Festo
8034239
Integrated Drive EMCA-EC-67-M-1TE-CO
The Festo part number 8034239 is an industrial component featuring a 24 V nominal DC voltage, a 150 W nominal motor power, a nominal current of 7.2 A, and a maximum speed of 3,300 1/min with a nominal rotary speed of 3,150 1/min. Driven by a PWM-MOSFET power output stage with cascade, P position, PI speed, and proportional-integral electricity controllers, this unit utilizes a magnetic absolute single-turn encoder for rotor position sensing. Integrated safety and protective functions include Safe Torque Off (STO) meeting SIL 2 and category 3, performance level d, alongside I²t monitoring, temperature and current monitoring, voltage failure detection, drag error monitoring, software end-position detection, and an external 6 Ohm braking resistor. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
