Festo
162168
Guide unit SPZ-10-40-P-A-KF
The Festo 162168 is a double-acting industrial component featuring a 10 mm piston diameter, a 40 mm stroke, and a slide operating mode of the drive unit. It incorporates a recirculating ball bearing guide, a fixed metallic stop for pneumatic cushioning, and an adjustable end-position range of 10 mm with M5 pneumatic connections. Designed with an NBR seal and wrought aluminum alloy cover, this guide operates within a 2.5 to 10 bar working pressure and -20 to 80 °C ambient temperature range while delivering a theoretical force of 60 N at 6 bar for both advance and return strokes. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
161974
Linear actuator DGPL-18- -PPV-A-GF-B
The Festo part number 161974 is a double-acting industrial component featuring an 18 mm piston diameter and an adjustable stroke ranging from 10 to 1,800 mm. Operating on compressed air compliant with ISO8573-1:2010 [7:-:-] at pressures between 2 and 8 bar, this unit delivers a theoretical force of 153 N for both advance and return strokes at 6 bar. It incorporates a plain-bearing guide, a positive-locking driver principle, proximity sensor position detection, and dual-end adjustable PPV pneumatic cushioning alongside YSR hard characteristic curve shock absorbers. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
162723
Filter regulator LFR-3/4-D-5M-MIDI
The Festo 162723 is a Midi size Series D filter regulator with a pressure gauge, featuring a structural design that combines pressure regulation and a 5 µm grade of filtration. This component operates within a pressure range of 1 bar to 16 bar, provides a pressure regulation range of 0.5 bar to 12 bar, and achieves a normal nominal flow rate of 2600 l/min for compressed air as per ISO 8573-1:2010 [-:9:-] or inert gases. Equipped with a manual rotating condensate drain, a 43 cm³ max condensate volume, a metal bowl guard, and a rotary knob with detent actuator lock, it maintains vertical ±5° mounting and moderate corrosion resistance class CRC 2. Submit the exact part number, quantity, and application requirements for a formal quote.
View product details →
Festo
161271
Flat cylinder DZF-32-200-A-P-A
The Festo 161271 is a double-acting industrial component featuring a 32 mm equivalent piston diameter and a 200 mm stroke with an M10x1.25 piston rod thread. Designed with an oval piston for anti-torsion guidance, this unit operates within a 1 bar to 10 bar pressure range using compressed air as per ISO 8573-1:2010 [7:4:4] and provides elastic cushioning rings at both ends. It achieves a theoretical retracting force of 415 N at 6 bar while accommodating a moderate corrosion stress rating of CRC 2 and an ambient temperature range of -20 °C to 80 °C. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
162167
Guide unit SPZ-10-25-P-A-KF
The Festo part number 162167 is a double-acting slide drive unit featuring a 10 mm piston diameter, a 25 mm stroke, and a 10 mm adjustable end-position range. Designed with a recirculating ball bearing guide and pneumatic cushioning with a fixed metallic stop, this component operates within a working pressure of 2.5 to 10 bar using compressed air according to ISO 8573-1:2010 [7:4:4]. It delivers a theoretical force of 60 N on both advance and return strokes at 6 bar, utilizes wrought aluminum alloy covers and NBR seals, and accommodates an ambient temperature range of -20 to 80 °C with any assembly position. Submit the exact part number, quantity, and application requirements for an RFQ quote.
View product details →
Festo
161971
Multi-pin CPV10-VI-P6-M7
The Festo multi-pin CPV10-VI-P6-M7 is an industrial component designated with part number 161971 and an official product weight of 219 g. This RoHS compliant unit conforms to VDMA24364-B1/B2-L LABS (PWIS) specifications as documented in the official Festo data sheet. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this component.
