Industrial sourcing catalog
Search by Manufacturer Part Number
Browse verified product records and request commercial availability, lead time and technical documentation.
SMC
EVG342-5D-04FA-Q
SMC EVG342-5D-04FA-Q — Industrial Valve
SMC manufactures the EVG342-5D-04FA-Q industrial valve. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
541549
Sub-base-SET MS4-AGA-EX
The Festo 541549 is a size 4 industrial component belonging to the MS series, featuring G1/8 pneumatic connections for both port 1 and port 2. Built with a die-cast aluminum sub-base, NBR seals, and steel screws, this 128 g part includes RoHS compliant materials and conforms to VDMA24364-B1/B2-L LABS standards with a CRC rating of 2 for moderate corrosion stress. It operates within a medium temperature range of -10 °C to 60 °C. Submit the exact part number, quantity, and application requirements to receive a formal quote.
View product details →
Festo
542582
On/off valve MS6-EE-1/2-10V24
The Festo 542582 is an electrically actuated piston gate valve featuring a piloted, 3/2-way closed, monostable function with a non-detenting manual override and a mechanical spring reset. Operating at a pressure range of 4 bar to 10 bar, this component achieves a normal nominal flow rate of 7000 l/min, a C value of 29 l/sbar, and a b-value of 0.4 with an exhaust air function that cannot be throttled. It is driven by a 24 V DC, 2.5 W coil with permissible voltage fluctuations of +/- 10% and supports a 100% duty cycle within a medium temperature range of -10 °C to 60 °C. The unit accommodates compressed air per ISO 8573-1:2010 [7:4:4] or inert gases, permits oil lubrication, and features a moderate corrosion resistance class (CRC 2), RoHS compliance, and VDMA24364-B1/B2-L LABS conformity. Submit the exact part number, quantity, and application requirements to receive a quote.
View product details →
Festo
543543
Regulator plate VABF-S3-1-R5C2-C-10
The Festo 543543 is an industrial component designed with a width of 26 mm based on the ISO 15407-1 norm, featuring pneumatic vertical stacking for a reversible pressure regulator for ports 2 and 4. It delivers a constant output pressure with secondary exhausting across a pressure regulation range of 0.05 MPa to 0.85 MPa (0.5 bar to 8.5 bar, or 7.25 psi to 123.25 psi) and supports an inlet pressure 1 from 0.5 bar to 10 bar using compressed air as per ISO 8573-1:2010 [7:4:4]. Weighing 430 g with an IP65 and NEMA 4 degree of protection, this unit mounts in any position on a manifold sub-base or individual sub-base and accommodates an optional pressure gauge with a retaining clamp. Submit the exact part number, quantity, and application requirements to receive a formal quote.
View product details →
Festo
541544
Mounting bracket MS6-WP-EX
The Festo 541544 is an industrial component of size 6 within the MS series, featuring a product weight of 76 g and RoHS compliant materials. This assembly integrates die-cast aluminum brackets, a POM and steel module connector, steel screws, and NBR seals, yielding a CRC 2 moderate corrosion stress rating and VDMA24364-B1/B2-L LABS conformity for media temperatures ranging from -10 °C to 60 °C. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
543542
Regulator plate VABF-S3-2-R5C2-C-10
The Festo 543542 is an 18 mm industrial component based on the ISO 15407-1 norm, featuring a pneumatic vertical stacking pressure regulator for ports 2 and 4 that is reversible. It provides a constant output pressure with secondary exhausting across a regulation range of 0.05 MPa to 0.85 MPa (0.5 bar to 8.5 bar, or 7.25 psi to 123.25 psi) and supports an inlet pressure 1 of 0.5 bar to 10 bar. Weighing 245 g with an IP65 and NEMA 4 degree of protection, the unit operates in ambient temperatures from -5 °C to 50 °C and mounts in any position on a manifold or individual sub-base. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →SMC
25A-VP744-5DZ1-04F-M-X555
SMC 25A-VP744-5DZ1-04F-M-X555 — Industrial Valve
The SMC 25A-VP744-5DZ1-04F-M-X555 is an industrial valve manufactured by SMC. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
541543
Module connector MS6-MV-EX
The Festo part number 541543 is an industrial component of size 6 within the MS series, featuring a product weight of 54 g and RoHS compliant materials. Constructed with NBR seals, steel and POM module connectors, and steel screws, this module holds a corrosion resistance class of CRC 2 for moderate corrosion stress alongside VDMA24364-B1/B2-L LABS PWIS conformity. It operates within a medium temperature range of -10 °C to 60 °C. Submit the exact part number, quantity, and application requirements to receive an RFQ quote.
