Palazzoli
The Palazzoli 644102 is a universal foldable distribution board rated for 18 kW at 400V and 50/60Hz, featuring an IP65 protection degree and IK08 shock resistance according to IEC/EN 62262. This 32A, 4P unit includes a 4P 32A MCB switch, a 40A 4P 30mA differential protection device, a power terminal block, fuse protection, three interlocked socket-outlets of 16A 2P+E 230V, and one interlocked socket-outlet of 16A 3P. Operating effectively within a maximum ambient temperature of +40°C and a minimum ambient temperature of -20°C, the assembly weighs a net and gross 10KG while accommodating storage temperatures from -30°C to +70°C. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this EAN 8014950060160 component.
View product details →Palazzoli
The Palazzoli 644101 is a foldable universal distribution board rated at 6 kW, 32A, and 230V with a frequency of 50/60Hz. Fabricated from recyclable Palazzoli technopolymer, this IP65-rated assembly features four 16A 2P+E 230V interlocked socket-outlets, a 2P 32A MCB switch, a 32A 1P+N 30mA differential protection, a power terminal block, and fuse protection. It operates in ambient temperatures ranging from -20°C to +40°C, withstands storage temperatures between -30°C and +70°C, provides IK08 shock resistance according to IEC/EN 62262, and has a net and gross weight of 10 KG. Submit the exact part number, quantity, and application requirements for a formal quote.
View product details →Palazzoli
Palazzoli part number 634010 is a universal foldable distribution board rated for 6 kW at 50/60Hz with a 32A rated current and 2P poles. This IP65-rated unit features IK08 shock resistance, an MCB 2P 32A switch type, a 32A 2P 30mA differential protection, three interlocked 16A 2P+E 230V sockets, one domestic 2P+E 10/16 socket, and a 2P+T 32A power plug, operating within an ambient temperature range of -20°C to +40°C. With a net weight of 10 KG and EAN code 8014950060276, the assembly withstands storage temperatures from -30°C to +70°C. Submit the exact part number, quantity, and application requirements for an RFQ quote.
View product details →Palazzoli
The Palazzoli 634006 is a foldable universal distribution board rated for 18 kW at 32A and 50/60Hz, featuring IP65 protection and IK08 shock resistance. This unit includes an MCB 4P 32A switch, a 40A 4P 30mA differential protection device, a 3P+N+T 32A power plug, and four interlocked socket-outlets comprising two 16A 2P+E 230V, one 16A 3P, and one 32A 3P. Operating within an ambient temperature range of -20°C to +40°C and a storage range of -30°C to +70°C, the assembly has a net weight of 13 kg and an EAN code of 8014950060269. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this Palazzoli distribution board.
View product details →Palazzoli
The Palazzoli 634005 is an 18 kW universal distribution board featuring a foldable design with four interlocked socket-outlets, a power plug, and MCB protection rated for an IP65 degree of protection. This unit operates at a rated current of 32A across 50/60Hz frequencies, incorporating an MCB 4P 32A switch type, a 40A 4P 30mA differential protection, two interlocked 16A 2P+E 230V sockets, one interlocked 16A 3P socket, and a 3P+N+T 32A plug type with an IK08 shock resistance rating. Designed for an ambient operating temperature range of -20°C to +40°C and a net weight of 10.21 kg, the assembly maintains functionality under storage conditions from -30°C to +70°C. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Palazzoli
The Palazzoli 634004 is a universal foldable distribution board rated for an 18 kW power capacity at 50/60Hz with a 32A rated current and 4P poles. Built with an IP65 protection degree and IK08 shock resistance, this unit operates in ambient temperatures ranging from -20°C to +40°C and features an MCB 4P - 32A switch type, a 40A 4P 30mA differential protection, two interlocked socket-outlets 16A 2P+E 230V, two interlocked socket-outlets 16A 3P, and a 3P+N+T - 32A power plug with a net weight of 10.21 kg. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
The Palazzoli universal distribution board, part number 634002, is a foldable unit equipped with 4 interlocked socket-outlets, a power plug, and MCB protection rated for an 18 kW power capacity at 50/60Hz. It features an MCB 4P 32A switch type, a 40A 4P 30mA differential protection, three 16A 2P+E 230V interlocked socket-outlets, one 16A 3P interlocked socket-outlet, and a 3P+N+T 32A plug type with an IP65 protection degree and IK08 shock resistance. The device operates within a maximum ambient temperature of +40°C and a minimum of -20°C, while maintaining a net weight of 10.21 kg and a 4P pole configuration. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
The Palazzoli 634001 is a universal foldable distribution board rated at 6 kW, operating at 230V and 50/60Hz with a 32A rated current. This IP65-rated unit features an IK08 shock resistance according to IEC/EN 62262, a 2P 32A MCB switch, a 32A 1P+N 30mA differential protection, four interlocked 16A 2P+E 230V socket-outlets, and a 2P+T 32A power plug. Designed for ambient temperatures ranging from -20°C to +40°C and storage temperatures between -30°C and +70°C, the assembly has a net weight of 10.21 kg and a gross weight of 10.43 kg. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this Palazzoli distribution board.
