Festo
The Festo 153373 is a mini Y-shaped industrial component featuring a push-pull structural design with 1 supply line and 2 outlets for 4 mm and 3 mm outside diameter pneumatic tubing respectively. This unit operates on compressed air conforming to ISO 8573-1:2010 [7:-:-] with a nominal width of 1.6 mm, an 11.6 mm tubing insertion depth, and supports lubricated operation across any mounting position. It withstands an operating pressure of -0.095 MPa to 0.6 MPa over a temperature range of -10 °C to 80 °C, and a temperature-dependent operating pressure up to 1.4 MPa. Each pack contains 10 units with a product weight of 3.6 g each, a corrosion resistance class of 1, and VDMA24364-B1/B2-L LABS conformity. Submit the exact part number, quantity, and application requirements for a formal quote.
View product details →
Festo
The Festo part number 153027 is a standard straight industrial component featuring a 7 mm nominal width, 18.2 mm tubing insertion depth, and an external hexagon SW21 mounting type with a coated screwed plug seal. Operating via the push-pull structural design, this unit handles compressed air per ISO 8573-1:2010 [7:-:-] and liquid water within an ambient temperature range of -10 °C to 80 °C, supporting a nominal tightening torque of 15.5 Nm with a ±20% tolerance. Each pack size contains 10 units, each weighing 32 g with a CRC rating of 1 and VDMA24364-B1/B2-L LABS conformity, capable of lubricated operation across varying pressure thresholds. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
The Festo 151704 is an electrical, piston slide industrial component featuring a 5/3 pressurized valve function, a standard nominal flow rate of 1,300 l/min, and a working pressure range of -0.9 to 10 bar. This piloted unit includes a mechanical spring reset, soft sealing principle, throttleable exhaust-air function, and reversible flow direction operating with compressed air in accordance with ISO 8573-1:2010 [7:4:4]. It accommodates a nominal size of 7 mm, pilot pressure of 4 to 6 bar, any assembly position, and detenting manual override with accessories while permitting lubricated operation. Submit the exact part number, quantity, and application requirements to receive a formal quote.
View product details →
Festo
The Festo 153221 is a standard industrial component featuring a 2.4 mm nominal width, 1 of supply lines, and 3 outlets utilizing a push-pull structural design with an integrated coated seal on the screwed plug. This unit operates across a temperature-dependent pressure range of -0.95 bar to 14 bar and an ambient temperature range of -10 °C to 80 °C, supporting compressed air per ISO 8573-1:2010 [7:-:-] or liquid water with lubricated operation possible. Weighing 33 g with a nominal tightening torque of 7 Nm (±20%), it features a 14.9 mm tubing insertion depth, VDMA24364-B1/B2-L LABS conformity, and CRC 1 corrosion resistance for installation in any mounting position. Submit the exact part number, quantity, and application requirements to receive a formal quote.
View product details →
Festo
The Festo part number 151703 is an electrical 5/3 exhausted industrial component featuring a piston slide design structure and a standard nominal flow rate of 1,300 l/min. Operating within a working pressure range of -0.9 to 10 bar, this piloted valve utilizes a soft sealing principle, a mechanical spring reset, and a reversible flow direction with a 7 mm nominal size. It accommodates compressed air operating media compliant with ISO 8573-1:2010 [7:4:4] and permits lubricated operation when subsequently required. Submit the exact part number, quantity, and application requirements to receive a formal quote.
