Industrial sourcing catalog
Browse verified product records and request commercial availability, lead time and technical documentation.
Festo
The Festo 153662 is a standard industrial component featuring a 2.3 mm nominal size and a push/pull design structure operating between -0.95 and 10 bar. Configured with a 5/32" outside diameter tubing connection, a grey release ring, and a PBT housing with NBR tubing seals, this unit functions with filtered compressed air or vacuum across an ambient temperature range of -10 to 60 °C. Certified by Germanischer Lloyd with a CRC rating of 1, the 5 g assembly incorporates high alloy, non-corrosive steel clamping segments and complies with RoHS standards. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo 153989 is a directly controlled 2/2-way bistable piston gate valve featuring a 1/8 NPT pneumatic connection 1, a QS-3/16 pneumatic connection 2, and a 2.5 mm nominal width. Constructed with a reinforced PBT housing and a soft sealing principle, this manual actuation component operates within a pressure range of -0.95 bar to 10 bar and supports a normal nominal flow rate of 185.4 l/min using compressed air conforming to ISO 8573-1:2010 [7:-:-]. It accommodates any mounting position through direct mounting via through-hole or direct fastening via thread, achieving a Class 4 cleanroom suitability according to ISO 14644-1 and a moderate corrosion resistance class of CRC 2. Submit the exact part number, quantity, and application requirements for an RFQ quote.
View product details →
Festo
This standard Festo industrial component, part number 153113, features a T-shape design with one supply line and two outlets utilizing the push-pull principle for a nominal width of 8.3 mm and a tubing insertion depth of 20.2 mm. The unit operates within a temperature range of -10 °C to 80 °C, supporting compressed air per ISO 8573-1:2010 [7:-:-] and liquid water with operating pressures up to 1.4 MPa depending on temperature. Each pack contains 10 units with a product weight of 42 g each, a coated seal on the screwed plug, and ISO 14644-1 Class 4 cleanroom suitability. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
Engineered with a 16 mm piston diameter and a stroke length adjustable from 1 to 200 mm, this double-acting Festo industrial component utilizes a piston and piston rod design with flexible cushioning rings at both ends. Operating within a pressure range of 0.13 to 1 MPa (1.3 to 10 bar) using compressed air conforming to ISO 8573-1:2010 [7:4:4], the unit delivers a theoretical force of 90 N upon both advance and retraction at 0.6 MPa. Available variants include a through, hollow piston rod and heat-resistant seals rated for temperatures up to 120 °C, while maintaining a moderate corrosion resistance classification of CRC 2. Submit part number 156071 along with your required quantity and application specifications to request a formal quote.
View product details →
Festo
The Festo part number 153661 is a standard-sized, L-shaped long industrial component featuring a nominal width of 5.6 mm and a push-pull structural design with a gray releasing ring. Constructed with a PBT housing and a weight of 11 g, it incorporates a 3/8" push-in sleeve and a connection for 3/8" outside diameter pneumatic tubing, operating within a pressure range of -0.95 bar to 10 bar (-13.775 psi to 145 psi) and an ambient temperature range of -10 °C to 60 °C (14 °F to 140 °F). This RoHS-compliant component supports compressed air operating medium per ISO 8573-1:2010 [7:-:-] with lubricated operation possible, features a corrosion resistance class of 1, and allows any mounting position. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
The Festo 153988 is a directly controlled, bistable 3/2-way piston gate valve featuring a 1/2 NPT pneumatic connection 1, a QS-1/2 pneumatic connection 2, and an unthrottlable exhaust function. Constructed with a reinforced PBT housing and soft sealing principles, this component delivers a normal nominal flow rate of 812.7 l/min at a nominal width of 4.7 mm across an operating pressure range of -0.95 bar to 10 bar. It offers manual actuation, an ambient temperature range of 0 °C to 60 °C, universal mounting position flexibility via through-holes or thread fastening, and moderate corrosion resistance rated at CRC 2. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 153112 is a T-shaped industrial component featuring a standard size, an 8 mm nominal width, and a 20.2 mm tubing insertion depth utilizing a push-pull structural design with one supply line and two outlets. It operates within a temperature range of -10 °C to 80 °C, handling compressed air according to ISO 8573-1:2010 [7:-:-] and ice-free liquid water, with an operating pressure spanning -0.095 MPa to 1.4 MPa depending on temperature. This pack of ten components weighs 31 g each, features a sealed screwed plug with a coating, exhibits a corrosion resistance class of 1, and meets ISO 14644-1 Class 4 cleanroom standards. Submit the exact part number, quantity, and application requirements to receive a quote.
