Festo
539185
Air solenoid valve VSVA-B-M52-MZD-A2-1T1L
The Festo 539185 is a 5/2-way monostable industrial component featuring an 18 mm width, a piston gate valve structural design, and a normal nominal flow rate of 550 l/min according to DIN 1343. Operating on 24V DC with an operating pressure range of -0.09 MPa to 1 MPa (-0.9 bar to 10 bar), this electrically actuated piloted valve includes a mechanical spring reset, soft sealing principle, positive overlap lap, and an LED signal status display. It offers IP65 and NEMA 4 degrees of protection, c UL us recognition (OL), and supports any mounting position with internal or external pilot air supply ports, sub-base pneumatic working ports matching ISO 15407-1, VDMA 24563 size 02 connecting plates, or G1/8 connections. Request a quote by submitting the exact part number, quantity, and application requirements.
