Industrial sourcing catalog
Search by Manufacturer Part Number
Browse verified product records and request commercial availability, lead time and technical documentation.

Festo
3659494
ISO cylinder DSBC-50-40-D3-PPSA-N3
Engineered by Festo, part number 3659494 is an ISO 15552 compliant double-acting industrial component featuring a 50 mm piston diameter, a 40 mm stroke, and an external M16x1.5 piston rod thread on one end. Built with a profile barrel, piston, and piston rod, this unit operates on compressed air within a 0.04 MPa to 1.2 MPa pressure range and incorporates self-adjusting pneumatic end-position cushioning with a 22 mm cushioning length. It achieves a theoretical retracting force of 990 N at 6 bar, supports position sensing via proximity switch, and functions reliably across an ambient temperature range of -20 °C to 80 °C. Submit the exact part number, quantity, and application requirements to request a quote for this component.
View product details →
Festo
36380
Standard cylinder DNG-80-500-PPV-A
The Festo 36380 is a double-acting industrial component featuring an 80 mm piston diameter, a 500 mm stroke, and an M20x1,5 male piston-rod thread adhering to ISO 15552 standards. Operating within a pressure range of 0.6 to 12 bar using compressed air conforming to ISO 8573-1:2010 [7:4:4], this single-ended piston rod unit delivers theoretical forces of 3,016 N on the advance stroke and 2,721 N on the return stroke at 6 bar. It incorporates adjustable pneumatic cushioning at both ends with a 30 mm cushioning length, position detection for proximity sensors, and Germanischer Lloyd authorization while supporting an ambient temperature range of -20 to 80 °C and CRC 2 corrosion resistance. Submit your exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
3659493
ISO cylinder DSBC-50-30-D3-PPSA-N3
The Festo 3659493 is a double-acting industrial component featuring a 50 mm piston diameter, a 30 mm stroke, and an M16x1.5 piston rod thread conforming to ISO 15552. Built with a profile barrel, piston, and piston rod at one end, this unit operates on compressed air from 0.4 bar to 12 bar and delivers a theoretical retracting force of 990 N at 6 bar. It incorporates self-adjusting pneumatic end-position cushioning with a 22 mm cushioning length, position sensing via a proximity switch, and moderate corrosion resistance rated at CRC 2. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →IMI-Norgren
WD2D-KITK
IMI-Norgren WD2D-KITK — Industrial Component
Source the IMI-Norgren WD2D-KITK industrial component directly through our marketplace. Request a formal quotation for this exact part number by submitting your required quantity and application specifications.
View product details →
Festo
3637972
Axial kit EAMM-A-S38-40P-G2
The Festo 3637972 industrial component features a nominal length of 44.7 mm, an actuator interface code of S38, and a motor-in interface code of 40P. This RoHS-compliant part supports a maximum rotational speed of 8000 rpm, a transferable torque of 6.5 Nm, and a mass moment of inertia of 5.87 kgmm² within an IP40-rated enclosure weighing 280 g. Featuring VDMA24364-B2-L LABS conformity and an any-position mounting capability, the unit operates in ambient temperatures from -10 °C to 60 °C, relative air humidity between 0 and 95%, and storage temperatures ranging from -25 °C to 60 °C. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →Filtration Group
77760259
Filtration Group 77760259 — Seal Kit
The Filtration Group part number 77760259, also designated as manufacturer model DICHTSATZ PIS 3076/86 / 77760259 | 348511, is an industrial component designed for specific filtration system configurations. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this item.
View product details →
Festo
3637971
Axial kit EAMM-A-S38-40A-G2
This Festo industrial component, part number 3637971, features a nominal length of 44 mm, a mass moment of inertia of 5.87 kgmm², and a transferable torque of 6.5 Nm with a maximum rotational speed of 8000 rpm. Designed with an actuator interface code of S38 and a motor input interface code of 40A, the unit weighs 270 g, maintains an IP40 degree of protection, and conforms to VDMA24364-B2-L LABS (PWIS) requirements. It operates within an ambient temperature range of -10 °C to 60 °C, tolerates storage temperatures from -25 °C to 60 °C and relative air humidity up to 95%, features RoHS-compliant materials, and supports any mounting position. Submit the exact part number, quantity, and application requirements to receive a formal quote.
