Festo
537780
Receiver SOEG-E-Q50-PA-K-3L
The Festo 537780 is an industrial block-design through-beam sensor receiver utilizing an infrared optoelectronic measuring principle for position detection with a working range of 0 to 15,000 mm. This component conforms to EN 60947-5-2 standards, carries RCM and c UL us - Listed (OL) authorizations, and features copper- and PTFE-free materials alongside a CE symbol according to the EU-EMV guideline. Operating on a DC voltage range of 10 to 30 V with 10% residual ripple and 30 mA idle current, the unit incorporates a PNP switch output with antivalent switching element function, supporting a maximum switching frequency of 1,000 Hz, a maximum output current of 200 mA, a voltage drop of 2.4 V or less, and pulsing short circuit strength within an ambient temperature range of -20 to 60 °C. Submit the exact part number, quantity, and application requirements to request a quote for this component.
