Palazzoli
The Palazzoli 720126 is a mobile 16A connector with a cable gland for quick mounting, operating at 230V and 50/60Hz with a 2P+ configuration and a 6h clock position. Constructed from recyclable Palazzoli technopolymer with an IK08 shock resistance and IP44 protection degree, this unit accommodates conductor sections from 1mm² to 6mm² and tightening diameters between 8 and 13 mm. Featuring dimensions of 70x50x135 mm, a net weight of 0.12 kg, and a rated insulation voltage of 690V, the item carries EAN code 8014950000876 with a minimum order quantity of 30 units. Submit part number 720126, your required quantity, and application details to receive a formal quotation.
View product details →
Palazzoli
The Palazzoli 720144 is a mobile 16A connector with a cable gland for quick mounting, operating at 50-60Hz with a rated voltage of 110V and a 3P+N+ pole configuration at a 4h clock position. Constructed from recyclable Palazzoli technopolymer with dimensions of 85x70x155 mm and a net weight of 0.20 kg, this IP44-rated and IK08 shock-resistant component accommodates conductor sections from 1 mm² to 6 mm² and tightening diameters between 10 and 15.5 mm. Please submit the exact part number 720144, quantity starting from the 5-piece minimum order, and your application requirements to request a quote.
View product details →Palazzoli
The Palazzoli 720134 is a mobile 16A connector with an integrated cable gland for quick mounting, operating at 110V and 50-60Hz with 3P+ poles in a 4h clock position. Constructed from recyclable Palazzoli technopolymer, this IP44-rated and IK08 shock-resistant component accommodates conductor sections from 1mm² to 6mm² and tightening diameters between 8.5 and 14 mm. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
The Palazzoli 720124 is a mobile 16A connector with integrated cable gland featuring a 110V rated operating voltage, 2P+ poles, and a 4h clock position configured for 50-60Hz frequencies. Constructed from recyclable Palazzoli technopolymer, this IP44-rated and IK08 shock-resistant component accommodates conductor sections from 1mm² to 6mm² with a tightening diameter of 8 to 13 mm. Measuring 70x55x140 mm with a net weight of 0.12 kg, the unit requires a minimum order quantity of 5 pieces. Submit part number 720124, quantity, and application requirements to receive a formal quotation.
View product details →
Palazzoli
The Palazzoli 705126 is a mobile 16A plug with a cable gland for quick mounting, featuring a 2P+ configuration, a 230V rated operating voltage at 50-60Hz, and a 6h clock position in black technopolymer recyclable material. Measuring 55x55x130 mm with a net weight of 0.11 KG, it accommodates conductor sections from 1 mm² to 6 mm², tightening diameters of 8 to 13 mm, and provides an IP44 protection degree with IK08 shock resistance. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Palazzoli
The Palazzoli 725126 is a mobile 16A connector with a cable gland for quick mounting, rated for 230V operating voltage and 690V insulation voltage at a 50-60Hz frequency. Constructed from recyclable Palazzoli technopolymer in black, this 2P+ component features a 6h clock position, IP44 protection degree, and IK08 shock resistance according to IEC/EN 62262, accommodating conductor sections from 1mm² to 6mm² with a tightening diameter of 8 to 13 mm. Each unit weighs 0.12 kg with dimensions of 70x50x140 mm, and the item carries a minimum order quantity of 10. Submit part number 725126, required quantity, and application specifications to request a formal quote.
