Industrial sourcing catalog
Browse verified product records and request commercial availability, lead time and technical documentation.
Festo
The Festo 1492315 is a force pilot-operated diaphragm valve featuring a soft sealing principle and a 40 mm nominal width in a 2/2-way, closed, monostable configuration with G1 1/4 in-line fitting connections. Designed for upright magnet mounting with non-reversible flow direction, this electrical component operates with a 230 V AC 50/60 Hz coil requiring 30.0 VA initial and holding power under permissible voltage fluctuations of +/- 10% and a medium pressure range of 0 bar to 10 bar. It processes compressed air as per ISO 8573-1:2010 [7:-:-], inert gas, mineral oil, water, and neutral liquids with a nominal fitting pressure PN of 40 and 0 bar differential pressure via a Type A plug electrical connection complying with EN 175301-803. Submit the exact part number, quantity, and application requirements to request a formal quote for this component.
View product details →
Festo
The Festo 1470874 is an electric actuator featuring a ball screw drive and an integrated stepper motor with a size of 25, a 1.8-degree full step angle, and a 3 A motor nominal current at 24 V DC nominal operating voltage. This structural design incorporates a stroke ranging from 50 mm to 300 mm with 0 mm stroke reserve, 0.1 mm reversing backlash, ±0.02 mm repetition accuracy, 10 m/s² maximum acceleration, and a 100% duty cycle for any mounting position. Certified with RCM compliance mark, c UL us Recognized (OL), and CE and UKCA markings per EMC and RoHS directives, it maintains insulation protection class B, a ±5% step angle tolerance, and a maximum piston rod rotation angle of ±1.5 degrees. Submit the exact part number, quantity, and application requirements for an RFQ.
View product details →
Festo
The Festo 1489958 is a pilot-controlled piston poppet valve featuring a 2/2-way, closed, monostable function with a 25 mm nominal width and soft sealing principle. Designed for in-line installation with a G3/4 fitting connection, this electrical component operates on compressed air, inert gas, and neutral liquids with a nominal pressure PN of 40 and a 100% duty cycle. Its Type A electrical connection adheres to EN 175301-803 and supports a 110 V AC 50/60 Hz coil with class H insulation, initial power of 10.5 VA, and holding power of 8.0 VA. Submit the exact part number, quantity, and application requirements to request a quote for this component.
View product details →
Festo
The Festo 1492024 is a directly actuated poppet valve utilizing a soft sealing principle and a 2/2-way, closed, monostable valve function with a nominal width of 1.5 mm. Configured for in-line installation with 1/4 NPT fitting connections and any mounting position, this electrical component operates on 230 V AC (50/60 Hz) power with insulation class F and a 100% duty cycle. It handles compressed air, inert gas, mineral oil, water, and neutral liquids with a nominal pressure PN of 50 and zero differential pressure. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
The Festo 1492314 is an electrically actuated force pilot operated diaphragm valve featuring a soft sealing principle and a 2/2-way, closed, monostable valve function. Designed for in-line installation with a G1 fitting connection and a nominal width of 27.5 mm, it operates with a 230 V AC (50/60 Hz) coil, a PN 40 nominal pressure rating, and a medium pressure range of 0 bar to 6 bar. This non-reversible component accommodates compressed air, inert gas, mineral oil, water, and neutral liquids, functioning with upright magnet mounting and an EN 175301-803 Type A rectangular electrical plug. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo 14708 is a double-acting industrial component with a 40 mm piston diameter and an adjustable stroke from 1 to 300 mm, built on the ISO 6431 standard with a piston and piston rod design structure. Featuring S6 heat-resistant seals supporting ambient temperatures up to 150 °C, operating pressures from 0.5 to 8 bar, and adjustable pneumatic cushioning at both ends, this unit delivers a theoretical force of 1,430 N on the advance stroke and 1,172 N on the return stroke at 6 bar. Aluminum die-cast covers, G1/4 pneumatic connections, and a CRC 2 corrosion resistance classification complete the assembly, which operates on filtered compressed air in any mounting position with proximity sensor position detection. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo part number 1489957 is a pilot-controlled piston poppet valve featuring a soft sealing principle, a 13 mm nominal width, and a 2/2-way closed monostable valve function with non-reversible flow direction. Designed for in-line installation with a G1/2 fitting connection, this electrical component operates on 110 V AC (50/60 Hz) with Class H insulation, a 100% duty cycle, and piloted control supporting a nominal pressure PN of 40 and a 0.5 bar differential pressure for compressed air, inert gas, and neutral liquids. