Festo
549965
Standard cylinder DNGZK-4"- -PPV-A
The Festo 549965 is a double-acting industrial component featuring a 4-inch piston diameter, a single-ended piston rod with a UNF3/4-16 male thread, and an adjustable pneumatic cushioning system (PPV) at both ends with a 30 mm cushioning length. Built on the ISO 15552 standard, this unit operates within a pressure range of 0.6 to 10 bar using dried compressed air, delivering a theoretical force of 4,712 N on the advance stroke and 4,418 N on the return stroke at 6 bar. It supports any assembly position, includes position detection for proximity sensors, and maintains a basic weight of 6,210 g with an additional 100 g per 10 mm stroke across a stroke range of 1 to 2,000 mm within an ambient temperature of -20 to 80 °C. Submit the exact part number, quantity, and application requirements to request a quote.
