Festo
32474
Standard cylinder DNU-32-500-PPV-A
The Festo part number 32474 is a double-acting industrial component featuring a 32 mm piston diameter, a 500 mm stroke, and an M10x1,25 male piston-rod end. Built with a single-ended piston rod and adjustable pneumatic cushioning at both ends (PPV), this unit conforms to ISO 6431, operates between 0.6 and 12 bar using dried compressed air, and provides theoretical forces of 462 N on advance stroke and 393 N on return stroke at 6 bar. It includes position detection for proximity sensors, holds a corrosion resistance classification CRC of 2, functions in ambient temperatures from -20 to 80 °C in any assembly position, and carries Germanischer Lloyd authorization. Submit the exact part number, quantity, and application requirements for a formal quote.