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo 1492023 is an electrical, directly actuated poppet valve featuring a soft sealing principle and a 2/2-way, closed, monostable valve function with a 1 mm nominal width. Designed for in-line installation with a 1/4 NPT fitting connection and any mounting position, it operates on 230 V AC (50/60 Hz) power with a 100% duty cycle and mechanical spring reset. This non-reversible component handles compressed air, inert gas, mineral oil, water, and neutral liquids up to a nominal pressure of 50 bar, utilizing a Type A plug electrical connection complying with EN 175301-803. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo 1492313 is an electrical, force pilot-operated diaphragm valve featuring a soft sealing principle and a G3/4 fitting connection for in-line installation with an upright magnet mounting position. This 2/2-way closed monostable valve operates with a nominal width of 27.5 mm, a nominal fitting pressure PN of 40, and a medium pressure range of 0 to 0.6 MPa (0 to 87 psi) with 0 bar differential pressure, handling compressed air, inert gas, mineral oil, water, and neutral liquids via a 230 V AC coil drawing 18.0 VA initial power and 15.0 VA holding power. Electrical connection is established through a rectangular Type A plug as per EN 175301-803, accommodating permissible voltage fluctuations of +/- 10% without manual override or flow direction reversibility. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
The Festo 1470777 is an electric actuator featuring a ball screw drive with a size of 25, a 300 mm stroke, and a 10 mm spindle pitch. Driven by a stepper motor with a 1.8 deg full step angle and a ±5% step angle tolerance, this unit incorporates an optical incremental encoder with an RS422 TTL A/B channels and zero index rotor position sensor interface. It is built with a plain-bearing guide for torsion protection, an external thread M8 piston rod end, and operates at a maximum acceleration of 10 m/s² in any mounting position. Submit the exact part number, quantity, and application requirements to receive a formal quote.
View product details →
Festo
The Festo part number 1489956 is a pilot-controlled piston poppet valve featuring a 2/2-way closed monostable function with soft sealing and a G3/8 fitting connection. Designed for in-line installation with the coil preferably on top, this electrical component accommodates compressed air, inert gas, and neutral liquids through a 13 mm nominal width with a non-reversible flow direction. It operates on 110 V AC at 50/60 Hz with class H insulation, a 100% duty cycle, and a nominal pressure PN of 40. Request a quote by submitting the exact part number, quantity, and application requirements.
View product details →
Festo
The Festo 1492022 is an electrically actuated, directly operated poppet valve featuring a 2/2-way closed monostable configuration with a soft sealing principle and a 2 mm nominal width. Designed for in-line installation in any mounting position, this non-reversible component utilizes a 1/8 NPT fitting connection and operates on a 230 V AC (50/60 Hz) electrical supply via a Type A plug conforming to EN 175301-803. It handles media including compressed air, inert gas, mineral oil, water, and neutral liquids at a nominal pressure of 100 PN with zero pressure difference, while utilizing a mechanical spring reset and maintaining a 100% duty cycle within an insulation class F rating. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo 1492312 is a 2/2-way closed monostable force pilot-operated diaphragm valve featuring a soft sealing principle and a nominal width of 13.5 mm for in-line installation with a G1/2 fitting connection. Actuated electrically via a Type A rectangular plug complying with EN 175301-803, the component operates on 230 V AC (50/60 Hz) with an initial power of 18.0 VA, a holding power of 15.0 VA, and permissible voltage fluctuations of +/- 10%. It handles a medium pressure range of 0 bar to 10 bar (0 MPa to 1 MPa, 0 psi to 145 psi), a nominal fitting pressure PN of 40, and zero differential pressure across compressed air as per ISO 8573-1:2010 [7:-:-], inert gas, mineral oil, water, and neutral liquids with an upright magnet mounting position and non-reversible flow direction. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo 1470775 is an electric actuator with a ball screw drive featuring a size 25 format, a 200 mm stroke, and 0 mm stroke reserve. This unit integrates a stepper motor with a 1.8 deg full step angle, a ±5% step angle tolerance, an incremental optical rotor position sensor with an RS422 TTL A/B channels plus zero index interface, and a plain-bearing guide providing torsion protection with a maximum piston rod rotation angle of +/- 1.5 deg. Driven by a 10 mm diameter and 10 mm/U pitch screw with an M8 external thread piston rod end, it achieves a maximum acceleration of 10 m/s², a reversing backlash of 0,1 mm, and supports any mounting position. Submit the exact part number, quantity, and application requirements for an RFQ.