View product details →
Palazzoli
The Palazzoli 638042 is an IP65-rated universal foldable distribution board with a net weight of 11.52 kg and a rated current of 32A at 50/60Hz, providing 18 kW of power through an MCB 4P 32A switch and 40A 4P 30mA differential protection. It features a 3P+N+T 32A power plug, four industrial socket-outlets at 16A 2P+E, four industrial socket-outlets at 16A 3P+E, and 4P poles, while offering an IK08 shock resistance alongside an operating ambient temperature range of -20°C to +40°C and a storage range of -30°C to +70°C. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
The Palazzoli 638041 is a foldable universal distribution board rated for 6 kW at 230V and 50/60Hz with a 32A rated current and 4P poles. It features eight 16A 2P+E industrial socket-outs, a 2P+T 32A power plug, an MCB 2P - 32A switch type, and a 32A 2P 30mA differential protection, all housed within an IP65 and IK08 shock-resistant enclosure capable of operating between -20°C and +40°C. With a net weight of 10.15 kg and gross weight of 10.37 kg, this unit supports storage temperatures from -30°C to +70°C and carries EAN code 8014950060368. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
The Palazzoli 638040 is a universal foldable distribution board rated for 6 kW at 32A and 50/60Hz, featuring an IP65 protection degree and IK08 shock resistance. This 2P assembly includes an MCB 2P 32A switch, a 32A 2P 30mA differential protection device, a 2P+T 32A power plug, four 16A 2P+E industrial socket-outlets, and four 2P+E 10/16 domestic socket-outlets with a net weight of 10.21 KG. It operates in ambient temperatures from -20°C to +40°C and withstands storage temperatures between -30°C and +70°C. Submit the exact part number, quantity, and application requirements for a formal quote.
View product details →
Palazzoli
The Palazzoli 634110 is a 10KG foldable universal distribution board featuring an IP65 protection degree, IK08 shock resistance, and a 6 kW power capacity rated for 230V at 50/60Hz. It incorporates a 32A 2P MCB switch, a 32A 2P 30mA differential protection, three interlocked 16A 2P+E 230V socket-outlets, one domestic 2P+E 10/16 socket-outlet, and a power terminal block operating between -20°C and +40°C. Submit the exact part number, quantity, and application requirements to request a quote for this 2P rated unit.
View product details →Palazzoli
The Palazzoli 634106 is a foldable universal distribution board rated at 18 kW and 32A for 50/60Hz operations, featuring an IP65 protection degree and IK08 shock resistance according to IEC/EN 62262. This 4-pole unit includes an MCB 4P 32A switch type, a 40A 4P 30mA differential protection, a power terminal block, and four interlocked socket-outlets comprising two 16A 2P+E 230V, one 16A 3P, and one 32A 3P connection. Engineered with a net weight of 10.60 KG, it operates within an ambient temperature range of -20°C to +40°C and stores between -30°C and +70°C. Submit the exact part number, quantity, and application requirements to request a quote for this distribution board.
View product details →Palazzoli
The Palazzoli 634105 is a foldable universal distribution board rated for an 18 kW power capacity at 400V and 50/60Hz, featuring four interlocked socket-outlets with a power terminal block and MCB protection. This 32A, 4P unit includes two 16A 2P+E 230V interlocked socket-outlets, one 16A 3P interlocked socket-outlet, an MCB 4P 32A switch type, and a 40A 4P 30mA differential protection device. Built to an IP65 protection degree with an IK08 shock resistance rating, the assembly operates in ambient temperatures ranging from -20°C to +40°C and has a net weight of 9.50 kg. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →Palazzoli
The Palazzoli 634104 is a universal foldable distribution board rated for an 18 kW power capacity at 400V and 50/60Hz, featuring an IP65 protection degree and IK08 shock resistance. This 32A, 4P unit includes an MCB 4P 32A switch, a 40A 4P 30mA differential protection, a power terminal block, and four interlocked socket-outlets comprising two 16A 2P+E 230V sockets and two 16A 3P sockets. Operating within an ambient temperature range of -20°C to +40°C and storage limits from -30°C to +70°C, the assembly has a net and gross weight of 9.50 kg. Please submit the exact part number, quantity, and application requirements to receive a formal quotation for this Palazzoli distribution board.