View product details →
Festo
162722
Filter regulator LFR-1/2-D-5M-MIDI
The Festo 162722 is a D-series Midi filter regulator featuring a structural design with a pressure gauge, a rotary knob with detent actuator lock, and a manual rotating condensate drain with a maximum condensate volume of 43 cm³ protected by a metal bowl guard. Operating within a pressure range of 1 bar to 16 bar and a regulation range of 0.5 bar to 12 bar, this component achieves a normal nominal flow rate of 2600 l/min while maintaining a 5 µm filtration grade for compressed air and inert gases under ISO 8573-1:2010 standards. Designed for vertical mounting within ±5°, it operates at temperatures between -10 °C and 60 °C with a moderate corrosion resistance class of 2 and allows oil lubrication. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
162166
Guide unit SPZ-10-10-P-A-KF
The Festo part number 162166 is a double-acting industrial component featuring a slide drive unit operating mode with a 10 mm piston diameter, a 10 mm stroke, and a 10 mm adjustable end-position range. Built with a recirculating ball bearing guide, wrought aluminum alloy cover, and NBR seals, this guide design structure incorporates pneumatic cushioning with a fixed metallic stop and provisions for proximity sensor position detection. It operates on compressed air conforming to ISO8573-1:2010 [7:4:4] within a working pressure range of 2.5 to 10 bar, delivering a theoretical force of 60 N for both advance and return strokes at 6 bar. Designed for any assembly position in ambient temperatures from -20 to 80 °C with an M5 pneumatic connection and CRC 0 corrosion resistance, it allows lubricated operation subsequently required for further operation. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
161270
Flat cylinder DZF-32-160-A-P-A
The Festo 161270 is a double-acting industrial component featuring a 32 mm equivalent piston diameter and a 160 mm stroke with an M10x1.25 piston rod thread. This unit utilizes an oval piston for torsion protection providing a maximum rotation angle of plus or minus 0.8 degrees and 0.8 Nm max torque operating within a pressure range of 1 bar to 10 bar. It incorporates elastic cushioning rings at both ends, position sensing via proximity switch, and operates with compressed air according to ISO 8573-1:2010 [7:4:4] across an ambient temperature range of -20 °C to 80 °C. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this component.
View product details →
Festo
161970
Multi-pin CPV10-VI-P4-M7
The Festo Multi-pin CPV10-VI-P4-M7, part number 161970, is an industrial component with a product weight of 164 g and VDMA24364-B1/B2-L LABS (PWIS) conformity. This unit features RoHS-compliant materials in accordance with the official Festo data sheet. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
162721
Filter regulator LFR-3/8-D-5M-MIDI
The Festo 162721 is a Midi size D series filter regulator featuring a structural design with a pressure gauge and an actuator lock via a rotary knob with detent. Operating within a pressure range of 1 bar to 16 bar and a regulation range of 0.5 bar to 12 bar, this unit delivers a normal nominal flow rate of 2400 l/min for compressed air and inert gases. It includes a 5 µm filtration grade, a manual rotating condensate drain with a 43 cm³ max condensate volume, a metal bowl guard, and operates in a vertical ±5° mounting position. Submit the exact part number, quantity, and application requirements to receive a quote for this component.
View product details →
Festo
162164
Twin-piston cylinder DPZJ-32-100-P-A-KF-S20
The Festo part number 162164 is a double-acting industrial component featuring a 32 mm piston diameter, a 100 mm stroke, and a yoke drive unit with a through, hollow piston rod and recirculating ball bearing guide. Operating on compressed air in accordance with ISO8573-1:2010 [7:4:4] across a working pressure range of 1 to 10 bar, this unit delivers a theoretical force of 724 N at 6 bar for both advance and return strokes. It incorporates flexible cushioning rings at both ends, a 10 mm adjustable end-position range, position detection for proximity sensors, and an ambient temperature range of -20 to 80 °C. Submit the exact part number, quantity, and application requirements for a formal quote.
View product details →
Festo
161969
Multi-pin CPV10-VI-P2-M7
The Festo multi-pin CPV10-VI-P2-M7 is an industrial component featuring a product weight of 135 g and RoHS compliant materials. This unit conforms to VDMA24364-B1/B2-L LABS (PWIS) standards according to official documentation. Submit the exact part number, quantity, and application requirements to request a formal quote for this item.