View product details →
Festo
The Festo 156070 is a double-acting industrial component featuring a 12 mm piston diameter, an adjustable stroke from 1 to 200 mm, and a male thread piston-rod end with a through, hollow design. Operating on compressed air in accordance with ISO 8573-1:2010 [7:4:4] within a pressure range of 0.15 to 1 MPa (1.5 to 10 bar or 21.75 to 145 psi), this unit delivers a theoretical force of 51 N on both advance and retraction at 0.6 MPa. It incorporates flexible cushioning rings at both ends, position detection capabilities for proximity sensors, heat-resistant seals rated up to 120 °C, and a moderate corrosion resistance classification of CRC 2. Submit the exact part number, quantity, and application requirements to request a quote for this component.
View product details →
Festo
The Festo 153660 is a standard industrial component featuring a 4.5 mm nominal size and a push/pull design structure with a 5/16" outside diameter port 2 pneumatic connection. Fabricated with a PBT housing, POM grey release ring, NBR tubing seal, and high alloy non-corrosive steel tube retaining claw, this 6.2 g part operates on compressed air matching ISO8573-1:2010 [7:-:-] across a -0.95 to 10 bar pressure range and -10 to 60 °C ambient temperature. It supports lubricated operation, achieves a CRC 1 low corrosion stress classification, mounts in any assembly position, and conforms to RoHS requirements with maritime classification detailed in its certificate. Submit the exact part number, quantity, and application requirements to request a formal quote for this container size 1 item.
View product details →
Festo
The Festo 153987 is a directly controlled 3/2-way bistable industrial component featuring a piston gate valve structural design and a normal nominal flow rate of 744.3 l/min normalized to DIN 1343. This unit provides a 3/8 NPT pneumatic connection 1, a QS-3/8 pneumatic connection 2, manual actuation, and an operating pressure range from -0.95 bar to 10 bar within an ambient temperature of 0 °C to 60 °C. Constructed with a PBT-reinforced housing and soft sealing principle, it supports compressed air operation according to ISO 8573-1:2010 [7:-:-] with optional oil lubrication. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo 153111 is a standard T-shaped industrial component featuring a push-pull structural design with a nominal width of 6.7 mm, an 18.1 mm tubing insertion depth, one supply line, and two outlets. It accommodates compressed air as per ISO 8573-1:2010 [7:-:-] or liquid water, operating at pressures from -0.095 MPa to 1.4 MPa depending on temperature, and supports lubricated operation with a coated screwed plug seal. This unit weighs 35 g, offers ISO Class 4 cleanroom suitability, and functions within an ambient temperature range of -10 °C to 80 °C. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo 100 mm piston diameter double-acting industrial component features a square piston rod with a male M20x1,5 thread, offering an adjustable stroke length from 1 to 600 mm and operating within a pressure range of 0.2 to 12 bar. Designed in accordance with ISO 6431, this unit incorporates adjustable pneumatic cushioning at both ends over a 30 mm cushioning length, delivering theoretical forces of 4,496 N on the advance stroke and 4,221 N on the return stroke at 6 bar. It functions in any assembly position using dried compressed air, accommodates position detection via proximity sensors, and maintains a CRC 2 corrosion resistance classification across ambient temperatures of -20 to 80 °C. Submit the exact part number, quantity, and application requirements for a formal quotation.
View product details →
Festo
The Festo 153659 is a standard L-shape, long industrial component featuring a nominal width of 3.1 mm and a push-pull structural design utilizing a 1/4" push-in sleeve and a pneumatic connection for 1/4" outer diameter tubing. Constructed with a PBT housing and a gray releasing ring, this RoHS-compliant part operates within a pressure range of -0.95 bar to 10 bar and temperatures from -10 °C to 60 °C using compressed air as per ISO 8573-1:2010 [7:-:-]. It weighs 4.3 g, offers a CRC rating of 1 for low corrosion stress, and can be mounted in any position with lubricated operation possible. Submit the exact part number, quantity, and application requirements for an RFQ quote.
