Festo
35212
Semi-rotary actuator DRQ-32-90-PPVJ-A
The Festo part number 35212 is a double-acting industrial component utilizing a rack and pinion design structure with a size 32 and a product weight of 2,270 g. It features an adjustable PPVJ pneumatic cushioning with a 77.3 deg cushioning angle, a 90 deg swivel angle, and a setting range of swivel angle on both sides of -5 /+ 5 deg. Operating at a working pressure of 2.5 to 10 bar using compressed air in accordance with ISO8573-1:2010 [7:-:-], this unit delivers a theoretical torque of 5 Nm at 6 bar and a max swivel frequency of 2.8 Hz at 6 bar. The assembly position is any, and it includes internal female threads for mounting, G1/8 pneumatic connections, provisions for proximity sensors, a case-hardened steel drive shaft, and TPE-U(PU) and NBR seals within an ambient temperature range of -10 to 60 °C. Submit the exact part number, quantity, and application requirements for a formal quote.
