Industrial sourcing catalog
Browse verified product records and request commercial availability, lead time and technical documentation.
Festo
This Festo double-acting industrial component features a 100 mm piston diameter, a 160 mm stroke, and an M20x1.5 external piston rod thread conforming to ISO 15552. Built with a profile barrel structural design, it operates between 0.04 MPa and 1.2 MPa utilizing compressed air per ISO 8573-1:2010 [7:4:4] and incorporates self-adjusting pneumatic end-position cushioning with a 31 mm cushioning length. The unit delivers a theoretical retracting force of 4418 N at 6 bar while supporting any mounting position and position sensing via proximity switch within a -20 °C to 80 °C ambient temperature range. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo part number 14148 is a double-acting industrial component featuring a 50 mm piston diameter and a 125 mm stroke with a single-ended male M16x1,5 piston rod thread. Conforming to ISO 6431, this unit operates within a 0.5 to 12 bar pressure range using dried compressed air and delivers theoretical forces of 1,131 N on the advance stroke and 924 N on the return stroke at 6 bar. It incorporates adjustable pneumatic cushioning at both ends with a 23 mm cushioning length, provision for proximity sensor position detection, and a CRC 2 corrosion resistance classification for ambient temperatures between -20 and 80 °C. Request a quote for Festo part number 14148 by submitting your exact quantity and application requirements.
View product details →
Festo
The Festo 1366842 is an industrial component operating at a nominal AC voltage of 400 V with an integrated mains filter, a nominal controller power of 12,000 VA, and a nominal output current of 20 A across an output frequency range of 0 to 1,000 Hz. It features Safe Torque Off (STO) providing SIL 2 and category 3, performance level d functionality, alongside a seven-segment display, a 47 Ohm braking resistance with a 12 kVA pulse power, and an RS232 parameters configuring interface supporting 9,600 to 115,000 Bits/s. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo 14147 is a double-acting industrial component featuring a 50 mm piston diameter, a 100 mm stroke, and a single-ended piston rod with an M16x1,5 male thread conforming to ISO 6431. Built for an operating pressure range of 0.5 to 12 bar and ambient temperatures between -20 and 80 °C, this unit operates on dried compressed air and incorporates adjustable pneumatic cushioning at both ends. It delivers a theoretical force of 1,131 N on the advance stroke and 924 N on the return stroke at 6 bar, while including position detection capabilities for proximity sensors and Germanischer Lloyd authorization. Submit the exact part number, quantity, and application requirements to receive a formal quote.
View product details →
Festo
The Festo 1384895 is a double-acting industrial component featuring a 100 mm piston diameter, a 125 mm stroke, and an M20x1.5 external piston rod thread conforming to ISO 15552. Constructed with a profile barrel, piston, and single-end piston rod, it operates on compressed air within a 0.04 MPa to 1.2 MPa pressure range and incorporates self-adjusting pneumatic end-position cushioning with a 31 mm cushioning length. The unit supports any mounting position, operates in ambient temperatures between -20 °C and 80 °C, and provides position sensing via proximity switch alongside a theoretical retracting force of 4418 N at 6 bar. Submit the exact part number, quantity, and application requirements to request a quote for this Festo component.
