Festo
172785
Round cylinder DSAH-63- -P-A
This double-acting industrial component from Festo features a 63 mm piston diameter with a variable stroke length ranging from 1 to 500 mm, utilizing flexible cushioning rings or plates at both ends. Operating on compressed air compliant with ISO8573-1:2010 [7:4:4] within a 1 to 10 bar pressure range and an ambient temperature span of -20 to 80 °C, it delivers a theoretical advance force of 1,870 N and a return force of 1,682 N at 6 bar. The assembly incorporates a high alloy steel non-corrosive housing, wrought aluminum alloy covers, NBR and TPE-U(PU) seals, a high alloy steel piston rod, and an M8 pneumatic connection, with a basic weight of 1,397 g at 0 mm stroke. Submit the exact part number, quantity, and application requirements for a formal quotation.