View product details →
Festo
The Festo 153372 is a mini Y-shape industrial component featuring a 2.9 mm nominal width, an 11.9 mm tubing insertion depth, and a push-pull structural design with a blue releasing ring. This pack of 10 units connects one 6 mm outside diameter supply line to two 6 mm outside diameter pneumatic outlets, supporting compressed air media per ISO 8573-1:2010 [7:-:-] with lubricated operation capability. It operates across an ambient temperature range of -10 °C to 80 °C, an operating pressure of -0.095 MPa to 0.6 MPa across full temperatures, a temperature-dependent operating pressure up to 1.4 MPa, and features any mounting position with a product weight of 5.5 g, CRC 1 low corrosion stress, and VDMA24364-B1/B2-L LABS conformity. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo part number 153026 is a standard straight industrial component featuring a push-pull structural design, a 7 mm nominal width, and an 18.2 mm tubing insertion depth with an external hexagon SW17 mounting type. This component accommodates compressed air and liquid water operating media across an ambient temperature range of -10 °C to 80 °C, utilizing a screwed plug seal with a coating and a nominal tightening torque of 9 Nm with a ±20% tolerance. Each pack contains 10 units with a product weight of 24 g each, supporting a corrosion resistance class of 1 and VDMA24364-B1/B2-L LABS conformity. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo part number 153220 is a standard industrial component featuring a nominal width of 6.4 mm, a tubing insertion depth of 23.4 mm, and a push-pull structural design with two outlets and one supply line. Operating with compressed air or liquid, ice-free water, this component handles an operating pressure from -0.095 MPa to 0.6 MPa across its entire temperature range of -10 °C to 80 °C, alongside a temperature-dependent operating pressure reaching up to 1.4 MPa. Weighing 149 g with a corrosion resistance class of 1 and a nominal tightening torque of 26 Nm at a ±20% tolerance, the unit utilizes a coated screwed plug seal and supports any mounting position. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo part number 151702 is an electrical piston slide industrial component featuring a 5/3 closed valve function and a standard nominal flow rate of 1,300 l/min. Engineered with a working pressure of -0.9 to 10 bar, a 7 mm nominal size, and a soft sealing principle, this piloted valve operates on compressed air meeting ISO8573-1:2010 [7:4:4] standards with reversible flow direction. It includes a mechanical spring reset, throttleable exhaust-air function, and mechanical override with accessories, exhibiting a 25 ms on-switching time and a 55 ms off-switching time. Submit the exact part number, quantity, and application requirements to receive a formal quote.
View product details →
Festo
The Festo 153371 is a mini Y-shape industrial component featuring one supply line and two outlets designed for 4 mm outside diameter pneumatic tubing. This push-pull principle unit operates with compressed air per ISO 8573-1:2010 [7:-:-] across an ambient temperature range of -10 °C to 80 °C, supporting lubricated operation and pressures from -0.095 MPa to 1.4 MPa depending on temperature. Weighing 3.5 g with a blue releasing ring, it offers a 1.7 mm nominal width, 11.6 mm tubing insertion depth, any mounting position, and CRC 1 low corrosion stress. Submit the exact part number, quantity, and application requirements for an RFQ quote.
View product details →
Festo
The Festo part number 153025 is a straight-design industrial component utilizing a push-pull principle with a 7 mm nominal width and an 18.2 mm tubing insertion depth. It operates with compressed air or liquid water across a temperature-dependent operating pressure of -0.95 bar to 14 bar and an ambient temperature range of -10 °C to 80 °C. Featuring an external hexagon SW14 mounting type, this standard-sized component has a 16 g product weight, a coated screwed plug seal, and a nominal tightening torque of 7 Nm with a ±20% tolerance. Submit the exact part number, quantity, and application requirements to receive a quote for this Festo component.
View product details →
Festo
The Festo 151701 is an electrical 5/2 bistable industrial component featuring a piston slide design structure and a nominal size of 7 mm with a standard nominal flow rate of 1,300 l/min. Operating at a working pressure of -0.9 to 10 bar, this piloted valve utilizes a soft sealing principle, throttleable exhaust-air function, and reversible flow direction for compressed air media according to ISO8573-1:2010 [7:4:4]. The unit operates within a temperature range of -5 to 50 °C, supports lubricated operation, and mounts via through holes with a detenting manual override. Submit the exact part number, quantity, and application requirements to receive a quote.
View product details →
Festo
The Festo part number 153219 is a standard industrial component featuring a 6.3 mm nominal width, 23.4 mm tubing insertion depth, and a structural design utilizing the push-pull principle with 1 supply line and 2 outlets. This component operates across a temperature-dependent pressure range of -0.95 bar to 14 bar and an entire-temperature-range operating pressure of -0.95 bar to 6 bar, supporting compressed air per ISO 8573-1:2010 [7:-:-] or ice-free liquid water. Featuring a coated screwed plug seal, a nominal tightening torque of 15.5 Nm with a ±20% tolerance, a product weight of 139 g, and a low corrosion stress rating of CRC 1, it functions within an ambient temperature range of -10 °C to 80 °C in any mounting position. Submit the exact part number, quantity, and application requirements to receive a quote.
