Industrial sourcing catalog
Search by Manufacturer Part Number
Browse verified product records and request commercial availability, lead time and technical documentation.
Festo
576456
Manifold block VABM-B10-20E-N38-5-P3
The Festo 576456 is an industrial component featuring a wrought aluminum alloy manifold rail with a width dimension of 22 mm and a product weight of 825 g. It accommodates a maximum number of 5 valve positions and provides a Corrosion Resistance Class of CRC 2 for moderate corrosion stress alongside VDMA24364-B1/B2-L LABS conformity. This RoHS-compliant part includes through-hole mounting, any mounting position, 3/8 NPT pneumatic connections 1 and 3, and a 1/8 NPT pilot air port 12. Submit the exact part number, quantity, and application requirements to receive a formal quote.
View product details →
Festo
575686
Air solenoid valve VUVS-L20-P53C-MZD-G18-F7-1C1
The Festo 575686 is a 21 mm electrical 5/3-way closed piston gate valve featuring a soft sealing principle and positive overlap lap. This piloted component delivers a nominal flow rate of 700 l/min through G1/8 pneumatic working ports across an operating pressure range of -0.9 bar to 10 bar utilizing 24V DC operating voltage. Equipped with an adjustable exhaust air function, mechanical spring reset, and IP65 protection degree with plug socket, it supports any mounting position and external pilot air supply with detenting or non-detenting manual override. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this c UL us recognized component.
View product details →SMC
GUL(F)20-50
SMC GUL(F)20-50 — Industrial Component
Source the SMC part number GUL(F)20-50 industrial component directly through our marketplace for your assembly needs. This specific unit carries the manufacturer designation GUL(F)20-50 as detailed in the official product catalog. Submit the exact part number, required quantity, and application requirements to receive a formal quotation.
View product details →
Festo
576455
Manifold block VABM-B10-20E-N38-4-P3
The Festo part number 576455 is an industrial component featuring a wrought aluminum alloy manifold rail with a width dimension of 22 mm and a product weight of 699 g. This assembly accommodates a maximum number of 4 valve positions and supports through-hole mounting in any position with RoHS compliant materials. Pneumatic connections 1 and 3 utilize 3/8 NPT ports, pilot air port 12 features a 1/8 NPT connection, and the unit maintains a corrosion resistance class (CRC) of 2 with VDMA24364-B1/B2-L LABS conformity. Submit the exact part number, quantity, and application requirements to request a quote for this component.
View product details →
Festo
575562
Air solenoid valve VUVS-L25-P53E-MD-N14-F8
The Festo 575562 is an electrical 26.5 mm piston gate valve featuring a 5/3 exhausted function and a 6.3 mm nominal width with internal pilot air supply. Operating at a pressure range of 0.25 MPa to 1 MPa (2.5 bar to 10 bar), this piloted valve delivers a normal nominal flow rate of 1000 l/min through 1/4 NPT pneumatic working ports and incorporates an adjustable exhaust air function with a soft sealing principle. Certified by c UL us - recognized (OL) and DNVGL-TAA000011J for maritime classification, it utilizes a mechanical spring reset, positive overlap lap, non-reversible flow direction, and supports both detenting and non-detenting manual override in any mounting position. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this industrial component.
View product details →
Festo
577333
Air solenoid valve VUVG-L10-M52-RT-M7-1H2L-W1
The Festo 577333 is a 10 mm electrical 5/2-way monostable piston gate valve featuring a piloted type of control with internal pilot air supply and a nominal width of 4 mm. Operating at 24V DC with an operating pressure range of 0.25 MPa to 0.8 MPa (2.5 bar to 8 bar), this unit delivers a normal nominal flow rate of 330 l/min through M7 pneumatic working ports. It includes an adjustable exhaust air function, a soft sealing principle, mechanical and pneumatic spring reset methods, and a covered manual override with detenting and non-detenting capabilities in any mounting position. Certified with the RCM compliance mark and c UL us recognized (OL), it carries CE and UKCA markings per EU and UK directives for EMC, low voltage, and RoHS while achieving an IP40 degree of protection with a plug socket. Submit the exact part number, quantity, and application requirements to receive a formal quote.