View product details →Palazzoli
The Palazzoli 634102 is a universal foldable distribution board with a rated operating voltage of 400V, a rated current of 32A, and a power capacity of 18 kW at 50/60Hz. It features four interlocked socket-outlets comprising three 16A 2P+E 230V sockets and one 16A 3P socket, integrated with a power terminal block, an MCB 4P 32A switch, and 40A 4P 30mA differential protection. Built for an IP65 protection degree and IK08 shock resistance according to IEC/EN 62262, the unit operates in ambient temperatures from -20°C to +40°C and has a net weight of 9.50 kg. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →Palazzoli
The Palazzoli 634101 is a universal foldable distribution board featuring four interlocked 16A 2P+E 230V socket-outlets, an integrated power terminal block, and MCB protection rated for 6 kW at 32A and 50/60Hz. Constructed from recyclable Palazzoli technopolymer with an IP65 protection degree and IK08 shock resistance, this 9.50 kg unit incorporates a 2P 32A switch type and a 32A 1P+N 30mA differential protection device, operating reliably within a maximum ambient temperature of +40°C and a minimum ambient temperature of -20°C. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this component.
View product details →Palazzoli
The Palazzoli 644110 is a universal foldable distribution board rated for 6 kW at 230V and 50/60Hz, featuring an IP65 protection degree and IK08 shock resistance according to IEC/EN 62262. This 32A 2P assembly integrates an MCB 2P 32A switch, a 32A 1P+N 30mA differential protection device, a power terminal block, fuse protection, three interlocked 16A 2P+E 230V socket-outlets, and one domestic 2P+E 10/16A socket-outlet with a net weight of 10.60 kg. It operates within a minimum and maximum ambient temperature range of -20°C to +40°C and withstands storage temperatures between -30°C and +70°C. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
The Palazzoli 644106 is a universal foldable distribution board rated for an 18 kW power capacity at 50/60Hz with a 32A rated current across 4 poles. This IP65-rated assembly features an MCB 4P 32A switch type, a 40A 4P 30mA differential protection device, a power terminal block, fuse protection, and four interlocked socket-outlets comprising two 16A 2P+E 230V outlets, one 16A 3P outlet, and one 32A 3P outlet. Built with an IK08 shock resistance according to IEC/EN 62262, the unit operates within a maximum ambient temperature of +40°C, a minimum ambient temperature of -20°C, and a net weight of 9.50 kg. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this Palazzoli distribution board.
View product details →Palazzoli
The Palazzoli 644105 is a universal foldable distribution board rated for an 18 kW power capacity at a 400V rated operating voltage and 50/60Hz frequency. This IP65-rated assembly features four interlocked socket-outlets comprising two 16A 2P+E 230V units and one 16A 3P unit, integrated with a power terminal block, fuse protection, a 32A 4P MCB switch type, and a 40A 4P 30mA differential protection device. Constructed with an IK08 shock resistance according to IEC/EN 62262, the 10 KG unit operates within a temperature range of -20°C to +40°C and stores between -30°C and +70°C. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →Palazzoli
The Palazzoli 644104 is a foldable universal distribution board rated for an 18 kW power capacity at 400V and 50/60Hz, featuring four interlocked socket-outlets comprising two 16A 2P+E 230V units and two 16A 3P units. Equipped with an MCB 4P 32A switch, 40A 4P 30mA differential protection, a power terminal block, and fuse protection, this 32A 4P assembly delivers an IP65 protection degree and IK08 shock resistance according to IEC/EN 62262. Operating within a temperature range of -20°C to +40°C and with a net weight of 10 KG, the unit supports storage temperatures from -30°C to +70°C. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
Palazzoli part number 644103 is a 400V, 18 kW universal foldable distribution board equipped with a 32A 4P MCB switch and a 40A 4P 30mA differential protection device. This IP65-rated assembly features four interlocked socket-outlets comprising three 16A 2P+E 230V units and one 16A 3P unit, alongside an integrated power terminal block and fuse protection operating at 50/60Hz. The 10 KG enclosure withstands an IK08 shock resistance rating according to IEC/EN 62262 and functions within an ambient temperature range of -20°C to +40°C. Submit the exact part number, quantity, and application requirements to receive an official RFQ.
View product details →