View product details →
Festo
542580
On/off valve MS4-EE-1/8-10V24
The Festo 542580 is a 3/2-way closed, monostable piston gate valve featuring piloted electrical actuation, a non-detenting manual override, and a mechanical spring reset. Operating at pressures from 4 bar to 10 bar, this component delivers a normal nominal flow rate of 1000 l/min with a C value of 4.5 l/sbar and a b-value of 0.5, supporting a 100% duty cycle at 24 V DC and 1.8 W. It is designed for compressed air meeting ISO 8573-1:2010 [7:4:4] or inert gases within a medium temperature range of -10 °C to 50 °C, where oil lubrication is possible and required for continued use. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
543541
Regulator plate VABF-S3-1-R5C2-C-6
The Festo part number 543541 is a 26 mm wide industrial component designed for pneumatic vertical stacking as a reversible pressure regulator for ports 2 and 4, complying with ISO 15407-1. Featuring a constant output pressure controller function with secondary exhausting, it operates within a regulation range of 0.05 MPa to 0.6 MPa (0.5 bar to 6 bar, or 7.25 psi to 87 psi) and an inlet pressure range of 0.5 bar to 10 bar using compressed air as per ISO 8573-1:2010 [7:4:4]. This IP65 and NEMA 4 rated unit weighs 430 g, supports any mounting position on a manifold or individual sub-base, and includes an optional pressure gauge connection with a retaining clamp. Submit the exact part number, quantity, and application requirements to receive a quote.
View product details →
Festo
541542
Mounting bracket MS6-WPB-EX
The Festo part number 541542 is an industrial component from the MS series in size 6, featuring a product weight of 115 g, a medium temperature range of -10 °C to 60 °C, and a CRC of 2 for moderate corrosion stress. Built with NBR seals, a die-cast aluminum bracket, steel screws, and POM and steel module connectors, the unit adheres to VDMA24364-B1/B2-L LABS conformity and RoHS material regulations. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
542579
On/off valve MS4-EE-1/4-10V24-Z
The Festo 542579 is a 3/2-way, closed, monostable industrial component featuring a piston gate valve structural design with electrical actuation and piloted control. It operates within a pressure range of 4 bar to 10 bar, delivers a normal nominal flow rate of 2000 l/min, and maintains a 100% duty cycle powered by 24 V DC at 1.8 W coil characteristics. This unit includes a mechanical spring reset method, non-detenting manual override, positive overlap lap, and accommodates compressed air per ISO 8573-1:2010 [7:4:4] or inert gases with a medium temperature range of -10 °C to 50 °C. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Danfoss Power Solutions
810188719
Danfoss Power Solutions 810188719 — Pressure Relief Valve
The Danfoss Power Solutions industrial component, part number 810188719, features a Buna-N seal material and operates with a pressure adjustment range of 70 to 315 bar (1015 to 4569 psi). This unit supports a rated pressure of 315 bar (4500 psi) and delivers a rated flow of 40 l/min (11 US gal/min) at 7 bar (100 psi). Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
543540
Regulator plate VABF-S3-2-R5C2-C-6
The Festo part number 543540 is an ISO 15407-1 compliant industrial component featuring an 18 mm width and a pneumatic vertical stacking pressure regulator for ports 2 and 4 that is reversible. It provides a constant output pressure with secondary exhausting, an inlet pressure range of 0.5 bar to 10 bar, and a pressure regulation range of 0.05 MPa to 0.6 MPa (0.5 bar to 6 bar or 7.25 psi to 87 psi). Built with an IP65 and NEMA 4 degree of protection, a 245 g product weight, and CRC 0 corrosion resistance, this unit operates on compressed air per ISO 8573-1:2010 [7:4:4] across an ambient temperature range of -5 °C to 50 °C. Submit the exact part number, quantity, and application requirements for an RFQ quote.