View product details →
Festo
The Festo 153370 is a mini Y-shape industrial component featuring a 1.6 mm nominal width, one supply line, and two outlets designed for 3 mm outside diameter pneumatic tubing. This push-pull design operates within an ambient temperature range of -10 °C to 80 °C and supports compressed air media in accordance with ISO 8573-1:2010 [7:-:-] with a blue releasing ring. Supplied in a pack size of 10 with a product weight of 3.7 g each, it accommodates any mounting position and permits lubricated operation. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo part number 153024 is a straight industrial component featuring a standard size, a 5 mm nominal width, and a 17 mm tubing insertion depth utilizing the push-pull principle. Operating on compressed air per ISO 8573-1:2010 [7:-:-] or liquid water, this component accommodates an operating pressure from -0.95 bar to 6 bar across the entire temperature range and up to 14 bar with temperature dependency. It incorporates a coated seal on the screwed plug, an external hexagon SW17 for mounting with a 9 Nm nominal tightening torque, and an ambient temperature range of -10 °C to 80 °C in any mounting position. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
The Festo 151700 is an electrically actuated 5/2 monostable industrial component featuring a piston slide design structure and a 7 mm nominal size. This piloted valve operates within a working pressure range of -0.9 to 10 bar, delivering a standard nominal flow rate of 1,300 l/min using compressed air in accordance with ISO 8573-1:2010 [7:4:4]. It incorporates an air spring reset, soft sealing principle, throttleable exhaust-air function, and reversible flow direction with a pilot pressure of 4 to 6 bar. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo part number 153218 is a standard industrial component featuring a nominal width of 5.3 mm, a tubing insertion depth of 20.2 mm, 1 supply line, and 2 outlets utilizing a push-pull structural design with a coated seal on the screwed plug. This unit operates with compressed air conforming to ISO 8573-1:2010 [7:-:-] or ice-free liquid water across a temperature-dependent operating pressure range of -0.095 MPa to 1.4 MPa and an ambient temperature range of -10 °C to 80 °C. With a product weight of 83 g, a nominal tightening torque of 15.5 Nm with a ±20% tolerance, a corrosion resistance class of 1, and VDMA24364-B1/B2-L LABS conformity, it supports any mounting position and allows lubricated operation. Submit the exact part number, quantity, and application requirements to request a quote for this Festo component.
View product details →
Festo
The Festo 153023 is a straight industrial component featuring a standard size, a 5 mm nominal width, and a 17 mm tubing insertion depth with a push-pull structural design. It operates with compressed air as per ISO 8573-1:2010 [7:-:-] or liquid water across an ambient temperature range of -10 °C to 80 °C and an operating pressure range from -0.095 MPa to 0.6 MPa. Each pack size contains 10 units weighing 15 g each, utilizing an external hexagon SW14 for mounting with a nominal tightening torque of 7 Nm at a ±20% tolerance. Submit the exact part number, quantity, and application requirements to receive a formal quote.
View product details →
Festo
The Festo 153369 is a mini T-shaped industrial component featuring a push-pull structural design with 1 supply line and 2 outlets, accommodating a 6 mm pneumatic tubing connection on one side and a 4 or 6 mm connection on the other. It operates with compressed air according to ISO 8573-1:2010 [7:-:-] across an ambient temperature range of -10 °C to 80 °C, supporting lubricated operation and featuring a low corrosion stress CRC rating of 1. This pack of 10 weighs 4 g each and functions at operating pressures from -0.095 MPa to 0.6 MPa across its full temperature range, or up to 1.4 MPa depending on the temperature. Submit the exact part number, quantity, and application requirements for an RFQ quote.
View product details →
Festo
The Festo 151695 is a directly controlled 5/3-way closed piston gate valve featuring a 10 mm nominal width, a hard sealing principle, and a magnetic spring reset method. It operates within a pressure range of 0 bar to 10 bar (0 MPa to 1 MPa), delivers a normal nominal flow rate of 2000 l/min normalized to DIN 1343, and incorporates reverse polarity protection across all electrical connections alongside a 0 - 10 V voltage setpoint/actual value range. Built with any mounting position, a 70 Hz cut-off frequency, and a safety position that approaches the blocked mid-position upon a power supply cable break, this electrical component functions with a DC operating voltage range of 17 V to 30 V. Submit the exact part number, quantity, and application requirements to receive a formal quote.
View product details →