View product details →
Festo
575685
Air solenoid valve VUVS-L20-P53C-MZD-G18-F7
The Festo 575685 is an electrical 5/3-way closed industrial component utilizing a piston gate valve structural design with a soft sealing principle and positive overlap lap. Featuring a 21 mm valve size, 5 mm nominal width, and G1/8 pneumatic working port, this piloted unit delivers a normal nominal flow rate of 700 l/min across an operating pressure range of -0.09 MPa to 1 MPa. It incorporates a mechanical spring reset method, adjustable exhaust air function, external pilot air supply port, and both detenting and non-detenting manual override capabilities with a pilot pressure of 0.25 MPa to 1 MPa. Certified as c UL us recognized (OL) and mountable in any position with reversible flow direction, this part is available for procurement. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
AC-Motoren
ACMAAS3A042502W00001
AC-Motoren ACMAAS3A042502W00001 — Asynchronous-Motor ACM 250 M 4/PHE
The AC-Motoren ACMAAS3A042502W00001 is a regular 4-pole asynchronous motor of type ACM 250 M 4/PHE featuring a frame size of 250 and B3 mounting. This unit delivers an operating power of 55 kW at 400/690 V and a speed of 1485 1/min under S1 duty type, with insulation class F and an IP55 protection class. Submit the exact part number, quantity, and application requirements to request a quote for this component.
View product details →
Festo
576454
Manifold block VABM-B10-20E-N38-3-P3
The Festo part number 576454 is an industrial component featuring a wrought aluminum alloy manifold rail with a width dimension of 22 mm and a product weight of 574 g. It accommodates a maximum of three valve positions and utilizes through-hole mounting for installation in any position. This RoHS compliant assembly includes 3/8 NPT pneumatic connections 1 and 3, a 1/8 NPT pilot air port 12, a corrosion resistance class (CRC) rating of 2 for moderate corrosion stress, and VDMA24364-B1/B2-L LABS conformity. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
575561
Pneumatic valve VUWS-L25-P53U-M-N14
The Festo 575561 is a 26.5 mm pneumatic industrial component featuring a 5/3-way pressurized valve function with a piston gate valve structural design and soft sealing principle. It delivers a normal nominal flow rate of 1000 l/min through 1/4 NPT pneumatic working ports, operating within a pressure range of -0.9 bar to 10 bar utilizing direct control and internal pilot air supply. Featuring an adjustable exhaust air function, mechanical spring reset, and c UL us recognition, this reversible component supports any mounting position and positive overlap. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Danfoss Industrieautomatik
032U6157
Danfoss Industrieautomatik 032U6157 — Spare Parts Kit
The Danfoss Industrieautomatik part number 032U6157 is an industrial component specifically designated as the manufacturer model ERSATZTEILSATZ EV220B / 032U6157 with identifier 276253. This Danfoss Industrieautomatik replacement part assembly supports maintenance requirements for compatible valve systems. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
577332
Air solenoid valve VUVG-L10-B52-T-M7-1H2L-W1
The Festo 577332 is a 10 mm electrical 5/2-way bistable piston gate valve featuring a piloted type of control with internal pilot air supply and positive overlap lap. Operating on 24V DC within an operating pressure range of 0.15 MPa to 0.8 MPa (1.5 bar to 8 bar), this unit delivers a normal nominal flow rate of 340 l/min to 380 l/min through M7 pneumatic working ports. It incorporates an adjustable exhaust air function, soft sealing principle, IP40 degree of protection with a plug socket, and detenting, non-detenting, or covered manual override options for any mounting position. The component carries RCM compliance, c UL us recognition (OL), CE markings per EU EMC, low voltage, and RoHS directives, and UKCA markings to UK instructions for EMC, electrical equipment, and RoHS. Submit the exact part number, quantity, and application requirements for an RFQ quote.