View product details →
Festo
The Festo part number 1489955 is a pilot-controlled piston poppet valve featuring a 2/2-way, closed, monostable valve function with soft sealing and a 13 mm nominal width. This electrical component utilizes Type A plug connections per EN 175301-803 and operates on 110 V AC (50/60 Hz) with an insulation class H coil, maintaining a 100% duty cycle and a PN 40 nominal pressure rating for compressed air, inert gas, and neutral liquids. Featuring in-line installation with G1/4 fitting connections and a non-reversible flow direction, it requires a 0.05 MPa (0.5 bar / 7.25 psi) pressure difference with no manual override. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 1492021 is a directly actuated poppet valve featuring a 2/2-way, closed, monostable function with a soft sealing principle and a 1.5 mm nominal width. This electrical component supports in-line installation in any mounting position with a 1/8 NPT fitting connection and a non-reversible flow direction, operating via a 230 V AC coil at 50/60 Hz with class F insulation and a 100% duty cycle. It accommodates compressed air, inert gas, mineral oil, water, and neutral liquids up to a nominal pressure PN of 100 with zero differential pressure, utilizing a mechanical spring reset method and a Type A plug electrical connection according to EN 175301-803. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo part number 1492311 is a force pilot operated diaphragm valve featuring a 2/2-way, closed, monostable function with a soft sealing principle and a 13.5 mm nominal width. This electrical component provides in-line installation via a G3/8 fitting connection and operates with an upright magnet mounting position for non-reversible flow of compressed air, inert gas, mineral oil, water, neutral liquids, and other flow media on request up to a medium pressure of 10 bar and a fitting nominal pressure PN of 40. It utilizes a 230 V AC 50/60 Hz electrical connection of type A, plug, as per EN 175301-803 in a rectangular design with coil characteristics of 18.0 VA initial power and 15.0 VA holding power, subject to permissible voltage fluctuations of +/- 10%. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo 1470773 is an electric actuator featuring a ball screw drive with a size of 25, a 150 mm stroke, and a 10 mm screw diameter with a 10 mm/U spindle pitch. It utilizes a stepper motor paired with an optical incremental encoder featuring an RS422 TTL A/B channels and zero index interface, delivering a 1.8-degree step angle with a ±5% tolerance and a maximum acceleration of 10 m/s². Equipped with a plain-bearing guide for torsion protection and an M8 external thread piston rod end, the unit supports any mounting position and maintains a reversing backlash of 0.1 mm alongside a maximum piston rod rotation angle of ±1.5 degrees. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo 1489954 is an electrical, pilot-controlled piston poppet valve featuring a soft sealing principle and a 25 mm nominal width in a 2/2-way, closed, monostable configuration with non-reversible flow direction. Designed for in-line installation with a G1 fitting connection and a coil preferably mounted on top, it operates via piloted control with a PN 40 nominal pressure fitting, a 0.5 bar differential pressure, and a 100% duty cycle coil rated at 110 V AC (50/60 Hz) with Class H insulation. Media compatibility includes compressed air conforming to ISO 8573-1:2010 [7:4:4], inert gas, neutral liquids, and other flow media available upon request through Type A EN 175301-803 rectangular plug electrical connections. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 1492020 is a directly actuated poppet valve featuring a soft sealing principle and a 2/2-way, closed, monostable valve function with a 1 mm nominal width. This electrical component operates via a 230 V AC coil at 50/60 Hz with class F insulation, a 100% duty cycle, and mechanical spring reset, supporting a nominal pressure of 100 bar and zero differential pressure. It utilizes 1/8 NPT fitting connections, Type A rectangular electrical connection per EN 175301-803, and accommodates compressed air, inert gas, mineral oil, water, and neutral liquids in any mounting position. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this component.
View product details →