View product details →Palazzoli
Manufactured by Palazzoli under part number 644010, this universal foldable distribution board delivers 6 kW of power at 50/60Hz with a rated current of 32A across 2P poles. The IP65-rated and IK08 shock-resistant enclosure houses an MCB 2P 32A switch, a 32A 1P+N 30mA differential protection device, three interlocked 16A 2P+E 230V socket-outlets, one domestic 2P+E 10/16 socket-outlet, and a 2P+T 32A plug, operating within an ambient temperature range of -20°C to +40°C. With a net weight of 10.60 kg, this unit requires a storage room temperature between -30°C and +70°C. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →Palazzoli
The Palazzoli 644006 is a universal foldable distribution board rated at 18 kW, 32A, and 50/60Hz with an IP65 protection degree and IK08 shock resistance. Weighing 9.50 kg net, this unit features a 4P 32A MCB switch, a 40A 4P 30mA differential protection device, a 3P+N+T 32A power plug, fuse protection, and four interlocked socket-outlets comprising two 16A 2P+E 230V, one 16A 3P, and one 32A 3P connections. It operates in ambient temperatures from -20°C to +40°C and withstands storage temperatures between -30°C and +70°C. Submit the exact part number, quantity, and application requirements for a quote.
View product details →Palazzoli
The Palazzoli 644005 is a foldable universal distribution board rated for an 18 kW power capacity at 50/60Hz with a 32A rated current and 4 poles. This IP65-rated unit features an MCB 4P 32A switch type, a 40A 4P 30mA differential protection device, two interlocked socket-outlets (16A 2P+E 230V), one interlocked socket-outlet (16A 3P), and a 3P+N+T 32A power plug with fuse protection. Constructed with an IK08 shock resistance according to IEC/EN 62262, the assembly operates within a maximum ambient temperature of +40°C and a minimum ambient temperature of -20°C, while maintaining a net weight of 10.88 KG. Submit the exact part number, quantity, and application requirements for an RFQ quote.
View product details →Palazzoli
Palazzoli part number 644004 is a foldable universal distribution board featuring an IP65 protection degree, an IK08 shock resistance rating, and an 18 kW power capacity operating at 50/60Hz. The unit incorporates a 32A 4P MCB switch, a 40A 4P 30mA differential protection device, two 16A 2P+E 230V interlocked socket-outlets, two 16A 3P interlocked socket-outlets, and a 3P+N+T 32A power plug with fuse protection, maintaining a net weight of 10.88KG across ambient operating temperatures from -20°C to +40°C. Submit the exact part number, quantity, and application requirements for a formal quote.
View product details →Palazzoli
The Palazzoli 644003 is a foldable universal distribution board rated for an 18 kW power capacity, 32A rated current, and 50/60Hz frequency across 4 poles. This IP65-rated unit features an MCB 4P - 32A switch type, a 40A 4P 30mA differential protection device, three interlocked 16A 2P+E 230V socket-outlets, one interlocked 16A 3P socket-outlet, and a 3P+N+T - 32A power plug with fuse protection. Constructed with an IK08 shock resistance, it operates within an ambient temperature range of -20°C to +40°C and a storage range of -30°C to +70°C, registering a net weight of 10.88 KG and a gross weight of 11.18 KG under EAN 8014950060306. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this component.
