Confirm the exact configuration
Use the manufacturer part number and model code—not appearance alone. Connection, size, material, voltage, pressure, seal, and control options can differ within the same product family.
Global industrial sourcing · Houston, Texas info@mropartsrfq.com
Reference imageConfirm configuration by manufacturer part number.
US Digital
MAE4
US Digital MAE4 — Linear Position Sensors Angle Sensors
The US Digital MAE4 is a miniature absolute kit encoder featuring a 12.7 mm case diameter and a 5V supply voltage. It provides analog and PWM outputs with shaft and bore diameter options of 1/8", 6 mm, and 1/4", operating within a temperature range of -40 to 125 °C. Request a quote by submitting the exact part number, quantity, and application requirements.
Request pricing and availabilityCommercial response within one business day for your destination and required quantity.
Request a QuoteWhy no listed price?
Industrial and obsolete parts are priced per enquiry: the final price depends on available stock, condition, quantity, and your delivery destination, so a fixed list price would be misleading. Request a quote and we confirm current pricing, lead time, and sourcing options — including hard-to-find and discontinued US Digital references — within one business day.
- Manufacturer
- US Digital
- Part number
- MAE4
- Product series
- MAE4 Miniature Absolute Kit Encoder
- Data verification
- Manufacturer evidence reviewed
For a faster response, include quantity, condition, and delivery destination.
Exact part-number verificationTechnical properties are matched to MAE4.
Worldwide sourcingSupport for planned and urgent industrial requirements.
Manufacturer documentationA document is added when the reviewed source provides one.
Verified configuration
Technical Specifications
- Product Name
- MAE4 Miniature Absolute Kit Encoder
- Product Category
- Linear Position Sensors Angle Sensors
- Function
- Absolute
- Category
- Encoder
- Case Ø [mm]
- 12.7
- Supply volatge [V]
- 5
- Output
- Analog, PWM
- Shaft & bore Ø [mm]
- 1/8", 6, 1/4"
- Temp. range [°C]
- -40 to 125
Engineering context
Identification and RFQ Guidance
What to include in your RFQ
Provide quantity, delivery country and ZIP/postal code, required condition, target date, and photographs of the existing nameplate when available.
Technical verification
Our sourcing response is prepared against US Digital MAE4. Final compatibility remains subject to the machine manufacturer’s requirements and complete application data.