View product details →
Festo
The Festo 153986 is a 3/2-way bistable industrial component featuring manual actuation and a piston gate valve structural design with direct control. Built with a reinforced PBT housing and a soft sealing principle, this non-reversible unit delivers a nominal width of 3.2 mm and a normal nominal flow rate of 340.2 l/min across an operating pressure range of -0.95 bar to 10 bar. It includes 1/4 NPT and QS-1/4 pneumatic connections, an unthrottled exhaust function, and supports installation in any mounting position via through-hole or thread direct fastening. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo 156069 is a double-acting industrial component featuring a 100 mm piston diameter, an adjustable stroke ranging from 1 mm to 400 mm, and a through, hollow piston rod with an external thread. It operates at pressures between 0.08 MPa and 1 MPa utilizing compressed air as per ISO 8573-1:2010 [7:4:4] with possible oil lubrication, delivering a theoretical force of 4418 N at 6 bar in both retracting and advancing directions. Equipped with elastic cushioning rings at both ends, position sensing for proximity sensors, and a moderate corrosion resistance class (CRC 2), this unit accommodates any mounting position via optional through-holes or accessories. Submit the exact part number, quantity, and application requirements to request a formal quote.
View product details →
Festo
The Festo part number 153110 is a standard T-shaped industrial component featuring a 6.7 mm nominal width, an 18.1 mm tubing insertion depth, one supply line, and two outlets utilizing a push-pull structural design with a coated screwed plug seal. This unit operates across an ambient temperature range of -10 °C to 80 °C, supports compressed air and ice-free liquid water with lubricated operation capability, and weighs 25 g with a Class 4 ISO 14644-1 cleanroom rating and CRC 1 low corrosion stress. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 153658 is an L-shaped industrial component featuring a standard size with a 4.9 mm nominal width and a push-pull structural design utilizing a gray releasing ring. Constructed with a PBT housing and weighing 7.8 g, it accommodates compressed air operating media according to ISO 8573-1:2010 [7:-:-] across an operating pressure range of -0.95 bar to 10 bar and temperatures from -10 °C to 60 °C. This RoHS compliant part connects a ø 3/8" push-in sleeve to a 5/16" outside diameter pneumatic tubing and offers universal mounting positioning with a CRC rating of 1 for low corrosion stress. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
The Festo 153985 is a directly controlled 3/2-way bistable industrial component featuring a piston gate valve structural design and manual actuation type. Constructed with a reinforced PBT housing and soft sealing principle, this unit operates within a pressure range of -0.95 bar to 10 bar and handles a normal nominal flow rate of 185.4 l/min with compressed air as per ISO 8573-1:2010 [7:-:-]. It is equipped with a 1/8 NPT pneumatic connection 1, a QS-3/16 pneumatic connection 2, an unthrottlable exhaust function, and supports alternative direct mounting via through-hole or thread in any mounting position. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo 156068 is a double-acting industrial component featuring a structural design with a piston and a hollow, through piston rod with an external thread and an 80 mm piston diameter. Operating within a stroke range of 1 mm to 400 mm and a pressure range of 0.08 MPa to 1 MPa (0.8 bar to 10 bar / 11.6 psi to 145 psi), this unit utilizes elastic cushioning rings or pads at both ends and accommodates compressed air as per ISO 8573-1:2010 [7:4:4] with optional oil lubrication. The assembly supports any mounting position via a through-hole or accessories, includes position sensing for proximity sensors, and provides a theoretical force of 2827 N both advancing and retracting at 6 bar. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo 153657 is a standard L-shaped industrial component featuring a 3.5 mm nominal width, a PBT housing with a gray releasing ring, and a push-pull structural design weighing 5.1 g. It accommodates a 5/16" push-in sleeve as pneumatic connection 1 and a 1/4" outer diameter pneumatic tubing for pneumatic connection 2, operating within a pressure range of -0.95 bar to 10 bar and temperatures from -10 °C to 60 °C using compressed air per ISO 8573-1:2010 [7:-:-]. This RoHS-compliant part offers CRC 1 low corrosion stress, VDMA24364-B1/B2-L LABS conformity, any mounting position, and support for lubricated operation with maritime classification detailed in its certificate. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
