Industrial sourcing catalog
Browse verified product records and request commercial availability, lead time and technical documentation.
Festo
The Festo 14155 is a double-acting industrial component featuring a 63 mm piston diameter, a 40 mm stroke, and a single-ended piston rod with an M16x1,5 male thread. Operating within a pressure range of 0.4 to 12 bar and temperatures from -20 to 80 °C, this ISO 6431 compliant unit delivers theoretical forces of 1,761 N on advance stroke and 1,601 N on return stroke at 6 bar. It incorporates adjustable pneumatic cushioning at both ends with a 23 mm cushioning length, provision for proximity sensors, and a CRC 2 corrosion resistance classification, while operating on dried compressed air that is lubricated or unlubricated in any assembly position. Submit the exact part number, quantity, and application requirements to request a quote for this component.
View product details →
Festo
The Festo 1385610 is a round, flat industrial component featuring a 10 mm suction cup diameter, an effective suction cup diameter of 8.2 mm, and an M5 vacuum connection positioned at the top. Designed for any mounting position, this transparent 2 g part delivers a holding force of 3.7 N at a nominal operating pressure of -0.07 MPa within an operating pressure range of -0.095 MPa to 0 MPa. It operates with atmospheric air based on ISO 8573-1:2010 [7:-:-], accommodates ambient temperatures from -40 °C to 200 °C, and features a corrosion resistance class of 2 alongside VDMA24364 Zone III LABS conformity. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 1366953 is a double-acting industrial component featuring a 50 mm piston diameter, a 125 mm stroke, and an M16x1.5 external piston rod thread conforming to ISO 15552. Built with a profile barrel structural design, it operates at pressures ranging from 0.04 MPa to 1.2 MPa using compressed air per ISO 8573-1:2010 [7:4:4] and includes adjustable pneumatic cushioning at both ends with a 22 mm cushioning length. This unit offers position sensing via proximity switch, an ambient temperature range of -20 °C to 80 °C, moderate corrosion resistance class 2, and ISO 14644-1 Class 5 cleanroom suitability. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
The Festo 14154 is a double-acting industrial component featuring a 63 mm piston diameter and a 25 mm stroke with an M16x1,5 male piston rod thread. Built to ISO 6431 standards with a single-ended piston rod design and position detection capability for proximity sensors, it operates within a 0.4 to 12 bar pressure range utilizing dried compressed air. This unit incorporates adjustable pneumatic cushioning at both ends (PPV) across a 23 mm cushioning length, delivering a theoretical force of 1,761 N on the advance stroke and 1,601 N on the return stroke at 6 bar. Designed for any assembly position within an ambient temperature range of -20 to 80 °C, it features a CRC 2 corrosion resistance classification, Germanischer Lloyd authorization, and weighs an additional 57 g per 10 mm of stroke. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo 1384901 is a double-acting industrial component featuring a 100 mm piston diameter, a 500 mm stroke, and an M20x1.5 external piston rod thread conforming to ISO 15552. Built with a piston, piston rod, and profile barrel structural design, this variant includes self-adjusting pneumatic end-position cushioning, position sensing via proximity switch, and an operating pressure range of 0.04 MPa to 1.2 MPa. It delivers a theoretical retracting force of 4418 N at 6 bar while operating within an ambient temperature range of -20 °C to 80 °C using compressed air as per ISO 8573-1:2010 [7:4:4]. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 1366952 is a double-acting industrial component featuring an ISO 15552 profile barrel design with a 50 mm piston diameter, a 100 mm stroke, and an M16x1.5 external piston rod thread at one end. It operates within a pressure range of 0.04 MPa to 1.2 MPa using compressed air according to ISO 8573-1:2010 [7:4:4], and incorporates adjustable pneumatic cushioning at both ends with a 22 mm cushioning length and 1 J end-position impact energy. Configurable in any mounting position for ambient temperatures from -20 °C to 80 °C, this unit provides position sensing via proximity switch, moderate corrosion resistance (CRC 2), and cleanroom suitability conforming to ISO 14644-1 Class 5. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo part number 14153 is a double-acting industrial component featuring a 63 mm piston diameter, an M16x1,5 male piston-rod thread, and a stroke range from 1 to 2,000 mm. Built to ISO 6431 with a single-ended piston rod and piston-rod design structure, it operates on dried compressed air at pressures from 0.4 to 12 bar across an ambient temperature range of -20 to 80 °C. This unit incorporates adjustable pneumatic cushioning at both ends with a 23 mm cushioning length, provision for proximity sensor position detection, and Germanischer Lloyd authorization. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