View product details →
Festo
3659492
ISO cylinder DSBC-50-25-D3-PPSA-N3
Engineered to ISO 15552 standards by Festo, part number 3659492 is a double-acting industrial component featuring a 50 mm piston diameter, a 25 mm stroke, and an external M16x1.5 piston rod thread on one end. The profile barrel design incorporates self-adjusting pneumatic end-position cushioning with a 22 mm cushioning length, 1 J end-position impact energy, and position sensing via proximity switch for operation across a 0.4 bar to 12 bar pressure range. Delivering a theoretical retracting force of 990 N at 6 bar using compressed air meeting ISO 8573-1:2010 [7:4:4], this unit supports any mounting position, an ambient temperature range of -20 °C to 80 °C, and moderate CRC 2 corrosion stress with VDMA24364-B1/B2-L LABS conformity. Submit your exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
3843
Blanking plug B-M5
The Festo part number 3843 is an industrial component comprising an anodized aluminum blanking plug with an M5 external thread and an external hexagon AF 7 mounting type. Featuring a nominal tightening torque of 1.33 Nm with a ±20% tolerance, this RoHS compliant plug incorporates an O-ring made of NBR and high-grade steel, achieves VDMA24364-B1/B2-L LABS conformity, and weighs 1 g with a pack size of 10. Submit your exact part number, quantity, and application requirements for a quote.
View product details →IMI-Norgren
WD2D-KITJ
IMI-Norgren WD2D-KITJ — Industrial Component
The IMI-Norgren WD2D-KITJ is an industrial component manufactured by IMI-Norgren. Submit your exact part number, quantity, and application requirements to request a quote for this part.
View product details →
Festo
3637970
Axial kit EAMM-A-S62-80P-G2
The Festo part number 3637970 is an industrial component featuring a nominal length of 77 mm, a product weight of 970 g, and a mass moment of inertia of 34.8 kgmm², with an actuator interface code of S62 and motor in interface codes of 80P, 80PA, and 80RA. It delivers a transferable torque of 17 Nm at a maximum rotational speed of 6000 rpm, operates in ambient temperatures from -10 °C to 60 °C with an IP40 degree of protection, and maintains RoHS material compliance and VDMA24364-B2-L LABS conformity. This unit supports any mounting position, relative air humidity levels of 0 to 95%, and storage temperatures ranging from -25 °C to 60 °C. Submit the exact part number, quantity, and application requirements for an RFQ quote.
View product details →
Festo
3659491
ISO cylinder DSBC-50-20-D3-PPSA-N3
The Festo 3659491 is a double-acting industrial component featuring a 50 mm piston diameter, a 20 mm stroke, and an M16x1.5 external piston rod thread conforming to ISO 15552. Built with a piston, piston rod, and profile barrel structural design, this unit operates at pressures from 0.04 MPa to 1.2 MPa utilizing compressed air per ISO 8573-1:2010 [7:4:4] with self-adjusting pneumatic end-position cushioning. It delivers a theoretical retracting force of 990 N at 6 bar across an ambient temperature range of -20 °C to 80 °C while accommodating position sensing via proximity switch. Submit the exact part number, quantity, and application requirements to receive a quote.
