Festo
533887
Push-in fitting QS-F-G3/8-12H
The Festo 533887 is a standard industrial component featuring a 10 mm nominal size and a push/pull design structure with a sealing ring on the screw-in stud. Constructed with a chromium- and nickel-plated brass housing, FPM thread and tubing seals, and a 23.6 g product weight, this part accommodates compressed air per ISO8573-1:2010 [7:-:-] across an operating pressure range of -0.95 to 16 bar and an ambient temperature range of 0 to 150 °C. It provides port 2 for 12 mm outside diameter tubing, supports lubricated operation, achieves a CRC 3 corrosion resistance classification, complies with RoHS materials notes, includes food safety to the manufacturer's declaration, holds Germanischer Lloyd authorization, and withstands a maximum tightening torque of 25 Nm. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
