View product details →
Festo
1776043
ISO cylinder DSBF-C-63-25-PPVA-N3-R
The Festo 1776043 is a double-acting industrial component featuring a 63 mm piston diameter, a 25 mm stroke, and an M16x1.5 piston rod thread with an external end. Built with a profile barrel structural design conforming to ISO 15552, it operates at pressures from 0.04 MPa to 1.2 MPa and includes adjustable pneumatic cushioning at both ends with a 22 mm cushioning length. This unit provides position sensing via a proximity switch, delivers a theoretical force of 1870 N advancing and 1682 N retracting at 6 bar, and is rated for a corrosion resistance class of 3 under ambient temperatures from -20 °C to 80 °C. Submit the exact part number, quantity, and application requirements to receive a formal quote.
View product details →
Festo
1778845
ISO cylinder DSBF-C-32-500-PPSA-N3-R
The Festo 1778845 is a double-acting industrial component featuring a 32 mm piston diameter, a 500 mm stroke, and an M10x1.25 external piston rod thread conforming to ISO 15552. Built with a piston, piston rod, and profile barrel structural design, this unit operates at pressures from 0.06 MPa to 1.2 MPa utilizing compressed air as per ISO 8573-1:2010 [7:4:4] with self-adjusting pneumatic end-position cushioning. It achieves a theoretical retraction force of 415 N at 6 bar, offers Class 5 cleanroom suitability according to ISO 14644-1, and possesses a CRC 3 high corrosion stress rating for ambient temperatures between -20 °C and 80 °C. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
177603
Installation kit HMZAS-PG-29
The Festo installation kit HMZAS-PG-29 is an industrial component featuring any mounting position and a corrosion resistance class (CRC) rating of 2 for moderate corrosion stress. This assembly complies with VDMA24364-B2-L LABS (PWIS) conformity requirements as detailed in the official Festo EN-US data sheet. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this hardware.
View product details →
Festo
177600
Lock nut MKM-PG-29
The Festo lock nut MKM-PG-29 is an industrial component featuring a PG 29 size and an installation mounting position of any orientation. This hardware carries a corrosion resistance class of CRC 2 for moderate corrosion stress along with VDMA24364-B2-L LABS conformity. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
1778844
ISO cylinder DSBF-C-32-400-PPSA-N3-R
The Festo part number 1778844 is a double-acting industrial component featuring a 32 mm piston diameter, a 400 mm stroke, and an M10x1.25 external piston rod thread conforming to ISO 15552. This profile barrel unit operates within a pressure range of 0.06 MPa to 1.2 MPa using compressed air according to ISO 8573-1:2010 [7:4:4], delivering a theoretical retracting force of 415 N at 6 bar. Equipped with self-adjusting pneumatic end-position cushioning, position sensing via proximity switch, and ISO 14644-1 Class 5 cleanroom suitability, the assembly achieves a CRC 3 high corrosion resistance rating for ambient temperatures between -20 °C and 80 °C. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
177599
Lock nut MKM-PG-21
The Festo lock nut MKM-PG-21 is an industrial component featuring a PG 21 size and an installation mounting position of any orientation. This hardware carries a corrosion resistance class of CRC 2 for moderate corrosion stress alongside VDMA24364-B2-L LABS conformity. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
1778843
ISO cylinder DSBF-C-32-320-PPSA-N3-R
The Festo 1778843 is a double-acting industrial component featuring a 32 mm piston diameter, a 320 mm stroke, and an M10x1.25 external piston rod thread conforming to ISO 15552. Constructed with a profile barrel, piston, and piston rod, this unit operates at pressures from 0.06 MPa to 1.2 MPa utilizing compressed air per ISO 8573-1:2010 [7:4:4] and incorporates self-adjusting pneumatic end-position cushioning. It achieves a corrosion resistance class of 3, meets ISO 14644-1 cleanroom Class 5 standards, and delivers a theoretical retracting force of 415 N at 6 bar while accommodating ambient temperatures between -20 °C and 80 °C. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
1780430
Motor flange EAMF-A-44A-60G/H
The Festo part number 1780430 is an industrial component weighing 178 g with VDMA24364-B2-L LABS conformity and RoHS compliant materials. It features motor input interface codes 60G and 60H alongside a coupling housing interface code of 44A, while supporting any mounting position. Operating parameters include an ambient temperature range of -10 °C to 60 °C, storage temperatures from -25 °C to 60 °C, and 0 to 95% relative air humidity. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
177598
Lock nut MKM-PG-16
The Festo MKM-PG-16 lock nut is an industrial component featuring a PG 16 size and an any mounting position. Built with a corrosion resistance class of CRC 2 for moderate corrosion stress, this part complies with VDMA24364-B2-L LABS (PWIS) conformity standards. Submit your required quantity and application details with part number 177598 to request a formal quotation.