View product details →Filtration Group
77967433
Filtration Group 77967433 — Seal Kit
The Filtration Group part number 77967433 is an industrial component identified by manufacturer model DICHTSATZ PI20063-PI20100 NBR / 77967433 | 330146. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
35416
Vacuum suction cup VASB-100-1/4-NBR
Engineered with a 100 mm round protective 1.5-fold bellows suction cup and an effective diameter of 85 mm, this Festo industrial component part number 35416 operates with atmospheric air based on ISO 8573-1:2010 [7:-:-]. It features an NBR suction cup with a shore hardness of 60 +/-5, a die-cast zinc screwed plug, a nominal width of 4 mm, and a G1/4 mounting thread, vacuum connection, and suction cup mounting positioned at the top. The unit delivers a breakaway force and holding force of 397 N at a 70% vacuum across an ambient temperature range of -20 °C to 80 °C, incorporating RoHS-compliant materials and VDMA24364-B1/B2-L LABS conformity in a black finish. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
3838404
Mounting kit EAHM-E17-K2-100
This Festo industrial component, designated by part number 3838404, features a product weight of 3000 g and incorporates galvanized steel screws. It meets VDMA24364-B2-L LABS conformity with a CRC corrosion resistance class of 1 for low corrosion stress, while the materials are RoHS compliant. Submit the exact part number, quantity, and application requirements to receive a formal quotation for this unit.
View product details →
Festo
3659482
ISO cylinder DSBC-50-320-D3-PPVA-N3
The Festo 3659482 is a double-acting industrial component featuring a 50 mm piston diameter, a 320 mm stroke, and an M16x1.5 external piston rod thread conforming to ISO 15552. Built with a profile barrel structural design, this unit operates within a pressure range of 0.04 MPa to 1.2 MPa using compressed air according to ISO 8573-1:2010 [7:4:4], delivering a theoretical retracting force of 990 N at 6 bar. It incorporates adjustable pneumatic cushioning at both ends with a 22 mm cushioning length, position sensing via proximity switch, and a moderate corrosion resistance class (CRC 2) for ambient temperatures between -20 °C and 80 °C. Submit the exact part number, quantity, and application requirements to request a quote for this component.
View product details →
Festo
3637967
Axial kit EAMM-A-S38-55A-G2
The Festo part number 3637967 is an industrial component featuring a nominal length of 48 mm, a mass moment of inertia of 5.87 kgmm², and a product weight of 340 g. Designed with an actuator interface code of S38 and a motor-in interface code of 55A, it supports a transferable torque of 6.5 Nm and a maximum rotational speed of 8000 rpm. This RoHS-compliant unit operates within an ambient temperature range of -10 °C to 60 °C, a storage temperature range of -25 °C to 60 °C, and 0 to 95 % relative air humidity while maintaining an IP40 degree of protection, VDMA24364-B2-L LABS conformity, and an unrestricted mounting position. Submit the exact part number, quantity, and application requirements for a quote.
View product details →IMI-Norgren
WD2D-KITH
IMI-Norgren WD2D-KITH — Industrial Component
Source the IMI-Norgren WD2D-KITH industrial component directly for your facility's maintenance and assembly operations. Submit the exact part number, quantity, and application requirements to receive a formal quotation.
View product details →
Festo
35415
Vacuum suction cup VASB-75-1/4-NBR
The Festo 35415 is a black round protective bellows 1.5-fold industrial component featuring a 75 mm suction cup diameter, 60 mm effective suction cup diameter, and 15.5 mm height compensation with a nominal width of 4 mm and 65.5 cm³ volume. Weighing 95 g with a 60 +/-5 Shore hardness, it mounts via a G1/4 vacuum connection in any position and delivers a holding force of 197 N at a nominal operating pressure of -0.07 MPa (-0.7 bar, -10.15 psi) within an operating pressure range of -0.095 MPa to 0 MPa (-0.95 bar to 0 bar, -13.775 psi to 0 psi). Built for atmospheric air based on ISO 8573-1:2010 [7:-:-] across an ambient temperature range of -20 °C to 80 °C, the unit offers moderate corrosion stress resistance (CRC 2) and VDMA24364-A1-L LABS conformity. Submit the exact part number, quantity, and application requirements to request a quote.
View product details →
Festo
3838337
Mounting kit EAHM-E17-K2-30
This Festo industrial component, part number 3838337, has a product weight of 2050 g and features galvanized steel screws. It complies with RoHS material standards and possesses a corrosion resistance class (CRC) of 1 for low corrosion stress, along with VDMA24364-B2-L LABS conformity. Submit the exact part number, quantity, and application requirements for a formal quotation.
View product details →