View product details →SMC
GUL(F)20-250
SMC GUL(F)20-250 — Industrial Component
The SMC GUL(F)20-250 is an industrial component manufactured by SMC. This specific part is designated by the manufacturer part number GUL(F)20-250. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
575684
Pneumatic valve VUWS-L20-B52-G18
The Festo 575684 is a 21 mm piston gate valve featuring a bistable 5/2-way pneumatic actuation type and a normal nominal flow rate of 700 l/min normalized to DIN 1343. This directly controlled component operates within a pressure range of -0.09 MPa to 1 MPa (-0.9 bar to 10 bar) and incorporates a G1/8 pneumatic working port with an internal pilot air supply. Certified as c UL us recognized (OL), the valve includes a soft sealing principle, adjustable exhaust air function, and a 6 ms changeover time with any mounting position. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
576453
Manifold block VABM-B10-20E-N38-2-P3
The Festo 576453 is an industrial component featuring a wrought aluminum alloy manifold rail with a width dimension of 22 mm and a product weight of 449 g. This part provides a maximum of 2 valve positions and includes through-hole mounting with an any mounting position capability, along with 3/8 NPT pneumatic connections 1 and 3 and a 1/8 NPT pilot air port 12. Materials are RoHS compliant, and the assembly adheres to VDMA24364-B1/B2-L LABS conformity with a CRC rating of 2 for moderate corrosion stress. Submit the exact part number, quantity, and application requirements to receive a quote for this item.
View product details →
Festo
575560
Air solenoid valve VUVS-L25-P53U-MD-N14-F8
The Festo 575560 is a 26.5 mm electrical 5/3-way pressurized industrial component featuring a piston gate valve structural design with a soft sealing principle and positive overlap. It operates at pressures from 0.25 MPa to 1 MPa (2.5 bar to 10 bar) with an internal pilot air supply port, providing a normal nominal flow rate of 1000 l/min through 1/4 NPT pneumatic working ports and an adjustable exhaust air function. Certified by c UL us - recognized (OL) and DNVGL-TAA000011J for maritime classification, this piloted component includes a mechanical spring reset method, detenting and non-detenting manual override, and a nominal width of 6.3 mm for any mounting position. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
577329
Air solenoid valve VUVG-S10-T32C-AT-M5-1H2L-W1
The Festo part number 577329 is an electrical piston gate valve featuring a 2x3/2 closed, monostable valve function and a 10 mm valve size with M5 pneumatic working ports. Operating at 24V DC within a pressure range of 0.15 MPa to 0.8 MPa (1.5 bar to 8 bar), this piloted component delivers a normal nominal flow rate of 150 l/min through a 2.7 mm nominal width, utilizing a pneumatic spring reset, soft sealing principle, and adjustable exhaust air function. It includes an IP40 degree of protection with a plug socket, a covered manual override with detenting and non-detenting options, internal pilot air supply, and any mounting position, while carrying RCM, c UL us, CE, and UKCA compliance markings. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this component.
View product details →
Festo
576449
Manifold block VABM-B10-20E-G38-10-P3
Engineered with a wrought aluminum alloy manifold rail and a width dimension of 22 mm, this Festo industrial component part number 576449 supports any mounting position via through-hole installation and accommodates a maximum of 10 valve positions. The unit features G3/8 pneumatic connections 1 and 3, a G1/8 pilot air port 12, and a total product weight of 1451 g while providing VDMA24364-B1/B2-L LABS conformity alongside a corrosion resistance class of CRC 2 for moderate corrosion stress. Featuring RoHS-compliant materials, this hardware is ready for specification in your assembly. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
575683
Air solenoid valve VUVS-L20-B52-ZD-G18-F7-1C1
The Festo part number 575683 is a 21 mm electrical piston gate valve featuring a 5/2-way bistable valve function, piloted control, and an external pilot air supply port with a pilot pressure of 0.15 MPa to 1 MPa. It delivers a normal nominal flow rate of 700 l/min through G1/8 pneumatic working ports, operates at 24V DC across an operating pressure range of -0.9 bar to 10 bar, and achieves an IP65 degree of protection when utilizing a plug socket in accordance with IEC 60529. This component incorporates adjustable exhaust air, a soft sealing principle, positive overlap lap, reversible flow direction, and both detenting and non-detenting manual override options for installation in any mounting position. Submit the exact part number, quantity, and application requirements to request a quote for this c UL us-recognized industrial component.
View product details →SMC
GUL(F)20-25
SMC GUL(F)20-25 — Industrial Component
The SMC GUL(F)20-25 is an industrial component designed for factory automation and fluid power systems. This specific SMC part number incorporates the manufacturer's established engineering specifications for pneumatic or hydraulic integration. Request a formal quote for the SMC GUL(F)20-25 by submitting your exact part number, required quantity, and application parameters.
View product details →