View product details →
Festo
The Festo industrial component, part number 1366257, is a straight design fitting featuring a 2.9 mm nominal width and a sealing ring on the screwed plug for mounting in any position. It operates across a pressure range of -0.095 MPa to 1.2 MPa for compressed air and handles water up to 0.6 MPa at 0 to 85 °C, with a maximum operating temperature of 120 °C for water vapor. Built with a corrosion resistance class of 4, IP69K degree of protection, and reduced Cu/Zn/Ni values suitable for Li-ion battery production, this 14.1 g part requires a nominal tightening torque of 6.5 Nm. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
This Festo 14146 double-acting industrial component features a 50 mm piston diameter, an 80 mm stroke, and an M16x1,5 male piston-rod thread with a single-ended piston rod design structure. It operates within a 0.5 to 12 bar pressure range on dried compressed air, delivering a theoretical force of 1,131 N on the advance stroke and 924 N on the return stroke at 6 bar. Configured with adjustable pneumatic cushioning at both ends, a 23 mm cushioning length, and position detection for proximity sensors, it conforms to ISO 6431 and carries Germanischer Lloyd authorization with CRC 2 corrosion resistance for ambient temperatures between -20 and 80 °C. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 1364705 is a Size 186 fiber filter from the L series featuring a manual condensate drain and a 0.01 µm filtration grade for compressed air and inert gases within an operating pressure range of 0 MPa to 5 MPa. It achieves a 99.99998% filter efficiency with a maximum standard flow rate of 10220 l/min and a minimum standard flow rate of 3406 l/min, delivering output air quality as per ISO 8573-1:2010 [1:4:2] while maintaining a maximum condensate volume of 200 cm³. Designed for a medium and ambient temperature range of 5 °C to 60 °C, this component exhibits a moderate corrosion resistance class of CRC 2 and complies with the EU pressure equipment directive. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo 100 mm piston diameter double-acting industrial component features a 100 mm stroke, an M20x1.5 external thread piston rod, and a profile barrel structural design conforming to ISO 15552. Operating between 0.04 MPa and 1.2 MPa with compressed air as per ISO 8573-1:2010 [7:4:4], this unit provides self-adjusting pneumatic end-position cushioning, position sensing via proximity switch, and a theoretical retracting force of 4418 N at 6 bar. It functions in any mounting position within an ambient temperature range of -20 °C to 80 °C, exhibits a corrosion resistance class of 2, and accommodates oil lubrication. Submit the exact part number, quantity, and application requirements to request a formal quote.
View product details →
Festo
The Festo 14145 is a double-acting industrial component featuring a 50 mm piston diameter and a 50 mm stroke with an M16x1,5 male piston rod thread, operating at pressures from 0.5 to 12 bar using dried compressed air. Conforming to ISO 6431, this single-ended piston rod design incorporates adjustable pneumatic cushioning at both ends (PPV), a 23 mm cushioning length, position detection for proximity sensors, and Germanischer Lloyd authorization. It delivers a theoretical force of 1,131 N on the advance stroke and 924 N on the return stroke at 6 bar across an ambient temperature range of -20 to 80 °C with a CRC 2 corrosion resistance classification. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 1362229 is an industrial component featuring a size 86 frame, a 1:1 gear ratio, and a transferable torque of 9.5 Nm with a 0.25 Nm no-load driving torque. This RoHS compliant part includes actuator interface code D40B, motor-in interface code 88A, a mass moment of inertia of 175 kgmm², and a product weight of 2490 g. It offers an IP40 degree of protection, any mounting position, VDMA24364 Zone III LABS conformity, and operates in ambient temperatures from -10 °C to 60 °C while withstanding storage temperatures between -25 °C and 60 °C and relative air humidity up to 95% at a maximum rotational speed of 5000 rpm. Submit the exact part number, quantity, and application requirements to receive a quote.
View product details →
Festo
This Festo industrial component (Part Number: 1384893) is a double-acting pneumatic cylinder featuring an 80 mm stroke, a 100 mm piston diameter, and an M20x1.5 external piston rod thread on one end. Built with a profile barrel structural design conforming to ISO 15552, it operates at pressures from 0.04 MPa to 1.2 MPa (0.4 bar to 12 bar) using compressed air as per ISO 8573-1:2010 [7:4:4]. The unit includes self-adjusting pneumatic end-position cushioning with a 31 mm cushioning length, position sensing via proximity switch, and delivers a theoretical retracting force of 4418 N at 6 bar. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
The Festo part number 14144 is a double-acting industrial component featuring a 50 mm piston diameter and a 40 mm stroke, operating within a pressure range of 0.5 to 12 bar using dried compressed air. Conforming to ISO 6431, this unit incorporates adjustable pneumatic cushioning at both ends (PPV), a male M16x1,5 piston rod thread, position detection capability for proximity sensors, and a CRC 2 corrosion resistance classification for ambient temperatures between -20 and 80 °C. Submit the exact part number, quantity, and application requirements to receive a quote.
