Industrial sourcing catalog
Browse verified product records and request commercial availability, lead time and technical documentation.
Festo
The Festo 153250 is an industrial component featuring a structural design based on the push-pull principle with a nominal width of 6.3 mm, one supply line, and six outlets. It accommodates an operating pressure from -0.095 MPa to 0.6 MPa across its entire temperature range and supports compressed air or liquid water media within an ambient temperature range of -10 °C to 80 °C. This standard-sized unit weighs 214 g, provides a nominal tightening torque of 26 Nm with a ±20% tolerance, and features a coating on the screwed plug seal with a CRC rating of 1. Submit the exact part number, quantity, and application requirements to receive a formal quote.
View product details →
Festo
The Festo 153058 is an L-shaped industrial component featuring a push-pull structural design with a standard size, a 4.7 mm nominal width, and an 18.1 mm tubing insertion depth. Weighing 5.7 g and equipped with an 8 mm push-in sleeve and an 8 mm pneumatic tubing connection, this unit operates across any mounting position with compressed air or liquid water within a -10 °C to 80 °C ambient temperature range. This pack size of 10 components achieves ISO 14644-1 Class 4 cleanroom suitability alongside a CRC rating of 1 and VDMA24364-B1/B2-L LABS conformity. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
The Festo part number 151775 is a double-acting industrial component featuring a 63 mm equivalent piston diameter, an adjustable stroke from 1 mm to 1000 mm, and an M16x1.5 piston rod thread. This profile barrel design incorporates an oval piston providing torsion protection with a maximum torque of 2 Nm and a piston rod rotation angle of +/- 0.67 degrees, supported by adjustable pneumatic cushioning at both ends and dual-side position sensing via proximity switch. It operates within a pressure range of 0.06 MPa to 1 MPa using compressed air according to ISO 8573-1:2010 [7:4:4] across an ambient temperature range of -20 °C to 80 °C, delivering a theoretical retracting force of 1682 N at 6 bar. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this unit.
View product details →
Festo
The Festo 153416 is a standard, L-shaped industrial component featuring a 6.2 mm nominal width, 20 mm tubing insertion depth, and a push-pull structural design with a coated screwed plug seal. Weighing 56 g, it supports compressed air operation per ISO 8573-1:2010 [7:-:-] across a temperature-dependent pressure range of -0.95 bar to 14 bar and a standard operating pressure range of -0.95 bar to 6 bar within an ambient temperature range of 0 °C to 60 °C. This part accommodates a maximum rotational speed of 300 rpm, a maximum radial torque of 0.02 Nm, and a nominal tightening torque of 15.5 Nm with a ±20% tolerance, maintaining a CRC rating of 1 and VDMA24364-B1/B2-L LABS conformity. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
Engineered with a standard L-shape design and a 3.2 mm nominal width, this Festo industrial component utilizes a push-pull structural principle for a 6 mm push-in sleeve connection and a 6 mm outside diameter pneumatic tubing connection with a blue releasing ring. The part accommodates any mounting position, a 17 mm tubing insertion depth, a product weight of 3.9 g, and operates with compressed air or liquid, ice-free water within a temperature range of -10 °C to 80 °C. It features a CRC of 1, VDMA24364-B1/B2-L LABS conformity, ISO 14644-1 Class 4 cleanroom suitability, and an operating pressure ranging from -0.095 MPa to 0.6 MPa for the entire temperature range or up to 1.4 MPa depending on temperature. Submit the exact part number, quantity, and application requirements to receive a quote for this pack size of 10.
View product details →
Festo
The Festo 153249 is an industrial component featuring a standard size with one supply line and six outlets utilizing a push-pull structural design. It operates with compressed air as per ISO 8573-1:2010 [7:-:-] or ice-free liquid water, accommodating an operating pressure from -0.095 MPa to 1.4 MPa depending on temperature and media. This unit weighs 205 g, includes a coated screwed plug seal, and features a nominal tightening torque of 15.5 Nm with a ±20% tolerance. Submit the exact part number, quantity, and application requirements for an official quote.