View product details →
Festo
541541
Sub-base-SET MS6-AGE-EX
This Festo industrial component from the MS series is sized at 6 and features G3/4 pneumatic connections for both port 1 and port 2. Built with a die-cast aluminum sub-base, NBR seals, and steel screws, the unit weighs 300 g, complies with RoHS materials standards, achieves a VDMA24364-B1/B2-L LABS conformity, and operates under a moderate corrosion stress corrosion resistance class (CRC) 2 within a medium temperature range of -10 °C to 60 °C. Request a quote today by submitting part number 541541 along with your required quantity and application parameters.
View product details →SMC
25A-VP742-5YZ1-04FA
SMC 25A-VP742-5YZ1-04FA — Industrial Valve
The SMC 25A-VP742-5YZ1-04FA is an industrial valve manufactured by SMC. Please submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
542578
On/off valve MS4-EE-1/4-10V24
The Festo 542578 is a 3/2-way closed, monostable industrial component featuring a piloted, electrically actuated piston gate valve with a non-detenting manual override and mechanical spring reset. Operating at pressures from 4 bar to 10 bar, this unit delivers a normal nominal flow rate of 2000 l/min, a C value of 9.5 l/sbar, a b-value of 0.44, and a positive overlap lap with an unthrottleable exhaust air function. Designed for a 100% duty cycle using 24 V DC (1.8 W) coil characteristics, it functions within a medium temperature range of -10 °C to 50 °C with compressed air per ISO 8573-1:2010 [7:4:4] or inert gases, where oil lubrication is possible and required for continued operation. The assembly provides moderate corrosion stress resistance (CRC 2), VDMA24364-B1/B2-L LABS conformity, and RoHS-compliant materials. Submit the exact part number, quantity, and application requirements for a formal quote.
View product details →
Festo
543539
Regulator plate VABF-S3-1-R4C2-C-10
The Festo 543539 is an industrial component featuring a width of 26 mm based on the ISO 15407-1 norm and a product weight of 430 g for mounting in any position on a manifold sub-base or individual sub-base. It functions as a pneumatic vertical stacking pressure regulator for ports 2 and 4, providing a constant output pressure with secondary exhausting across a regulation range of 0.2 MPa to 0.85 MPa (2 bar to 8.5 bar, or 29 psi to 123.25 psi) given an inlet pressure 1 of 0.5 bar to 10 bar. Operating with compressed air as per ISO 8573-1:2010 [7:4:4] and allowing for oil lubrication, this RoHS-compliant unit achieves an IP65 and NEMA 4 degree of protection within an ambient temperature range of -5 °C to 50 °C. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
541540
Sub-base-SET MS6-AGD-EX
The Festo 541540 is an industrial component from the MS series featuring a size 6 body and G1/2 pneumatic connections on both ports 1 and 2. Constructed with a die-cast aluminum sub-base, NBR seals, and steel screws, this RoHS-compliant unit supports a medium temperature range of -10 °C to 60 °C and has a product weight of 300 g. It provides a corrosion resistance class (CRC) of 2 for moderate corrosion stress and conforms to VDMA24364-B1/B2-L LABS (PWIS) requirements. Submit the exact part number, quantity, and application requirements to receive a formal quote.
View product details →
Festo
542577
Soft-start valve MS6N-DE-3/8-10V24-Z
The Festo part number 542577 is a 2/2 piston seat industrial component featuring electrical actuation, piloted control, and an internal pilot air supply port with a non-reversible flow direction. This unit operates within a 4 bar to 10 bar pressure range, delivers a normal nominal flow rate of 5050 l/min, and utilizes a 24 V DC 1.8 W coil at a 100% duty cycle with a mechanical spring reset. Constructed with a moderate corrosion resistance class (CRC 2), it supports compressed air and inert gases according to ISO 8573-1:2010 [7:4:4] with optional oil lubrication, a detenting and non-detenting manual override, and any mounting position. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this Festo component.
View product details →