View product details →
Festo
The Festo 1361879 is an industrial component featuring a wrought aluminum alloy manifold rail with a width dimension of 12 mm and a product weight of 2060 g. This assembly accommodates a maximum of 35 valve positions and includes G1/4 pneumatic connections for ports 1, 3, and 5. It is rated for corrosion resistance class 0 with no corrosion stress, VDMA24364-B1/B2-L LABS conformity, and RoHS compliant materials, utilizing a maximum tightening torque of 0.6 Nm for valve mounting and 5 Nm for wall mounting. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
This Festo industrial component features a 100 mm piston diameter, a 50 mm stroke, an M20x1.5 external piston rod thread, and conforms to ISO 15552. Operating with double-acting compressed air within a 0.04 MPa to 1.2 MPa range, the profile barrel unit incorporates self-adjusting pneumatic end-position cushioning and position sensing via proximity switch. It offers an ambient temperature range of -20 °C to 80 °C, a corrosion resistance class of CRC 2, and delivers a theoretical retracting force of 4418 N at 6 bar. Submit the exact part number, quantity, and application requirements to request a formal quote.
View product details →
Festo
The Festo 14143 is a double-acting industrial component featuring a 50 mm piston diameter, a 25 mm stroke, and a single-ended piston rod with an M16x1,5 male thread adhering to ISO 6431 standards. This unit operates within a 0.5 to 12 bar pressure range using dried compressed air, delivering a theoretical force of 1,131 N on the advance stroke and 924 N on the return stroke at 6 bar. Configurable in any assembly position, it includes adjustable pneumatic cushioning at both ends with a 23 mm cushioning length, proximity sensor position detection, and Germanischer Lloyd authorization. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
The Festo 1361878 is an industrial component featuring a wrought aluminum alloy manifold rail with a width dimension of 12 mm and a product weight of 1907 g. This unit accommodates a maximum of 32 valve positions, incorporates G1/4 pneumatic connections for ports 1, 3, and 5, and meets RoHS material compliance with a CRC rating of 0 and VDMA24364-B1/B2-L LABS conformity. Installation requires a maximum tightening torque of 0.6 Nm for valve mounting and 5 Nm for wall mounting. Submit the exact part number, quantity, and application requirements to request a quote for this item.
View product details →
Festo
The Festo part number 14142 is a double-acting industrial component featuring a 50 mm piston diameter, a single-ended piston rod with an M16x1,5 male thread, and a stroke length ranging from 1 to 2,000 mm conforming to ISO 6431. Operating at pressures between 0.5 and 12 bar using dried compressed air, this unit achieves theoretical forces of 1,131 N on the advance stroke and 924 N on the return stroke at 6 bar. It incorporates adjustable pneumatic cushioning at both ends with a 23 mm cushioning length, position detection for proximity sensors, and a corrosion resistance classification of CRC 2 for ambient temperatures from -20 to 80 °C in any assembly position. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
This Festo industrial component, part number 1384891, is a double-acting ISO 15552 standard cylinder featuring a 100 mm piston diameter, a 40 mm stroke, and an M20x1.5 external piston rod thread at one end within a profile barrel structural design. It operates on compressed air per ISO 8573-1:2010 [7:4:4] within a 0.4 bar to 12 bar pressure range, delivering a theoretical retracting force of 4418 N at 6 bar while utilizing self-adjusting pneumatic end-position cushioning across a 31 mm cushioning length. The unit accommodates any mounting position, incorporates position sensing via proximity switch, and maintains a corrosion resistance class of 2 within an ambient temperature range of -20 °C to 80 °C. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 1361877 is a wrought aluminum alloy manifold rail with a width dimension of 12 mm and a product weight of 1704 g, configured to support a maximum of 28 valve positions. It features G1/4 pneumatic connections for ports 1, 3, and 5, alongside a corrosion resistance class (CRC) rating of 0 for no corrosion stress and VDMA24364-B1/B2-L LABS conformity with RoHS compliant materials. Installation requires a maximum tightening torque of 0.6 Nm for valve mounting and 5 Nm for wall mounting. Submit the exact part number, quantity, and application requirements to receive a quote for this component.
View product details →