View product details →
Festo
The Festo 151774 is a double-acting industrial component featuring a 50 mm equivalent piston diameter, an M16x1.5 piston rod thread, and a variable stroke ranging from 1 mm to 1000 mm. Built with a structural profile barrel, piston, and through piston rod design, it utilizes an oval piston for torsion protection, an adjustable pneumatic cushioning system at both ends, and built-in position sensing via proximity switch. It operates within a pressure range of 0.6 bar to 10 bar using compressed air meeting ISO 8573-1:2010 [7:4:4] standards, delivering a theoretical retracting force of 989 N at 6 bar across an ambient temperature range of -20 °C to 80 °C. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 153415 is a standard L-shaped industrial component featuring a nominal width of 4.6 mm, an 18 mm tubing insertion depth, and a push-pull structural design with a coated screwed plug seal. This unit operates within a temperature-dependent pressure range of -0.95 bar to 14 bar and an entire temperature range pressure of -0.95 bar to 6 bar, supporting compressed air media per ISO 8573-1:2010 [7:-:-] with optional lubricated operation. Weighing 39 g with a corrosion resistance class of 1 and a maximum rotational speed of 400 rpm, it accommodates an ambient temperature range of 0 °C to 60 °C and a nominal tightening torque of 15.5 Nm. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
The Festo 153056 is a standard L-shape industrial component featuring a 2 mm nominal width, 14.9 mm tubing insertion depth, and a push-pull structural design for a 4 mm push-in sleeve and 4 mm outside diameter pneumatic tubing. Weighing 2.7 g with a blue releasing ring, it operates on compressed air meeting ISO 8573-1:2010 [7:-:-] or liquid, ice-free water across an ambient temperature range of -10 °C to 80 °C, supporting pressures from -0.095 MPa to 1.4 MPa depending on temperature. This pack of 10 components achieves ISO 14644-1 Class 4 cleanroom suitability and VDMA24364-B1/B2-L LABS conformity with a CRC 1 low corrosion stress rating. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
The Festo 153248 is a standard industrial component featuring one supply line and six outlets with a nominal width of 5.2 mm and a 20.2 mm tubing insertion depth based on a push-pull structural design. This unit operates with compressed air or liquid, ice-free water across an ambient temperature range of -10 °C to 80 °C, supporting a nominal tightening torque of 15.5 Nm with a ±20% tolerance. Weighing 126 g with a corrosion resistance class of 1, the part utilizes a coated seal on the screwed plug and allows for lubricated operation in any mounting position. Submit the exact part number, quantity, and application requirements for an RFQ quote.
View product details →
Festo
The Festo 153055 is a standard, L-shaped industrial component featuring an R1/2 external thread pneumatic connection 1, a 13 mm nominal width, and a 24.1 mm tubing insertion depth utilizing a push-pull structural design with a coated screwed plug seal. Weighing 79 g and mountable in any position via an external hexagon SW22, this unit operates with compressed air or liquid water under temperature-dependent pressures ranging from -0.95 bar to 14 bar and ambient temperatures between -10 °C and 80 °C. It maintains ISO 14644-1 Class 4 cleanroom suitability alongside a CRC 1 corrosion resistance class and VDMA24364-B1/B2-L LABS conformity. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 153414 is an L-shaped industrial component featuring a standard size, a 4.6 mm nominal width, and an 18 mm tubing insertion depth utilizing a push-pull structural design with a coated screwed plug seal. Designed for compressed air operating media compliant with ISO 8573-1:2010 [7:-:-], this unit operates within a temperature range of 0 °C to 60 °C and supports lubricated operation with a product weight of 32 g. It accommodates an operating pressure of -0.095 MPa to 0.6 MPa across the full temperature range and -0.095 MPa to 1.4 MPa under temperature-dependent conditions, alongside a maximum rotational speed of 400 rpm, a maximum radial torque of 0.015 Nm, and a nominal tightening torque of 9 Nm with a ±20% tolerance. Please submit the exact part number, quantity, and application requirements for a quote.
View product details →
Festo
The Festo 151773 is a double-acting industrial component featuring a 40 mm equivalent piston diameter, an M12x1.25 piston rod thread, and an adjustable stroke ranging from 1 mm to 1000 mm. Built with a profile barrel structural design and an oval piston for anti-torsion guidance, this unit incorporates adjustable pneumatic cushioning at both ends, a 21 mm cushioning length, and a maximum piston rod rotation angle of plus or minus 1.4 degrees. It operates within a pressure range of 0.06 MPa to 1 MPa using compressed air conforming to ISO 8573-1:2010 [7:4:4] and provides a theoretical retracting force of 633 N at 6 bar across an ambient temperature range of -20 °C to 80 °C. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 153247 is a standard industrial component featuring a nominal width of 5.2 mm, a 20.2 mm tubing insertion depth, and one supply line with six outlets utilizing a push-pull structural design. This part operates with compressed air as per ISO 8573-1:2010 [7:-:-] or liquid, ice-free water, handling an operating pressure ranging from -0.95 bar to 6 bar across its entire temperature range of -10 °C to 80 °C. Featuring a coated seal on the screwed plug, a nominal tightening torque of 9 Nm with a ±20% tolerance, a product weight of 122 g, and a low corrosion stress rating of CRC 1, it supports lubricated operation and has any mounting position. Submit the exact part number, quantity, and application requirements to receive a quote.
