Festo
549947
Tie rod cylinder DNG-1 5/8"- -PPV-A-S2
The Festo part number 549947 is a double-acting industrial component with a 1 5/8" piston diameter, a UNF1/2-20 piston rod thread, and a stroke length adjustable from 1 to 2,000 mm based on the ISO 15552 standard. This piston and piston rod assembly features adjustable pneumatic cushioning at both ends (PPV), a 21 mm cushioning length, proximity sensor position detection, and an S2 through piston rod variant designed for an operating pressure range of 0.6 to 10 bar using dried compressed air. It delivers a theoretical force of 754 N on the advance stroke and 633 N on the return stroke at 6 bar, operating within an ambient temperature range of -20 to 80 °C with a CRC 2 corrosion resistance classification, a basic weight of 790 g for a 0 mm stroke, and an additional weight of 40 g per 10 mm of stroke. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