View product details →Palazzoli
The Palazzoli 644002 is a foldable universal distribution board rated for 18 kW at 32A and 50/60Hz, featuring IP65 protection and IK08 shock resistance. Weighing 10.88 kg net, this 4-pole assembly includes an MCB 4P 32A switch, 40A 4P 30mA differential protection, three interlocked 16A 2P+E 230V sockets, one interlocked 16A 3P socket, and a 3P+N+T 32A power plug. It operates within an ambient temperature range of -20°C to +40°C and can be stored between -30°C and +70°C. Submit the exact part number, quantity, and application requirements for a quote.
View product details →Palazzoli
The Palazzoli 644001 is a foldable universal distribution board rated for 6 kW at 230V and 50/60Hz, featuring four interlocked 16A 2P+E 230V socket-outlets with a 2P+T 32A power plug and fuse protection. This IP65-rated assembly includes a 32A 2P MCB switch, a 32A 1P+N 30mA differential protection device, and provides IK08 shock resistance for operation in ambient temperatures ranging from -20°C to +40°C. With a net weight of 10.88 KG, the unit accommodates storage temperatures between -30°C and +70°C. Submit the exact part number, quantity, and application requirements for an RFQ quote.
View product details →
Palazzoli
The Palazzoli 601540 is a stainless steel support engineered for ACS Janus distribution boards, manufactured using galvanized and painted steel. This component has a net weight of 4.55 KG, a gross weight of 5.06 KG, and corresponds to EAN code 8014950060382 in accordance with Reg. EU 2023/988 (GPSR) standards and directives. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Palazzoli
The Palazzoli 634100 is an empty portable distribution board measuring 329X572X325 mm, constructed from recyclable Palazzoli technopolymer in blue RAL 5015. This Insulation Class II unit features an IP65 protection degree, IK10 shock resistance according to IEC/EN 62262, and a rated insulation voltage of 500 V, accommodating up to 4 installable socket-outlets and 12 modules on a DIN rail. Operating within an ambient temperature range of -20°C to +40°C with a net weight of 5.90KG, this enclosure supports wired distribution boards for up to 4 interlocked or 8 fixed sockets. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Palazzoli
The Palazzoli 151353 is a wall-mounting steel junction box measuring 250x250x130 mm with a box height of 118 mm, finished with a non-toxic anti-UV polyester paint cured in the oven. Featuring an IP66/IP67 protection degree, IK10 shock resistance, and C4(M)/C3(H) equivalent corrosivity category, this unit operates at 690V~ with a 6000V rated impulse withstand voltage. It includes a ceramic terminal block with double contact configured for 5x2x35 mm² poles, four M40 holes, and fire resistance ratings of 830 °C for 120 minutes and 1000 °C for 90 minutes. Submit the exact part number, quantity, and application requirements for a formal quote.
View product details →Palazzoli
Manufactured by Palazzoli under part number 151351, this steel junction box features dimensions of 250X250X130 mm, an exterior height of 118 mm, and wall-mounting execution with four M40 holes. The unit includes ceramic terminal blocks with double contacts for 5x2x16 mm² sections, a rated operating voltage of 690V~, and a rated impulse withstand voltage of 6000V, protected by IP66/IP67 ingress ratings and IK10 shock resistance. Protected by a non-toxic polyester anti-UV oven-cured surface finish providing C4(M)/C3(H) equivalent corrosivity resistance, the 3.37 KG enclosure is fire-resistant at 830 °C for 120 minutes or 1000 °C for 90 minutes. Submit the exact part number, quantity, and application requirements to receive a quote.
View product details →Palazzoli
The Palazzoli 151355 is a wall-mounting steel junction box featuring dimensions of 150X150X90 mm with a box height of 78 mm and a net weight of 1.49 KG. This IP66/IP67 rated enclosure is fire resistant up to 830 °C for 120 minutes or 1000 °C for 90 minutes, and incorporates a ceramic terminal block with double contact rated for 690V~ and 6000V rated impulse withstand voltage. Constructed from steel with a non-toxic polyester anti-UV oven-cured surface finish equivalent to corrosivity category C4(M)/C3(H), the unit includes four M25 holes, 5x2x6 mm² poles for section, and provides an IK10 shock resistance according to IEC/EN 62262. Submit part number 151355, required quantity, and application requirements for a formal quote.