View product details →
Festo
161269
Flat cylinder DZF-32-125-A-P-A
The Festo 161269 is a double-acting industrial component featuring a 32 mm equivalent piston diameter, a 125 mm stroke, and an M10x1.25 piston rod thread with an oval piston design that provides an integrated torsion protection of 0.8 Nm and a maximum rotation angle of +/- 0.8 degrees. Operating on compressed air according to ISO 8573-1:2010 [7:4:4] within a pressure range of 1 bar to 10 bar, this unit incorporates elastic cushioning rings at both ends, a corrosion resistance class of CRC 2, and position sensing via proximity switch. It delivers a theoretical retracting force of 415 N at 6 bar across an ambient temperature range of -20 °C to 80 °C, and permits operation with oil lubrication. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
162163
Twin-piston cylinder DPZJ-32-80-P-A-KF-S20
The Festo part number 162163 is a double-acting industrial drive unit featuring a yoke operating mode, a 32 mm piston diameter, and an 80 mm stroke with a 10 mm adjustable end-position range. Designed with a recirculating ball bearing guide and a hollow, through piston rod, this component operates on compressed air conforming to ISO8573-1:2010 [7:4:4] within a working pressure range of 1 to 10 bar. It delivers a theoretical force of 724 N for both advance and return strokes at 6 bar, utilizes flexible cushioning rings or plates at both ends, and functions within an ambient temperature range of -20 to 80 °C. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
162720
Filter regulator LFR-3/8-D-5M-MINI
The Festo part number 162720 is a mini-size D-series structural design filter regulator featuring an integrated pressure gauge, a rotary knob with detent actuator lock, and a 5 µm grade of filtration. Operating within a pressure range of 1 bar to 16 bar and a regulation range of 0.5 bar to 12 bar, this component supports a normal nominal flow rate of 1350 l/min while utilizing compressed air or inert gases with a 22 cm³ max condensate volume and manual rotating condensate drain. Submit the exact part number, quantity, and application requirements to receive a quote for this item.
View product details →
Festo
161937
Inscription label IBS-9X17
This Festo industrial component, part number 161937, measures 17 by 9 mm with a height of 9 mm and a length of 17 mm. The part features labelling of 24, is supplied in a pack size of 24, and carries a corrosion resistance class (CRC) of 0 for no corrosion stress. Featuring RoHS compliant materials, the component conforms to VDMA24364-B1/B2-L LABS (PWIS) standards. Submit the exact part number, quantity, and application requirements to receive a formal quote.
View product details →
Festo
161268
Flat cylinder DZF-32-100-A-P-A
The Festo 161268 is a double-acting industrial component featuring a 32 mm equivalent piston diameter, a 100 mm stroke, and an M10x1.25 piston rod thread. Operating within a pressure range of 1 bar to 10 bar utilizing compressed air per ISO 8573-1:2010 [7:4:4], this unit incorporates elastic cushioning rings at both ends and an oval piston providing an anti-torsion guide with a maximum rotation angle of +/- 0.8 degrees. It offers a corrosion resistance class of 2, operates in ambient temperatures from -20 °C to 80 °C, and delivers a theoretical retracting force of 415 N at 6 bar. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
162162
Twin-piston cylinder DPZJ-32-50-P-A-KF-S20
The Festo part number 162162 is a double-acting industrial component featuring a 32 mm piston diameter, a 50 mm stroke, and a yoke drive unit design with a recirculating ball bearing guide and through, hollow piston rod. Operating with compressed air in accordance with ISO8573-1:2010 [7:4:4] at a working pressure of 1 to 10 bar, it achieves a theoretical force of 724 N at 6 bar for both advance and return strokes, while utilizing flexible cushioning rings at both ends for 0.5 Nm impact energy in end positions. This unit accommodates any assembly position, ambient temperatures from -20 to 80 °C, a maximum speed of 1 m/s, and position detection via proximity sensors, alongside an adjustable end-position range of 10 mm. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
161936
Inscription clip MN2H-BZT-10X
The Festo inscription clip MN2H-BZT-10X is an industrial component with a product weight of 7 g and a materials note specifying it is free of copper and PTFE. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this Festo component.
View product details →