View product details →
Festo
The Festo 153054 is a standard L-shaped industrial component featuring a nominal width of 10.3 mm, an R1/2 external thread for pneumatic connection 1, and an external hexagon SW21 mounting type with a coated screwed plug seal. Built on a push-pull structural design with a 23.4 mm tubing insertion depth, this part operates with compressed air according to ISO 8573-1:2010 [7:-:-] or ice-free liquid water across temperatures from -10 °C to 80 °C. It supports an operating pressure of -0.095 MPa to 0.6 MPa for the entire temperature range and up to 1.4 MPa depending on the temperature, while weighing 61 g with Class 4 cleanroom suitability measured per ISO 14644-1. Submit the exact part number, quantity, and application requirements for a quote on this Festo component.
View product details →
Festo
The Festo part number 153413 is a standard, L-shaped industrial component featuring a 4.6 mm nominal width, an 18 mm tubing insertion depth, and a push-pull structural design with a coated screwed plug seal. This component operates with compressed air according to ISO 8573-1:2010 [7:-:-] across a temperature-dependent pressure range of -0.095 MPa to 1.4 MPa and an entire-temperature-range pressure of -0.095 MPa to 0.6 MPa, while supporting lubricated operation, a maximum rotational speed of 400 rpm, and a nominal tightening torque of 7 Nm with a ±20% tolerance. Weighing 33 g, the unit has a corrosion resistance class of 1, VDMA24364-B1/B2-L LABS conformity, an ambient temperature range of 0 °C to 60 °C, a maximum radial torque of 0.015 Nm, and allows for any mounting position. Submit the exact part number, quantity, and application requirements to receive a quote.
View product details →
Festo
The Festo 153246 is a standard industrial component featuring a push-pull structural design with 1 supply line and 6 outlets, providing a nominal width of 4.1 mm and an 18.1 mm tubing insertion depth. It operates with compressed air per ISO 8573-1:2010 [7:-:-] or ice-free liquid water, supporting an operating pressure of -0.095 MPa to 0.6 MPa across its full temperature range and up to 1.4 MPa under temperature-dependent conditions. Weighing 81 g with a corrosion resistance class of 1 and a nominal tightening torque of 15.5 Nm (±20%), this unit accommodates any mounting position and permits lubricated operation. Submit the exact part number, quantity, and application requirements to receive a formal quote.
View product details →
Festo
The Festo 151772 is a double-acting industrial component featuring a 32 mm equivalent piston diameter, an M10x1.25 piston rod thread, and an adjustable stroke range from 1 mm to 1000 mm within a profile barrel structural design. This unit utilizes an oval piston for torsion protection up to a 1 Nm max torque, incorporates adjustable pneumatic cushioning at both ends with a 19 mm cushioning length, and operates within a 0.6 bar to 10 bar pressure range using compressed air. Position sensing is achieved via a proximity switch, while the assembly supports any mounting position, features a through piston rod variant, and delivers a theoretical retracting force of 415 N at 6 bar. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 153053 is an L-shaped industrial component featuring a nominal width of 10 mm and a 23.4 mm tubing insertion depth utilizing the push-pull principle. It operates with compressed air per ISO 8573-1:2010 [7:-:-] or liquid water, supporting pressures from -0.095 MPa to 1.4 MPa depending on temperature, and includes a coated screwed plug with an R3/8 external thread and external hexagon SW17 mounting. This pack size of 10 components weighs 38 g each, achieves ISO 14644-1 Class 4 cleanroom suitability, and features a corrosion resistance class of 1 for low corrosion stress across an ambient temperature range of -10 °C to 80 °C in any mounting position. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
The Festo 153412 is a standard L-shaped industrial component featuring a nominal width of 3.1 mm, a tubing insertion depth of 17 mm, and a push-pull structural design utilizing a coating seal on the screwed plug. Operating on compressed air per ISO 8573-1:2010 [7:-:-], this 23 g part supports a temperature-dependent operating pressure of -0.095 MPa to 1.4 MPa and a max rotational speed of 500 rpm with any mounting position. It achieves a nominal tightening torque of 9 Nm with a ±20% tolerance, a max radial torque of 0.012 Nm, and a corrosion resistance class of 1 under ambient temperatures from 0 °C to 60 °C. Submit the exact part number, quantity, and application requirements for a quote.
View product details →