The Festo part number 1384900 is a double-acting industrial component featuring a 100 mm piston diameter, a 400 mm stroke, and an M20x1.5 external piston rod thread conforming to ISO 15552 standards. Built with a profile barrel structural design, it operates at pressures from 0.04 MPa to 1.2 MPa using compressed air per ISO 8573-1:2010 [7:4:4] and provides self-adjusting pneumatic end-position cushioning with a cushioning length of 31 mm. This unit supports any mounting position, achieves a theoretical retracting force of 4418 N at 6 bar, and includes position sensing via proximity switch within an ambient temperature range of -20 °C to 80 °C. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
The Festo 14152 is a double-acting industrial component featuring a 50 mm piston diameter, a 300 mm stroke, and an ISO 6431 conformance design. Operating within a pressure range of 0.5 to 12 bar and an ambient temperature range of -20 to 80 °C, this unit delivers a theoretical advance stroke force of 1,131 N and return stroke force of 924 N at 6 bar. It incorporates adjustable pneumatic cushioning at both ends, a male M16x1,5 piston rod thread, and position detection capabilities for proximity sensors. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 1366951 is a double-acting industrial component featuring a 50 mm piston diameter, an 80 mm stroke, and an M16x1.5 piston rod thread with an external thread end. Built with a piston, piston rod, and profile barrel structural design conforming to ISO 15552, this unit operates within a pressure range of 0.04 MPa to 1.2 MPa and includes adjustable pneumatic cushioning at both ends. It supports position sensing via proximity switch, operates in any mounting position across an ambient temperature range of -20 °C to 80 °C, and achieves ISO 14644-1 Class 5 cleanroom suitability with a moderate corrosion resistance class of 2. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
The Festo 1415120 is a round, flat industrial component featuring a 125 mm suction cup diameter, an effective suction cup diameter of 112.8 mm, and a 6 mm suction cup height compensation. It operates within a pressure range of -0.095 MPa to 0 MPa, delivering a holding force of 700 N at a nominal operating pressure of -0.07 MPa, with atmospheric air as the operating medium per ISO 8573-1:2010 [7:-:-]. Weighing 214 g with a G3/8 vacuum connection, this transparent component has a moderate corrosion stress rating (CRC 2) and functions within an ambient temperature range of -40 °C to 200 °C. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo part number 1384899 is a double-acting industrial component featuring a 100 mm piston diameter and a 320 mm stroke, conforming to ISO 15552 with a profile barrel structural design. This unit operates within a pressure range of 0.04 MPa to 1.2 MPa utilizing compressed air as per ISO 8573-1:2010 [7:4:4] and incorporates self-adjusting pneumatic end-position cushioning with a cushioning length of 31 mm. It achieves a theoretical retraction force of 4418 N at 6 bar while providing position sensing via proximity switch and an ambient temperature range of -20 °C to 80 °C. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
The Festo 1366950 is a double-acting industrial component featuring a 50 mm piston diameter, a 50 mm stroke, and an M16x1.5 external piston rod thread conforming to ISO 15552. Designed with a profile barrel, piston, and single-end piston rod, it operates within a pressure range of 0.04 MPa to 1.2 MPa and includes adjustable pneumatic cushioning at both ends with a 22 mm cushioning length. This unit supports position sensing via proximity switch, functions within an ambient temperature range of -20 °C to 80 °C, and exhibits a moderate corrosion resistance class of CRC 2. Submit the exact part number, quantity, and application requirements to receive a quote.