View product details →
Festo
1778842
ISO cylinder DSBF-C-32-250-PPSA-N3-R
The Festo 1778842 is a double-acting industrial component featuring a 32 mm piston diameter and a 250 mm stroke, conforming to ISO 15552 with an M10x1.25 external piston rod thread. Built with self-adjusting pneumatic end-position cushioning, a profile barrel structural design, and position sensing via proximity switch, it operates within a pressure range of 0.06 MPa to 1.2 MPa and an ambient temperature span of -20 °C to 80 °C. The unit achieves a theoretical retracting force of 415 N at 6 bar while offering class 3 high corrosion resistance and ISO 14644-1 class 5 cleanroom suitability. Please submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
177597
Lock nut MKM-PG-11
The Festo MKM-PG-11 lock nut features a PG 11 size and supports any mounting position. This industrial component is classified with a corrosion resistance class (CRC) of 2 for moderate corrosion stress and complies with VDMA24364-B2-L LABS (PWIS) conformity standards. Submit the exact part number, quantity, and application requirements for an official quote.
View product details →
Festo
177596
Lock nut MKM-PG-9
The Festo lock nut MKM-PG-9 is an industrial component featuring a PG 9 size and an arbitrary mounting position. This hardware achieves a corrosion resistance class of CRC 2 for moderate corrosion stress and complies with VDMA24364-B2-L LABS (PWIS) conformity standards. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
1778841
ISO cylinder DSBF-C-32-200-PPSA-N3-R
The Festo part number 1778841 is a double-acting industrial component featuring a 32 mm piston diameter, a 200 mm stroke, and an M10x1.25 piston rod thread with an external end. Conforming to ISO 15552, this unit incorporates self-adjusting pneumatic end-position cushioning, a profile barrel structural design, and position sensing via a proximity switch for operation across a 0.6 bar to 12 bar pressure range. Rated at corrosion resistance class 3, the assembly operates within an ambient temperature range of -20 °C to 80 °C using compressed air meeting ISO 8573-1:2010 [7:4:4] standards. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
177595
Adapter connector MKA-PG-29-PG-21
The Festo 177595 adapter connector, designated as MKA-PG-29-PG-21, features an any mounting position and complies with VDMA24364-B2-L LABS conformity standards. This industrial component provides a corrosion resistance class of CRC 2 for moderate corrosion stress environments. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
1778840
ISO cylinder DSBF-C-32-160-PPSA-N3-R
The Festo 1778840 is a double-acting industrial component featuring a 32 mm piston diameter, a 160 mm stroke, and an M10x1.25 piston rod thread conforming to ISO 15552. Constructed with a piston, piston rod, and profile barrel design, this unit operates at pressures from 0.06 MPa to 1.2 MPa utilizing compressed air according to ISO 8573-1:2010 [7:4:4]. It incorporates self-adjusting pneumatic end-position cushioning, position sensing via proximity switch, and a corrosion resistance class of 3 for high corrosion stress environments. Submit the exact part number, quantity, and application requirements to receive a quote.
View product details →
Festo
177594
Adapter connector MKA-PG-21-PG-29-KU
The Festo MKA-PG-21-PG-29-KU adapter connector, designated by part number 177594, features any mounting position and a corrosion resistance class (CRC) of 2 for moderate corrosion stress. This component complies with VDMA24364-B2-L LABS (PWIS) conformity standards according to the official Festo data sheet. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