View product details →
Festo
The Festo part number 14151 is a double-acting industrial component featuring a 50 mm piston diameter, a 250 mm stroke, and an M16x1,5 male piston-rod thread with a single-ended design conforming to ISO 6431. This unit operates within a 0.5 to 12 bar pressure range using dried compressed air, delivering a theoretical return force of 924 N and advance force of 1,131 N at 6 bar. It incorporates adjustable pneumatic cushioning at both ends with a 23 mm cushioning length, position detection for proximity sensors, and a CRC 2 corrosion resistance classification for ambient temperatures between -20 and 80 °C. Submit the exact part number, quantity, and application requirements for a formal quote.
View product details →
Festo
The Festo part number 1384898 is a double-acting industrial component featuring a 100 mm piston diameter, a 250 mm stroke, and an M20x1.5 external piston rod thread conforming to ISO 15552. This profile barrel unit operates within a pressure range of 0.04 MPa to 1.2 MPa and delivers a theoretical retracting force of 4418 N at 6 bar utilizing compressed air per ISO 8573-1:2010 [7:4:4]. Equipped with self-adjusting pneumatic end-position cushioning, position sensing via proximity switch, and a moderate corrosion resistance class (CRC 2), it functions across an ambient temperature range of -20 °C to 80 °C in any mounting position. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo 1366949 is a double-acting industrial component featuring a 50 mm piston diameter, a 40 mm stroke, and an M16x1.5 external piston rod thread conforming to ISO 15552. Built with a profile barrel structural design, this unit operates within a pressure range of 0.04 MPa to 1.2 MPa and includes adjustable pneumatic cushioning at both ends with a 22 mm cushioning length. It accommodates compressed air media per ISO 8573-1:2010 [7:4:4], offers position sensing via proximity switch, and achieves ISO 14644-1 Class 5 cleanroom suitability alongside a moderate corrosion resistance class (CRC) of 2. Submit the exact part number, quantity, and application requirements to receive a quote.
View product details →
Festo
The Festo part number 14150 is a double-acting industrial component featuring a 50 mm piston diameter, a 200 mm stroke, and an M16x1,5 male piston-rod thread. Built with a single-ended piston rod in a piston and piston rod design structure, this unit conforms to ISO 6431 and includes adjustable pneumatic cushioning at both ends with a 23 mm cushioning length. It operates within a pressure range of 0.5 to 12 bar using dried compressed air, delivering a theoretical force of 1,131 N on the advance stroke and 924 N on the return stroke at 6 bar. Designed for any assembly position with position detection for a proximity sensor, the component has a CRC 2 corrosion resistance classification, an ambient temperature range of -20 to 80 °C, Germanischer Lloyd authorization, and an additional weight of 48 g per 10 mm of stroke. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 100 mm piston diameter industrial component with a 200 mm stroke operates in a double-acting mode using compressed air as per ISO 8573-1:2010 [7:4:4] within an operating pressure range of 0.04 MPa to 1.2 MPa. Conforming to ISO 15552, the profile barrel unit features self-adjusting pneumatic end-position cushioning, position sensing via proximity switch, and an external M20x1.5 piston rod thread delivering a theoretical retracting force of 4418 N at 6 bar. This model achieves moderate corrosion resistance (CRC 2) and functions within an ambient temperature range of -20 °C to 80 °C in any mounting position. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo 14149 is a double-acting industrial component featuring a 50 mm piston diameter, a 160 mm stroke, and a male M16x1,5 piston-rod end. Designed with a single-ended piston rod and position detection for proximity sensors, it operates on dried compressed air within a 0.5 to 12 bar pressure range and a -20 to 80 °C ambient temperature range. This unit conforms to ISO 6431, incorporates adjustable pneumatic cushioning at both ends (PPV), and delivers a theoretical force of 1,131 N on the advance stroke and 924 N on the return stroke at 6 bar. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
The Festo 1366948 is a double-acting industrial component featuring a 50 mm piston diameter, a 25 mm stroke, and an M16x1.5 piston rod thread with an external thread end. Built with a profile barrel, piston, and single-ended piston rod, this ISO 15552-conforming cylinder operates within a pressure range of 0.04 MPa to 1.2 MPa and includes adjustable pneumatic cushioning at both ends. It provides position sensing via proximity switch, operates across an ambient temperature range of -20 °C to 80 °C, and meets ISO 14644-1 Cleanroom Class 5 standards with a CRC rating of 2. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
